14
CONTROL COMMAND

D Band stacking register

To send or read the desired band stacking register's
contents, a combination of the frequency band and the
register codes ("01" is fixed as the register code) as fol-
lows are used.
For example, when sending/reading the contents in
the 21 MHz band, the code "0701" is used.
• Frequency band codes
CODE BAND
01 1.8 MHz
02 3.5 MHz
03 7 MHz
04 10 MHz
05 14 MHz
06 18 MHz
07 21 MHz
08 24 MHz
09 28 MHz
10 50 MHz
11 General

D Data mode with filter width setting

The following data sequence is used when sending or
reading the data mode with filter width setting.
q w
X X X
First parameter
00=Data mode OFF
01=Data mode ON
91
FREQUENCY RANGE
1.800000 – 1.999999
3.400000 – 4.099999
6.900000 – 7.499999
9.900000 – 10.499999
13.900000 – 14.499999
17.900000 – 18.499999
20.900000 – 21.499999
24.400000 – 25.099999
28.000000 – 29.999999
50.000000 – 54.000000
Other than above
X
Second parameter
00=Data mode OFF
01=FILTER Wide
02=FILTER Middle
03=FILTER Narrow
