SSH Settings

The SSH settings control CLI access to the PremierWave XC over the SSH protocol.
SSH Settings
SSH State
SSH Port
SSH Max Sessions

To Configure SSH Settings

Using Web Manager

To configure SSH settings, click CLI in the menu bar and select Configuration.
Using the CLI

To enter the SSH command level: enable -> config -> cli -> ssh
Using XML

Include in your file:
<configgroup name="ssh">
and
<configitem name="state">

XML Settings

The PremierWave XC allows for the configuration of units using an XML configuration record
(XCR). Export a current configuration for use on other PremierWave XCs or import a saved
configuration file.

XML: Export Configuration

You can export the current system configuration in XML format. The generated XML file can be
imported later to restore a configuration. It can also be modified and imported to update the
configuration on this PremierWave XC unit or another. The XML data can be dumped to the
screen or exported to a file on the file system.
By default, all groups are exported. You may also select a subset of groups to export.
PremierWave XC User Guide

Table 12-4 SSH Settings

Description
Select Enabled or Disabled to enable or disable CLI access via SSH.
Specify the SSH Port and override the default, as needed. Blank the field to
restore the default.
Specify the maximum number of concurrent SSH sessions that will be allowed.
12: Advanced Settings
85
