Mainboard Overview - Top (Connectors)
Figure 9
Mainboard Top
Connectors
1. USB Port
2. Inverter
Connector
3. Speaker
Connector
4. LCD Cable
Connector
5. Power Board
Connector
6. Keyboard Cable
Connector
7. Audio Board
Connector
8. Microphone
Cable Connector
9. TouchPad Cable
Connector
10. Fingerprint
Connector
11. Modem
Connector
1 - 10 Mainboard Overview - Top (Connectors)
4
2
3
1
1
11
5
6
8
10
9
7
