Embedded Integration Kit
Copyright and Trademark
Copyright 2000, Lantronix. All rights reserved. No part of the contents of this book may
be transmitted or reproduced in any form or by any means without the written permission
of Lantronix. Printed in the United States of America.
User's Guide
Covering these Device Servers:
CoBox-Micro
CoBox-Mini
CoBox-Mini100
UDS-10B
Revision C 1/02
Part Number 900-226
