Icom IC-7200 Instruction Manual page 77

Key speed
This item adjusts the CW key speed. The key speed can
be selected from 6 to 60* wpm.
* 39, 43, 45, 47, 49, 51, 53, 55, 56, 58 and 59 cannot be
selected.
CW pitch
This item adjusts the CW receive pitch. The pitch can be
selected from 300 to 900 Hz in 10 Hz steps.
Side tone level
This item adjusts the CW side tone level from 0% to
100% in 1% steps.
Side tone level limit
Turn the CW side tones output level limiting capability
ON and OFF.
When this item is set to ON, the CW side tone is linked to
the [AF] control until rotation of the [AF] control reaches
to the specified level—further rotation will not increase
the volume of the CW side tones.
on : CW side tone level is limited with the [AF] control.
oF : CW side tone level is linked to the [AF] control.
Twin peak filter
This item turns the twin peak filter ON or OFF.
on : Twin peak filter is ON.
oF : Twin peak filter is OFF.
NOTE: The RTTY mark frequency (2125 Hz) and shift
width (170 Hz) are automatically set when the twin
peak filter is ON.
RTTY mark tone
This item selects the RTTY mark frequency. There are 3
selectable values: 1275, 1615 and 2125 Hz.
NOTE: 2125 Hz is automatically set when the twin
peak filter is ON.
(CW mode)
(CW mode)
(CW mode)
(CW mode)
(RTTY mode)
(RTTY mode)
SET MODE
20 WPM (default)
600 Hz (default)
30% (default)
ON (default)
OFF (default)
2125 Hz (default)
10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
72
