EUROCOM M400A COBRA User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M400A COBRA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EUROCOM M400A COBRA

Summary of Contents for EUROCOM M400A COBRA

  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Infor- mation contained herein is for reference only and does not constitute a commitment on the part of the man- ufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be dam- aged.
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifi- Warning cations, consult your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the com- puter. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshoot- ing, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 15: Table Of Contents

    Preface Contents Notice ................I System Map: Left View ......... 1-11 FCC Statement ............II System Map: Right View ........1-12 Instructions for Care and Operation ..... IV System Map: Bottom View ........1-13 Power Safety ............VI Windows XP Start Menu & Control Panel .... 1-14 Battery Precautions ..........VII Video Features ............
  • Page 16 Preface 8 Channel Sound Support ........2-13 Battery FAQ ............3-12 Adding a Printer .............2-14 Drivers & Utilities USB Printer ............2-14 Install Instructions: ..........2-14 What to Install ............4-1 Parallel Printer ............2-14 Module Driver Installation ........4-1 Service Packs ............4-3 Power Management Authorized Driver Message ........
  • Page 17 Preface Wireless LAN .............4-12 Power On Boot Beep (Advanced Menu) ....5-9 Bluetooth .............4-12 Security Menu ............5-10 PC Camera ............4-12 Set Supervisor Password (Security Menu) .... 5-10 Password on boot: (Security Menu) ....... 5-11 BIOS Utilities Fixed disk boot sector (Security Menu) ....5-11 Boot Menu .............
  • Page 18 Preface Intel PRO/Wireless 2915ABG WLAN Interface (Ports & Jacks) Driver Installation ..........7-4 Overview ..............A-1 Bluetooth Module .............7-5 Ports and Jacks ............A-2 Bluetooth Driver Installation ........7-5 Built-In Microphone ..........A-2 PC Camera ..............7-7 Card Reader Port ............. A-2 PC Camera Driver Installation ......7-8 DC-In Jack ..............
  • Page 19 Preface Display Modes ............B-6 Audio ..............D-4 Clone Mode ............B-7 Keyboard & Pointing Device ........D-4 Extended Desktop Mode ........B-8 PCMCIA ..............D-5 Enabling TV Display ..........B-11 Interface ..............D-5 Card Reader ............D-5 Intel Video Driver Controls Communication ............
  • Page 20 Preface XVIII...

  • Page 21: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Model Differences

    Quick Start Guide Model Differences This notebook series includes four different model types. The models differ in video support, system memory (RAM) supported, and AC adapter supplied. Models A & B include ATI X700 (ATI M26) PCI Express video cards, Models C & D include built-in Intel (Intel GMA 900) video (see “Video Features”...

  • Page 23: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 24: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows XP) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals. System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the Microsoft Win- dows XP (Home &...

  • Page 25: System Startup

    Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC adapter.

  • Page 26: System Map: Top View With Lcd Panel Open

    Quick Start Guide System Map: Top View with LCD Panel Open Optional Built-In PC Camera Wireless Device Operation Aboard LED Power & Aircraft Communication Indicators The use of any portable LED Status Indicators electronic transmission devices aboard aircraft is AP-Key Buttons usually prohibited.

  • Page 27: Led Indicators

    Quick Start Guide LED Indicators Table 1 - 3 - LED Status Indicators The two sets of LED indicators (LED Power & Com- munication Indicators and LED Status Indicators) Icon Color Description on the computer display helpful information about the current status of the computer.

  • Page 28: Ap-Key Buttons

    Quick Start Guide AP-Key Buttons Keyboard These buttons give instant access to the default Inter- The keyboard has an embedded numerical keypad for net browser and e-mail program, and toggle power to easy numeric data input (see Figure 1 - 3) and features the optional module(s) (WLAN/Bluetooth/PC Cam- Function Keys to allow you to change operational fea-...
  • Page 29 Quick Start Guide Function Keys To use the function keys, press and hold the Fn key, then press the appropriate function key (Esc - F10 etc.). Function Function Function Key Fn + F8 Decrease LCD Brightness Fn + Esc Sleep Toggle Fn + F9 Increase LCD Brightness Fn + F3...

  • Page 30: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front & Rear Views LCD Latches Speaker Built-In Microphone Infrared Transceiver S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack Line-In Jack Vent/Fan Intake 10. DC-In Jack 11. Security Lock Slot 12.

  • Page 31: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 5 Left View RJ-45 LAN Jack S-Video-Out Port External Monitor Port Mini-IEEE 1394 Port 2 * USB 2.0 Ports External USB Hard Disk Drives Mini-IEEE 1394 Port If you are using an external USB HDD (or any USB device with The Mini-IEEE 1394 Port only supports SELF POW- a power rating of 500mA or above), make sure you use the ERED IEEE 1394 devices.

  • Page 32: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 6 - Right View Optical Device Drive Bay (for CD/DVD Device - see page PC Card Slot (see page 3-in-1 Card Reader (reads SD/ MMC/ & MS formats - see page RJ-11 Phone Jack Speaker Changing DVD Regional Codes...

  • Page 33: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 7 - Bottom View Vent/Fan Intake Modem/Bluetooth & Modem Combo Module The CPU is not a user ser- Cover viceable part. Opening this CPU Cover compartment, or access- ing the CPU in any way, Hard Disk/Memory/WLAN may violate your warranty.

  • Page 34: Windows Xp Start Menu & Control Panel

    Quick Start Guide Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 35: Video Features

    Quick Start Guide Video Features Your computer will have EITHER an ATI X700 (ATI M26) PCI Express video card (Model A & B comput- ers), OR built-in Intel (Intel GMA 900) on-board video (Model C & D computers), depending on your pur- chase option (see “Video Adapter”...
  • Page 36 Quick Start Guide ATI Display Properties Intel Display Properties Figure 1 - 9 - Display Properties Desktop 1 - 16 Video Features...

  • Page 37: Display Devices & Options

    Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV as your display device. A VGA monitor/Flat Panel Display connects to the external monitor port, a TV to the S-Video-Out Port.

  • Page 38: Power Management Features

    Quick Start Guide Power Management Features The Power Options control panel icon in Windows (see page 14) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk (by means of Power Schemes), or you may use either Standby or Hibernate mode to conserve power throughout the system (enable Hibernate support from the control panel as pictured in Figure 1 -...

  • Page 39: Features & Components

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and compo- nents of the computer: • The Hard Disk Drive • The Optical (CD/DVD) Device • The 3-in-1 Card Reader •...

  • Page 40: Hard Disk Drive

    Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk Power Safety can be taken out to accommodate other 2.5" serial (SATA) OR parallel (PA- TA) hard disk drives with a height of 9.5 mm. Before attempting to access any of the inter- components...

  • Page 41: Optical Device

    Features & Components Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The ac- Sound Volume tual device will depend on the module you purchased (see “Storage” on Adjustment page D - 4). The optical device is usually labeled “Drive D:” and may be used as a boot device if properly set in the BIOS (see “Boot Menu”...

  • Page 42: Handling Cds Or Dvds

    Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/ CD Emergency Eject DVDs can be accessed. If you need to manually Note the following: eject a CD (e.g.

  • Page 43: Dvd Regional Codes

    Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...

  • Page 44: 3-In-1 Card Reader

    Features & Components 3-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. • MMC (MultiMedia Card) • SD (Secure Digital) •...

  • Page 45: Pc Card Slot

    Features & Components PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PC- PC Card Slot Cover MCIA CardBus PC Card Slot. Make sure you install the PCMCIA/Card Read- er Card driver (see “What to Install”...

  • Page 46: Auto Mail Checker

    Features & Components Auto Mail Checker After you have installed the driver for the Auto Mail Checker program (see “What to Install” on page 4 - 1) you may then configure it to give you noti- fication when you receive new mail. You must be online to receive this noti- fication (note that this program only supports the POP3 protocol), and your default mail program does not need to be open.
  • Page 47 Features & Components You may then configure the options for your mailserver, name, password, pro- gram and method(s) of notification. Note Check with your Inter- net Service Provider, network administrator or Mail Service provid- er for details on what to put on these pages.

  • Page 48: Touchpad And Buttons/Mouse

    Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a Mouse Driver mouse to your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. The central button may If you are using an ex- be configured to function as you require.

  • Page 49: Configuring The Infrared Settings For Fir

    Features & Components Configuring the Infrared Settings for FIR To configure your computer for Fast Infrared (FIR) communication follow these steps: Infrared Communication Click Start, point to Settings and click Control Panel (or just click Start > The infrared transceiv- Control Panel).

  • Page 50: Audio Features

    Features & Components Audio Features You can configure the audio options on your computer from the Sounds and Sound Volume Audio Devices Windows control panel (see Figure 1 - 8 on page 1 - 14), Adjustment or from the Sound Effect Manager icon in the taskbar/control panel (this will bring up the Realtek Audio Configuration menus).

  • Page 51: Channel Sound Support

    Features & Components 8 Channel Sound Support If you wish to configure your system for 8 channel sound support, then the fol- lowing ports should be used as outputs. • Side Speaker Out - Connect to S/PDIF Out • Center/Subwoofer Speaker Out - Connect to Microphone In •...

  • Page 52: Adding A Printer

    Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions Parallel Printer will help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the printer attach the paral- lel cable to the printer.

  • Page 53: Power Management

    Power Management Chapter 3: Power Management OS Note Overview Power management To conserve power, especially when using the battery, your computer uses the functions will vary ACPI power management system. Power management conserves power by slightly depending on controlling individual components of the computer (the monitor and hard disk your operating system.

  • Page 54: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC adapter or a battery pack. Power Button as Standby or AC Adapter Hibernate Button Use only the AC adapter that comes with your computer (Models A & B - DC Output 20V, 4.5A minimum/ Models C &...

  • Page 55: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press Shutdown the power button on the front panel. Note that you should always shut your com- When the computer is on, you can use the power button as a Standby/Hiber- puter down by choos- nate/Shutdown hot-key button when it is pressed for less than 4 seconds Turn...

  • Page 56: Power Schemes

    Power Management Power Schemes You can set your computer to conserve power through individual components Resuming by means of Power Schemes. You can also adjust the settings for each Operation scheme to set the monitor to turn off after a specified time, and the computer's The system can re- hard disk motor to turn off if the hard disk drive has not been accessed for a sume from Monitor or...
  • Page 57 Power Management Each Windows Power Scheme will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.

  • Page 58: System Power Options

    Power Management System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This system features Standby and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - Figure 3 - 2 on page 3 -...

  • Page 59: Standby

    Power Management Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is System Resume made to idle at its slowest speed. All open applications are retained in memo- The system can resume ry.

  • Page 60: Configuring The Power Button

    Power Management Configuring the Power Button The power button may be set to send the computer in to either Standby or Hi- bernate mode (Figure 3 - 3). In Standby mode, the LED will flash green. In Hibernate mode the LED will be off. If you are in a power saving mode set to save power through individual components (e.g.

  • Page 61: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery New Battery Warning Always completely discharge, then fully charge, a new battery (see “Battery When the battery is FAQ” on page 3 - 12 for instructions on how to do this).

  • Page 62: Recharging The Battery With The Ac Adapter

    Power Management Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. Conserving Battery Power We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason see “Removing the Battery”...

  • Page 63: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 64: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Caution Don’t turn off the computer by yourself even when you see a message that in- Danger of explosion if dicates the battery is critically low, just let the computer use up all of the bat- battery is incorrectly...

  • Page 65: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utilities essential to the operation or improvement The Device Drivers & Utilities + User’s Manual of some of the computer’s subsystems. The system CD-ROM contains the drivers and utilities neces- takes advantage of some newer hardware compo- sary for the proper operation of the computer.
  • Page 66 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver installation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”.

  • Page 67: Service Packs

    Drivers & Utilities Service Packs Check the warnings on the following pages regard- ing installation of the appropriate Service Pack for Windows XP Service Pack 2 your Windows OS. Make sure you have installed Make sure you install Windows XP Service Pack 2 the appropriate Service Pack before installing all (or a Windows XP version which includes Service the drivers.

  • Page 68: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message Updating/Reinstalling Individual Drivers If you receive a message telling you that the driver you are installing is not authorized (Digital Signa- If you wish to update/reinstall individual drivers it ture Not Found), just click Yes or Continue Any- may be necessary to uninstall the original driver.

  • Page 69: Driver Installation

    Drivers & Utilities Driver Installation NoteBook Driver Installation Application Insert the Device Drivers & Utilities + User’s Man- Check the driver installation order from Table 4 - ual CD-ROM and the NoteBook Driver Installa- 1, on page 4 - 6 (the drivers must be installed tion application will run automatically.
  • Page 70 Drivers & Utilities Feature Windows XP (SP2) Service Pack Install Service Pack 2 on your system if not included in your Windows version Chipset Page 4 - 8 Audio Page 4 - 8 Modem Page 4 - 9 Network (LAN) Page 4 - 9 (see “ATI Video Driver Installation”...

  • Page 71: Manual Driver Installation

    Drivers & Utilities Manual Driver Installation Driver Installation Procedure If you wish to install the drivers manually, click the This section covers driver and utility installation in- Exit button to quit the NoteBook Driver Installa- structions for Windows XP Home & Professional. tion application, then follow the manual installa- New Hardware Found tion procedure for each driver.

  • Page 72: Chipset

    Drivers & Utilities Chipset Audio 1. Double-click Chipset from the NoteBook 1. Double-click AUDIO from the NoteBook Driver Installation menu. Driver Installation menu. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse..) to D:\Drivers\ (Browse..) to D:\Drivers\ 00Chipset\setup.exe and click OK.

  • Page 73: Modem

    Drivers & Utilities Modem 1. Double-click MODEM from the NoteBook 1. Double-click LAN from the NoteBook Driver Installation menu. Driver Installation menu. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse..) to D:\Drivers\ (Browse..) to D:\Drivers\ 02Modem\Setup.exe and click OK.

  • Page 74: Video

    Drivers & Utilities Video AP-Key The installation of the video driver will depend on 1. Double-click AP-Key from the NoteBook your video system: Driver Installation menu. For ATI PCI Express video cards (Models A & B Click Start (menu) > Run... and navigate only) see “ATI Video Driver Installation”...

  • Page 75: Touchpad

    Drivers & Utilities TouchPad PCMCIA/Card Reader 1. Double-click TouchPad from the NoteBook 1. Double-click PCMCIA from the NoteBook Driver Installation menu. Driver Installation menu. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse..) to D:\Drivers\ (Browse...) to D:\Drivers\ 06Touchpad\SETUP.EXE and click OK.

  • Page 76: Automail

    Drivers & Utilities AutoMail Wireless LAN 1. Double-click AutoMail from the NoteBook See the introduction in “Intel PRO/Wireless Mini- PCI WLAN Module” on page 7 - 2, and check the Driver Installation menu. install procedure for your appropriate module and operating system.

  • Page 77: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return Setup and restore the Configuration: The Setup utility Setup Defaults with If your computer has never been set up, or you are making important changes...

  • Page 78: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to con- POST Screen duct a POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. 2.CPU type If there is a problem that prevents the system from booting, it will display a 3.Memory status...

  • Page 79: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 80: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and man- age basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5.1 is usually present for a...

  • Page 81: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When Setup menus you select a heading, a new screen appears. Scroll through the features listed shown in this section on each screen to make changes to Setup.

  • Page 82: Main Menu

    BIOS Utilities Main Menu PhoenixBIOS Setup Utility Figure 5 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:11:05] System Date: [09/22/2004] <Tab>, <Shift Tab>, or <Enter> selects field. IDE Channel 0 Master [20004MB] IDE Channel 0 Slave [CD-ROM] SATA Port 1...

  • Page 83: Ide Channel 0 Master/Slave (Main Menu)

    BIOS Utilities IDE Channel 0 Master/Slave (Main Menu) Pressing Enter under opens the sub-menu to show the configuration of the ei- ther a CD Device or HDD that on the computer’s IDE Channels 0 or 1. Use the Auto (Type:) setting to have the items configured automatically for you. SATA Port 1 (Main Menu) Pressing Enter under opens the sub-menu to show the configuration of the SATA Port 1.

  • Page 84: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Power Boot Exit Item Specific Help Advanced Chipset Control Select options for Advanced Chipset National 383 SIO Control Sub-Menu features. Legacy USB Support: [Enabled] Boot-time Diagnostic Screen: [Enabled]...

  • Page 85: National 383 Sio Control Sub-Menu (Advanced Menu)

    BIOS Utilities National 383 SIO Control Sub-Menu (Advanced Menu) Pressing Enter here will provide a sub-menu that controls the configuration of various National 383 SIO devices. Legacy USB Support (Advanced Menu) Use this menu item to enable/disable the support for Legacy Universal Serial Bus.

  • Page 86: Security Menu

    BIOS Utilities Security Menu Figure 5 - 4 PhoenixBIOS Setup Utility Security Menu Main Advanced Security Security Boot Exit Item Specific Help Supervisor Password Is: Clear Set Supervisor Password [E E nter] Supervisor Password Password on boot: [Disabled] controls access to the setup utility.

  • Page 87: Password On Boot: (Security Menu)

    BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password (supervisor or user password) should be entered to boot the computer. If “Enabled” is selected, only users who enter a Password Warning correct password can boot the system (see the warning in the sidebar). The default setting is “Disabled”.

  • Page 88: Boot Menu

    BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 5 - 5 Main Advanced Security Exit Boot Boot Menu Item Specific Help Boot priority order: IDE 0: FUJITSU MHT2020AT-(PM) Keys used to view or IDE 1: TSSTcorpCD/DVDW TS-L532A configure devices: Up and Down arrows IDE 2: select a device.
  • Page 89 BIOS Utilities Boot devices usually are hard drives, floppy drives, and CD-ROMs/DVD- ROMs and Networks (LANs). When you specify a device as a boot device on the Boot Menu, it requires the availability of an operating system on that device. Most home computers come with an operating system already installed on “Drive C:”.

  • Page 90: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 PhoenixBIOS Setup Utility Exit Menu Main Advanced Security Boot Exit Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...

  • Page 91: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the Warranty Warning steps outlined to make the desired upgrades. If you have any trouble or prob- lems you can contact your service representative for further help. Before you Please check with your begin you will need: service representative...

  • Page 92: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake any upgrade proce- • Your system is still under warranty or a service contract dures, make sure that you have turned off the •...

  • Page 93: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety Warranty Warning reasons it is best to remove the battery. Please check with your Turn the computer off, and turn it over. service representative Slide the latch in the direction of the arrow.

  • Page 94: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) HDD System or parallel (PATA) hard disk drives with a height of 9.5mm (h) (see “Storage” Warning on page D - 4).
  • Page 95 Upgrading The Computer Turn off the computer, and turn it over and remove the battery. Locate the hard disk/memory bay cover and remove screws Remove the bay cover Figure 6 - 3 HDD/RAM Bay Cover Removal Upgrading the Hard Disk Drive 6 - 5...
  • Page 96 Upgrading The Computer Pull the tab in the direction of the arrow in order to release the disk assembly from the connector. Lift the hard disk assembly up out off the computer. Remove screws from points on the side of the hard disk assembly in order to separate the bracket from the hard disk Reverse the process to install a new hard disk(s).

  • Page 97: Changing Serial And Parallel Hard Disk Cables

    Upgrading The Computer Changing Serial and Parallel Hard Disk Cables The system can support either serial (SATA) OR parallel (PATA) hard disks, however different cables are used to support each hard disk type. If you are HDD Cable changing hard disk types then you will be required to change the cable. You will need to bend Remove the hard disk assembly (see page the cable back and en-...

  • Page 98: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line RAM Modules (SO-DIMM) DDR, OR DDRII (DDR2) type memory modules (see “Memo- Supported ry” on page D - 3 for details of supported module types).
  • Page 99 Upgrading The Computer Turn off the computer, and turn it over and remove the battery. Locate the hard disk/memory bay cover and remove screws Remove the bay cover Figure 6 - 6 HDD/RAM Bay Cover Removal Upgrading the System Memory (RAM) 6 - 9...
  • Page 100 Upgrading The Computer Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the arrows in Figure 6 - Contact Warning Be careful not to touch the metal pins on the module’s connecting edge.

  • Page 101: Upgrading The Optical (Cd/Dvd) Device

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Locate the hard disk/memory bay cover and remove screws Remove the bay cover Use a screwdriver to carefully push the optical device out of the computer at point Figure 6 - 8...

  • Page 102: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with Warranty a faster/new one you will need to contact your customer service representa- tive. We recommend that you do not do this yourself, since if it is done incor- The CPU is not a user serviceable part.

  • Page 103: Modules

    Modules Chapter 7: Modules Overview This chapter contains the information on the WLAN, Bluetooth, and PC Camera modules which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service repre- sentative. The chapter includes information on the following: •...

  • Page 104: Intel Pro/Wireless Mini-Pci Wlan Module

    Modules Intel PRO/Wireless Mini-PCI WLAN Module Either an Intel PRO/Wireless 2200BG (802.11b/g) or 2915ABG (802.11a/ Wireless Device b/g) Mini-PCI WLAN module is supplied as a standard feature for the com- Operation Aboard puter. You will have the appropriate software CD provided for your module. Aircraft The use of any portable Before installing the Intel PRO/Wireless 2200BG or 2915ABG Mini-PCI...

  • Page 105: Intel Pro/Wireless 2200Bg Wlan Driver Installation

    Modules Intel PRO/Wireless 2200BG WLAN Driver Installation 1. Make sure the module is powered on, then insert the Intel PROSet/ Wireless CD-ROM into the CD drive. 2. Click Install Software (button). 3. Click the button to accept the license and click Next > Next > OK. 4.

  • Page 106: Intel Pro/Wireless 2915Abg Wlan Driver Installation

    Modules Intel PRO/Wireless 2915ABG WLAN Driver Installation 1. Make sure the module is powered on, then insert the Intel PROSet/ Wireless CD-ROM into the CD drive. 2. Click Install Software (button). 3. Click the button to accept the license and click Next > Next > OK. 4.

  • Page 107: Bluetooth Module

    Modules Bluetooth Module Before installing the Bluetooth driver, make sure that the optional Bluetooth Wireless Device module is on. Use the Bluetooth AP-Key button to toggle power to the Operation Aboard Bluetooth module . Make sure you install the drivers in the order indicated in Aircraft Table 4 - 1, on page 4 - The use of any portable...
  • Page 108 Modules Figure 7 - 2 Bluetooth Control Panels/ Help 7 - 6 Bluetooth Module...

  • Page 109: Pc Camera

    Modules PC Camera If you have purchased the optional PC Camera you will need to install the de- Taking Still vice driver for it as indicated on the following pages (make sure you install Pictures the drivers in the order indicated in Table 4 - 1, on page 4 - 6).

  • Page 110: Pc Camera Driver Installation

    Modules PC Camera Driver Installation 1. Insert the PC Camera CD-ROM into the drive. 2. Click Next. 3. Click Finish to restart the computer. 4. After restart the computer will find the new hardware for you. 5. Run the AMCAP program from the CMM PC Camera item in the Start >...
  • Page 111 Modules Figure 7 - 3 Audio Setup PC Camera 7 - 9...

  • Page 112: Amcap

    Modules AMCAP AMCAP is a video viewer useful for general purpose video viewing and test- ing, and can capture video files to .avi format. Pre-Allocating File Space Run the AMCAP program from the Start > Programs/All Programs > CMM You may pre-allocate PC Camera menu (it is recommended that you set the capture file before the file size for the cap- the capture process - see Set Capture File below).
  • Page 113 Modules Eliminating Screen Flicker If you find that the video screen in the AMCAP program is flickering, you can try to adjust the option from the Video Capture Filter options. Run the AMCAP program from the Start > Programs/All Programs > CMM PC Camera menu.
  • Page 114 Modules 7 - 12...

  • Page 115: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 116: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 117: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wallet.

  • Page 118: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 119: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 120 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 121: Power

    Troubleshooting Power Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is but it doesn’t work. present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 122 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If hot. this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...

  • Page 123: Display

    Troubleshooting Display Problem Possible Cause - Solution Nothing appears The system is in a power saving mode. Toggle the sleep/resume key combination, Fn + screen. Esc (see “Sleep Button” on page 3 - The screen controls need to be adjusted. Toggle the screen control key combinations Fn + F8/F9.

  • Page 124: Boot Password

    Troubleshooting Boot Password Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact password. your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.

  • Page 125: Audio & Cd Device

    Troubleshooting Audio & CD Device Problem Possible Cause - Solution The sound cannot be The volume might be set too low. Check the volume control in the Volume Control Panel heard or the volume is in the Windows taskbar, or use the key combination Fn + F5 and F6 (see “Audio very low.

  • Page 126: Keyboard

    Troubleshooting Keyboard Problem Possible Cause - Solution Unwelcome numbers If the LED is lit, then Num Lock is turned ON. (see “LED Indicators” on page 1 - appear when typing. Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically.

  • Page 127: Operation

    Troubleshooting Operation Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC adapter, press a key on the screen goes dark. the keyboard, or press the sleep (Fn + Esc) key combination, or press the power button if no LEDs are lit.

  • Page 128: Modules

    Troubleshooting Modules Problem Possible Cause - Solution Wireless LAN/ The modules are off. Check the LED indicators to see if the modules are on or off (see Bluetooth/ PC Camera “LED Indicators” on page 1 - 7). If the LED indicator is off, then press the AP-Key modules cannot combination in order to enable the modules (see...

  • Page 129: Interface (Ports & Jacks)

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your com- puter to communicate with external devices, connect to the internet etc. Interface (Ports &...

  • Page 130: Ports And Jacks

    Interface (Ports & Jacks) Ports and Jacks Item Description Built-In Microphone The built-in microphone allows you to record on your computer Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device.

  • Page 131: Microphone-In Jack

    Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. Mini-IEEE 1394 Port This port allows a high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). Mini-IEEE 1394 Port The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.

  • Page 132: Security Lock Slot

    Interface (Ports & Jacks) Item Description Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Jack allows you to connect your DVD-capable PC to a Dolby AC-3 compatible receiver for “5.1”...

  • Page 133: Ati Video Driver Controls

    ATI Video Driver Controls Appendix B: ATI Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - ATI Video Driver Installation Make sure you install the drivers in the order indicated in Table 4 - 1 on page 4 - 6.

  • Page 134: Ati Mobility Radeon Properties

    ATI Video Driver Controls ATI Mobility Radeon Properties More advanced video configuration options are provided in the ATI Mobility ATI Taskbar Icon Radeon X700 control panel tab: You can also access Open the Display Properties (see “Video Features” on page 1 - 15) con- ATI Mobility Radeon trol panel.
  • Page 135 ATI Video Driver Controls Figure B - 2 ATI Mobility Radeon X700 Properties Tabs Help Menus Right-click on almost any item in the tabs to bring up the “What’s This?” button. Click to Configure Theater Mode Help Menu Click “What’s This?”...

  • Page 136: Display Devices

    ATI Video Driver Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel dis- play or TV as your display device. The following are the display options: Theater Mode Theater Mode can be The built-in LCD. enabled clicking An external monitor connected to the external monitor port.

  • Page 137: Attaching Other Displays

    ATI Video Driver Controls Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the external Function Key port on the left of the computer. monitor Combination Attach your external monitor to the external monitor port (or TV to the S- You can use the Fn + Video-Out Port), and turn it on.

  • Page 138: Display Modes

    ATI Video Driver Controls Display Modes Single Primary & Clone Only one of your attached displays is used. Displays Multiple - Clone Mode The Primary display in an Extended Desktop Clone Mode simply shows an exact copy of the Primary display desktop on environment will be as- the other display(s).

  • Page 139: Clone Mode

    ATI Video Driver Controls Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same con- Display Data Channel tent. Use this feature to display the screen through a projector for a presenta- Information tion.

  • Page 140: Extended Desktop Mode

    ATI Video Driver Controls Extended Desktop Mode The system supports Extended Desktop in multiple display environments in WindowsXP. An Extended Desktop creates a desktop spanning multiple dis- plays and acts as a large workspace. To get this effect: Attach your external monitor to the external monitor port (or TV to the S- Video-Out Port), and turn it on.
  • Page 141 ATI Video Driver Controls 10. In the example shown in Figure B - 5 the primary monitor is on the left, the other display is on the right. Help Click either the Display pop- Further help is avail- up menu, or click the icon for able through the appropriate display.
  • Page 142 ATI Video Driver Controls 12. One display will be set to 1 (Primary). The displays may be switched as long as one as set to Primary. Figure B - 6 Displays Tab In this picture the notebook (Extended Desktop LCD panel is the primary dis- Mode) play, and the desktop may be extended to any attached dis-...

  • Page 143: Enabling Tv Display

    ATI Video Driver Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an S-Video cable from the TV to the S-Video-Out Port on the left side of the computer (see “System Map: Left View”...
  • Page 144 ATI Video Driver Controls B - 12...

  • Page 145: Intel Video Driver Controls

    Intel Video Driver Controls Appendix C: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Intel Video Driver Installation Make sure you install the drivers in the order indicated in Table 4 - 1 on page 4 - 6.

  • Page 146: Dynamic Video Memory Technology

    Intel Video Driver Controls Dynamic Video Memory Technology ® Intel DVMT automatically and dynamically allocates as much (up to DVMT Notes 224MB) system memory (RAM) as needed to the video system (the video driver must be installed - see page 1).

  • Page 147: Intel Graphics Properties

    Intel Video Driver Controls Intel Graphics Properties More advanced video configuration options are provided by the Intel(R) Taskbar Icon Graphics Media Accelerator Driver. You can also access Open Display Properties (see “Video Features” on page 1 - 15). the controller proper- Click the Intel(R)...
  • Page 148 Intel Video Driver Controls You may make changes to the Devices, Color, Schemes, Hot Keys by clicking the appropriate tab and adjusting the setting, then clicking OK. The Informa- tion and Open GL tabs display useful information about the graphics proper- Intel Graphics ties of the computer, and the Support item in the Information tab has weblinks Properties...

  • Page 149: Schemes

    Intel Video Driver Controls Schemes Use Schemes to configure quick settings for applications which require spe- cific resolution and color settings in order to run properly e.g. games, multi- Application.exe media programs. To set the schemes: You will need to locate the actual application Go to the Graphics Properties control panel (see “Intel Graphics Proper-...

  • Page 150: Display Devices

    Intel Video Driver Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel dis- Function Key play or TV as your display device. The following are the display options: Combination You can use the Fn + The built-in LCD.

  • Page 151: Attaching Other Displays

    Intel Video Driver Controls Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the external Function Key monitor port on the left of the computer. Combination Attach your external monitor to the external monitor port (or TV to the S- You can use the Fn + Video-Out Port), and turn it on.

  • Page 152: Display Modes

    Intel Video Driver Controls Display Modes Single Display Function Key Combination Only one of your attached displays is used. You can use the Fn + Intel(R) Dual Display Clone F7 key combination to toggle through the dis- This mode will drive multiple displays with the same content. Each device play options: may be configured independently for different resolutions, refresh rates, color quality etc.
  • Page 153 Intel Video Driver Controls To Enable Intel(R) Dual Display Clone Mode Attach your external monitor to the external monitor port (or TV to the S- Video-Out Port), and turn it on. Go to the Graphics Properties control panel (see “Intel Graphics Properties”...
  • Page 154 Intel Video Driver Controls To Enable Extended Desktop Mode: Attach your external monitor to the external monitor port (or TV to the S- Video-Out Port), and turn it on. Display Settings Go to the Graphics Properties control panel (see “Intel Graphics Extended Desktop Properties”...
  • Page 155 Intel Video Driver Controls To Enable Extended Desktop (Display Properties) Attach your external monitor to the external monitor port (or TV to the S- Video-Out Port), and turn it on. Display Settings Click Start, point to Settings (or click Control Panel) and click Control Extended Desktop Panel (if you are in Category View choose Appearance and Themes).

  • Page 156: Tv Settings

    Intel Video Driver Controls TV Settings If you are using a TV as a display device you may adjust the settings as fol- Function Key lows: Combination Attach your TV to the S-Video-Out Port and turn it on. You can use the Fn + Go to the Graphics Properties control panel (see “Intel Graphics F7 key combination to...

  • Page 157: Specifications

    Specifications Appendix D: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly proces- sor types/speeds and CD/DVD device types) may be changed or updated due to the manufacturer's release sched- ule.

  • Page 158: Processor

    Specifications Feature Specification µ Processor Intel Pentium® M Processor 0.09) 0.09 Micron Process Technology (478-pin) Micro-FC-PGA Package 2MB On-die L2 Cache & 533MHz FSB Models 730/ 740/ 750/ 760/ 770 1.6/ 1.73/ 1.86/ 2/ 2.13 GHz µ Intel Pentium® M Processor 0.13) 0.13 Micron Process Technology (478-pin) Micro-FCPGA Package 1MB On-die L2 Cache &...

  • Page 159: Memory

    Specifications Feature Specification Memory Models A & C: Models B & D: Two SO-DIMM Sockets Supporting DDR Two SO-DIMM Sockets Supporting DDRII Memory (DDR2) Memory Single Channel Dual Channel Speed up to 333 MHz Speed up to 533 MHz (Note: Do Not Use Other Module Types) (Note: Do Not Use Other Module Types) Memory Expandable up to 2GB (128/ 256/ Memory Expandable up to 2GB (128/ 256/...

  • Page 160: Video Adapter

    Specifications Feature Specification Video Adapter Models A & B: Models C & D: ATI M26(X700) PCI-E 16X Intel® Graphics Media Accelerator 900 (Intel® 128MB/256MB(M26) DDR-DRAM GMA 900) Pure Hardware DirectX 9 Dynamic Video Memory Technology DVMT 128-bit Memory Interface 3.0 - Supports up to 224MB of Video Memory (dynamically allocated from system memory where needed) Supports Dual Independent Displays...

  • Page 161: Pcmcia

    Specifications Feature Specification PCMCIA One Type-II PCMCIA CardBus PC Card Slot Interface Four USB 2.0 Ports One Headphone-Out Jack One Mini-IEEE 1394 Port One Microphone-In Jack One External Monitor Port One Line-In Jack One Parallel Port (LPT1) Supporting ECP/EPP One RJ-11 Jack for Plug & Play Fax/Modem One S/PDIF Output Jack One RJ-45 Jack for 10M/100M/1000M Fast One S-Video-Out Port...

  • Page 162: Power

    Specifications Feature Specification Power Models A & B - AC Adapter: Models C & D - AC Adapter: Full Range AC Adapter 90 W 100~240V, Full Range AC Adapter 65 W 100~240V, 47~63Hz 47~63Hz 6 Cell Smart Lithium-Ion Battery Pack, 4.4AH 12 Cell Smart Lithium-Ion Battery Pack, 6.6AH (Optional) Environmental Temperature...

Table of Contents
