CONTROL COMMAND
Command table (continued)
Command
Sub command
1A
0314
0315
0316
0317
0318
0319
0320
0321
0322
0323
0324
04
1B
00
01
1C
00
01
D D Band stacking register
To send or read the desired band stacking register's con-
tents, combined code of the frequency band and register
codes as follows are used.
For example, when sending/reading the contents in the
21 MHz band, the code "0701" is used.
• Frequency band code
Code
Freq. band
01
1.8
02
3.5
03
7
04
10
05
14
06
18
07
21
08
24
09
28
10
50
11
GENE
73
Description
Send/read RTTY marker fre-
quency (0=1275 Hz, 1=1615 Hz,
2=2125 Hz)
Send/read RTTY shift width
(0=170 Hz, 1=200 Hz, 2=425 Hz)
Send/read RTTY keying polarity
(0=Normal, 1=Reverse)
Send/read noise blanker level
(0=min. to 255=max.)
Send/read key type (0=Normal,
1=Reverse, 2=Bug, 3=OFF,
4=Mic. [UP]/[DN])
Send/read CW keyer dot/dash
ratio (28=1:1:2.8 to 45=1:1:4.5)
Send/read CW keyer repeat time
(01=1 sec. to 60=60 sec.)
Send/read CW keyer transmission
indication (0=Normal, 1=First 3-
character, 2= First 3-character+
contact number)
Send/read contact number style
(0=Normal, 1=190→ANO,
2=190→ANT, 3=90→NO,
4=90→NT)
Send/read count up trigger chan-
nel (1=MK1, 2=MK2, 3=MK3)
Send/read present number (1–999)
Send/read DATA mode (0=OFF,
1=ON)
Set/read repeater tone frequency
Set/read TSQL tone frequency
Set/read the transceiver's condi-
tion (0=Rx; 1=Tx)
Set/read antenna tuner condition
(0=OFF, 1=ON, 2=Start tuning or
while tuning)
Frequency range (unit: MHz)
1.800000–1.999999
3.400000–4.099999
6.900000–7.499999
9.900000–10.499999
13.900000–14.499999
17.900000–18.499999
20.900000–21.499999
24.400000–25.099999
28.000000–29.999999
50.000000–54.000000
Other than above
• Register code
Code
Registered number
01
D D Codes for memory keyer contents
To send or read the desired memory keyer contents, the
channel and character codes as follows are used.
• Channel code
Code
Channel number
01
02
03
• Character's code
Character
ASCII code
0–9
30–39
Numerals
A–Z
41–5A
Alphabetical characters
space
20
Word space
/
2F
Symbol
?
3F
Symbol
,
2C
Symbol
.
2E
Symbol
^
5E
e.g., to send
✱
2A
Inserts contact number (can be
used for 1 channel only)
D D Codes for memory name contents
To send or read the desired memory name settings, the
character codes, instructed codes for memory keyer con-
tents as above, and follows are additionally used.
• Character's code— Alphabetical characters
Character
ASCII code
a–z
61–7A
• Character's code— Symbols
Character
ASCII code
!
21
$
24
&
26
?
3F
'
27
+
2B
:
3A
=
3D
>
3E
)
29
]
5D
}
7D
_
5F
1
MK1
MK2
MK3
Description
, enter ^4254
BT
Character
ASCII code
—
—
Character
ASCII code
#
23
%
25
¥
5C
"
22
`
60
–
2D
;
3B
<
3C
(
28
[
5B
{
7B
|
7C
–
7E
