Introduction

External Locator - Top View with LCD Panel Open

Figure 1
Top View
1. Optional Built-In
PC Camera
2. LCD
3. Power Button
4. Hot Key Buttons
5. Keyboard
6. Built-In
Microphone
7. Touchpad &
Buttons
8. Fingerprint*
(Optional)
9. LED Indicators
*Note: This model may have
either a fingerprint module or
card reader module, depend-
ing on the purchase configura-
tion.
1 - 4 External Locator - Top View with LCD Panel Open
1
2
4
5
6
7
8
9
M770CU/M775CU
2
3
4
5
7
9
W760CU/W765CU
1
3
6
