To Configure Line Settings; Statistics; To View Line Statistics - Lantronix PremierWave XC User Manual

Line Command
Mode Settings
Serial String
Echo Serial String
Signon Message

To Configure Line Settings

Note: The following section describes the steps to view and configure Line 1 settings;
these steps apply to other line instances of the device.
Using Web Manager

To configure a specific line, click Line in the menu bar and select Line 1 -> Configuration.

To configure a specific line in Command Mode, click Line in the menu bar and select Line 1 -
> Command Mode.
Using the CLI

To enter Line 1 command level: enable -> line 1
Using XML

Include in your file: <configgroup name="line" instance="1">

Include in your file: <configgroup name="serial command mode" instance="1">

Statistics

To View Line Statistics

Using Web Manager

To view statistics for a specific line, click Line in the menu bar and select Line 1 ->
Statistics.
Using the CLI

To view Line statistics: enable -> line 1, show statistics
PremierWave XC User Guide
Description
Enter the Text or Binary string of bytes that must be read on the Serial Line during
boot time in order to enable Command Mode. It may contain a time element to
specify a required delay in milliseconds x, formed as {x}. Applies only if mode is "Use
Serial String". It may contain a binary character(s) of the form [x]. For example, use
decimal [12] or hex [0xc].
Select Enabled or Disabled for Echo Serial String. Applies only if mode is "Use
Serial String". Select enable to echo received characters back out on the line while
looking for the serial string.
Enter the string of bytes to be sent to the Serial Line during boot time. It may contain
a binary character(s) of the form [x]. For example, use decimal [12] or hex [0xc].
7: Line and Tunnel Settings
48
