EUROCOM M190S World Warrior User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M190S World Warrior and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EUROCOM M190S World Warrior

Summary of Contents for EUROCOM M190S World Warrior

  • Page 2: Trademarks

    Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Infor- mation contained herein is for reference only and does not constitute a commitment on the part of the man- ufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 3: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Do not use this product near water, for example near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 5: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
  • Page 6 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 7: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifi- Power Safety cations, consult your service representative or local power company.

  • Page 8: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the com- puter. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.

  • Page 9: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 10: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 11 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshoot- ing, keep these points in mind: Hand-carry the notebook: For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 12 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 13 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 14: Table Of Contents

    Preface Contents Top View ............1-6 Front View ............1-7 Trademarks ............I LCD Panel ............1-8 FCC Statement ..........II LED Status Indicators ........1-8 Instructions for Care and Operation ....IV Close Cover Switch ........1-8 Power Safety ............ VI Power Button ..........
  • Page 15 Preface PC Card Slot ..........1-14 The CD Device ............2-12 Right Side View ..........1-15 Loading Discs ..........2-12 Hard Disk Drive ...........1-16 Handling CDs or DVDs ........2-13 Dual USB 2.0 Ports ........1-16 DVD Regional Codes ........2-14 RJ-11 Phone Jack .........1-17 Changing the DVD Regional Codes ....
  • Page 16 Preface Opening the LCD ..........3-2 New Battery ..........3-24 Video Driver Controls ..........3-3 Battery Life ..........3-24 Making Adjustments for the Display ....3-3 Battery FAQ ............. 3-25 Display Properties ..........3-4 Conserving Battery Power ....... 3-25 SiS Utility Tray/Manager ........3-5 Removing and Replacing the Battery ....3-26 Video Memory ............3-7 Installing the CDMA or GPRS SIM Card .....
  • Page 17 Preface Video (WinXP) ..........4-10 Setting up a New HDD ........6-4 TouchPad (WinXP) ..........4-11 Upgrading the System Memory ....... 6-5 Hot-Key (WinXP) ..........4-11 Upgrading the Memory in Socket 2 ....6-6 BIOS Utilities .......5-1 Upgrading the Processor .......... 6-8 Troubleshooting ......7-1 Overview ..............5-1 Important BIOS Settings ..........5-2 Basic Hints and Tips ..........

  • Page 18: Introduction

    Introduction Chapter 1: Introduction Overview Notes This manual refers to the hardware and essential software required to run your Check the light colored notebook computer. Depending on how your system is configured, some or all boxes with the mark of the features described may already be set up. What this chapter covers: above to find detailed information about the •...

  • Page 19: Warning Boxes

    Introduction Warning Boxes No matter what your level please pay careful attention to the warning and safe- ty information indicated by the symbol. Also please note the safety and handling instructions as indicated in the Preface . Not Included Operating Systems (e.g. Windows 2000 Professional, Windows XP etc.) have their own manuals, as do applications (e.g.

  • Page 20: Quick Start Guide

    Introduction Quick Start Guide This guide assumes that you are already familiar with computers and can tell at a glance what and where all the key components are. If you are not that com- Peripheral Devices fortable with this type of device, then please refer to the following pages, Please note that pe- which give an overview of the system.

  • Page 21: Cdma Or Gprs Modem Operation

    Introduction CDMA or GPRS Modem Operation If you have purchased the optional internal CDMA OR GPRS modem mod- ule, full instructions for use are available in the manual that accompanies the Modem Operation module. Aboard Aircraft The use of any porta- CDMA ble electronic trans- For most CDMA services you will need to install the CDMA Application,...

  • Page 22: System Map

    Introduction System Map Your notebook PC has a lot of built-in features. Most of these are enabled by your operating system. Further explanations of the various subsystems are covered in the chapter or pages indicated. Getting to Know Your Computer The following pages will help you to become familiar with the basic functions, and to learn the location of the various ports and components of your compu- ter.

  • Page 23: Top View

    Introduction Top View To open the LCD panel: Place the computer on a stable surface. Move the cover latch to the right to release the top cover. Lift the top cover to reveal the LCD panel and keyboard. Adjust the LCD panel to a comfortable viewing angle. If you have the optional CDMA/GPRS modem module, you can extend the phone antenna to use this function to access the internet etc.

  • Page 24: Front View

    Introduction Front View Figure 1 - 2 Front View 1. LCD Panel 2. LED Status Indicators 3. Close Cover Switch 4. Power Button 5. Built-In Microphone 6. Keyboard 7. Speakers 8. Hot-Key Buttons 9. TouchPad & Buttons 10. LED Power & Communication Indicators 11.

  • Page 25: Lcd Panel

    Introduction LCD Panel “LCD” on page A - 1 for details on the LCD options for this computer. LED Status Indicators “LED Status Indicators” on page 2 - 7 Refer to for more information. Close Cover Switch This switch acts as a sensor to tell when the LCD panel is closed. When this LCD cover sensor is activated, the default setting of your operating system’s Figure 3 - power scheme sends the computer into a power saving state (see...

  • Page 26: Power Button

    Introduction Power Button Press this button to turn your computer On or Off (see “Turning on the Com- puter” on page 2 - 5). This button may be configured to be used as a sleep/ resume key in the power management control panel of your operating system “Configuring the Power Button”...

  • Page 27: Speakers

    Introduction Speakers Two built-in speakers provide rich, stereo sound. Hot-Keys “Programming the Hot-Keys” on To learn how to set the hot-keys see page 2 - 17 TouchPad & Buttons The pointing device features a sensitive glide pad for precise movements, and “TouchPad and But- functions in the same way as a two-button mouse (see tons/Mouse”...

  • Page 28: Microphone-In Jack

    Introduction Microphone-In Jack Plug an external microphone in to this port to record on your notebook com- puter. Headphone-In Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack.

  • Page 29: Left Side View

    Introduction Left Side View Figure 1 - 3 Left Side View 1. Antenna (raised) 2. External Monitor (CRT) Port 3. DC-In Jack 4. PS/2 Type Port 5. Telephone Headset Jack 6. External IDE Device Port 7. Mini IEEE 1394 Port 8.

  • Page 30: Antenna

    Introduction Antenna Raise the antenna when using the optional CDMA or GPRS modem. External Monitor Port Connect an external monitor to this port to allow dual video or simultaneous “Multimonitor” on page 3 display on the LCD and the external monitor (see - 12 DC-In Jack Plug the supplied AC adapter into this jack to power your notebook.

  • Page 31: Mini - Ieee 1394 Port

    Introduction Mini - IEEE 1394 Port This port allows high-speed connection to various peripheral devices, e.g. ex- ternal disk drives and digital cameras (see note below). IEEE 1394 The IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. PC Card Slot This is a Type-II (PCI) PC Card slot (also previously referred to as PCMCIA).

  • Page 32: Right Side View

    Introduction Right Side View Figure 1 - 4 Right Side View 1. Hard Disk Bay 2. Dual USB 2.0 Ports 3. Vent 4. Phone & LAN Jacks Overheating To prevent your computer from overheating make sure nothing blocks the vent/fan outlets while the computer is in use.

  • Page 33: Hard Disk Drive

    Introduction Hard Disk Drive “Upgrading the Hard Disk Drive” on page 6 - 3 Please see for information on upgrading/replacing your hard disk drive. Drive Warning Don’t try to remove the hard disk (HDD) while the system is on. This could cause data loss or damage.

  • Page 34: Rj-11 Phone Jack

    Introduction RJ-11 Phone Jack This port connects to the built-in modem (not the optional CDMA or GPRS modem module which is wireless and does not need a telephone line). You may plug the telephone line directly into this RJ-11 telephone connection. Note: Broadband (e.g.

  • Page 35: Rear & Bottom Views

    Introduction Rear & Bottom Views Figure 1 - 5 Rear View 1. Security Lock Security Lock To prevent possible theft a Kensington-type lock can be attached to this slot. Figure 1 - 6 Locks can be purchased at any computer store. Bottom View 1.

  • Page 36: Using The Computer

    Using The Computer Chapter 2: Using The Computer Overview Your notebook computer can be used almost anywhere, in the home, office, or on the road. To learn more about your computer, please read this chapter. This chapter includes: • The Power Sources •...

  • Page 37: The Power Sources

    Using The Computer The Power Sources Either an AC adapter or a battery pack can power the computer. The Power Button as AC Adapter a Standby or Hibernate Button Only use the AC adapter supplied with your computer. The wrong type of AC adapter will damage the computer and its components.

  • Page 38: Battery

    Using The Computer Battery The battery allows you to use your notebook computer while you are on the road, or an electrical outlet is unavailable. Battery life varies depending on the applications and the configuration you're using. To increase battery life, let the battery discharge completely before recharging.

  • Page 39: Recharging Battery With The Ac Adapter

    Using The Computer Recharging Battery with the AC Adapter The battery pack automatically recharges when the AC adapter is attached and plugged into an electrical outlet. If the computer is powered on, and in use, it will take several hours to fully recharge the battery. When the computer is turned off but plugged into an electrical outlet, battery charge time is reduced (refer to “LED Power &...

  • Page 40: Turning On The Computer

    Using The Computer Turning on the Computer Now you are ready to begin using your notebook computer. To turn it on sim- ply press the power button on the top right of the front panel. Forced Off When the computer is turned on, the power button can also be used as a Stand- If the Ctrl + Alt + Del combination by/Hibernate/Shutdown hot-key button if pressed for less than 4 seconds...

  • Page 41: Led Indicators

    Using The Computer LED Indicators There are two sets of LED indicators (LED Status Indicators and LED Pow- er & Communication Indicators) on your computer. These display helpful information about the current status of the computer. Figure 2 - 3 LED Indicator Location 1.

  • Page 42: Led Status Indicators

    Using The Computer LED Status Indicators Icon Color Description Num Lock The external IDE device (floppy, CD, CD-RW, DVD For more information Green etc.) is being accessed on the number lock feature “The Function Keys and Green The Hard Drive is being accessed Numeric Keypad”...

  • Page 43: Led Power & Communication Indicators

    Using The Computer LED Power & Communication Indicators Table 2 - 2 Icon Color Description LED Power & Green The battery is fully charged Communication Indicators The battery is being charged Blinking Red Low battery warning Green The system power is on The system is in sleep mode (see Blinking Green “Configuring the Power Button”...

  • Page 44: The Hard Disk Drive (Hdd)

    Using The Computer The Hard Disk Drive (HDD) The hard disk drive is used to store your data in the notebook computer. It is mounted in a removable case and can be taken out to accommodate other 2.5" Power Safety IDE hard disk drives of 9.5mm height.

  • Page 45: The External Ide Device

    Using The Computer The External IDE Device The computer may come with an optional external IDE combination drive. It may contain one of the following combinations, depending on your purchase: CD-ROM & FDD DVD-ROM & FDD CD-RW & FDD CD-RW & CD-ROM CD-RW &...

  • Page 46: The Floppy Disk Drive (Fdd)

    Using The Computer The Floppy Disk Drive (FDD) A 1.44 MB, 3.5"floppy disk drive module may be part of your optional exter- nal IDE drive combination. By default it is drive "A:" and can be used as a Media Warning boot device if properly set in the BIOS.

  • Page 47: The Cd Device

    Using The Computer The CD Device Depending on the configuration purchased, your system may have one or more CD devices. If present in a standard configuration, one will appear as Sound Volume drive "D:". If there is a second drive it will be drive "E:". Adjustment You may set the vol- Loading Discs...

  • Page 48: Handling Cds Or Dvds

    Using The Computer Handling CDs or DVDs Proper handling of your discs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CD-ROMs CD Emergency Eject / DVD-ROMs can be accessed. If you need to manually Remember to: eject a CD (e.g.

  • Page 49: Dvd Regional Codes

    Using The Computer DVD Regional Codes DVD region detection is device dependent, not OS dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This can- not be altered even if you change your operating system or you use the module in another computer.

  • Page 50: Changing The Dvd Regional Codes

    Using The Computer Changing the DVD Regional Codes Go to the Control Panel in Windows XP/2000 and double-click System, click Device Manager (Hardware tab), then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties menu, and select the DVD Region (tab) to bring up the control panel as seen “DVD Regional Codes (Windows XP)”...

  • Page 51: The Pc Card Slot

    Using The Computer The PC Card Slot The computer is equipped with a type II (PCI) PCMCIA 3.3V/5V socket. Inserting and Removing PC Cards • Align the PC Card with the slot and push the card in until it locks into place.

  • Page 52: Hot-Keys

    Using The Computer Hot-Keys The computer has three Hot-Key buttons for quick one button access to e-mail , the Internet or a user-defined application . To use the “user-de- Non-Default E-Mail fined Hot-Key”, you must install the Hot-Key driver. Refer to “Install Proce- and Browser Programs...
  • Page 53 Using The Computer To configure and specify an application for Application 1 (the default Hot- Key setting is for the CD Player application), you must follow the instruc- tions below. Application.exe Right-click the Hot-Key icon on the taskbar and the following menu will You will need to locate appear.

  • Page 54: The Function Keys And Numeric Keypad

    Using The Computer The Function Keys and Numeric Keypad Function Keys On the bottom-left of the keyboard is the Fn key, or Function key. The Fn key Other Keyboards allows you to change some of the operational features of your computer in- If your keyboard is stantly.
  • Page 55 Using The Computer Table 2 - 5 Keys Description Function Keys Fn+Esc Sleep/Resume Toggle Fn+F2 Mute Toggle Fn+F3 Brightness Down Special Characters Fn+F4 Brightness Up Some software appli- Fn+F6 Display Toggle cations allow number-keys Fn+F7 Volume Down used with Alt to pro- Fn+F8 Volume Up duce special charac-...

  • Page 56: Function Keys And Numeric Keypad

    Using The Computer Function Keys and Numeric Keypad Figure 2 - 7 Function Keys Figure 2 - 8 Numeric Keypad The Function Keys and Numeric Keypad 2 - 21...

  • Page 57: Touchpad And Buttons/Mouse

    Using The Computer TouchPad and Buttons/Mouse The pointing device features a sensitive glide pad for precise movements. It functions the same way as a two-button mouse (the central Rocker Switch Mouse Driver may be configured as a “third” button if you prefer). The right TouchPad but- If you are using an ex- ton is the same as the right mouse button;...

  • Page 58: Adding A Printer

    Using The Computer Adding a Printer The most commonly used peripheral is a printer. The following conventions will help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options. USB Printer Most new printers have a USB interface connection.

  • Page 59: Parallel Printer

    Using The Computer Parallel Printer This is still the most common type of printer. A Parallel to USB converter may be purchased at most computer stores. Install Instructions: Set up the printer according to its instructions (unpacking, paper tray, toner/ ink cartridge etc.).

  • Page 60: Advanced Controls

    Advanced Controls Chapter 3: Advanced Controls Overview This chapter covers: Drivers • Advanced video controls • Power and battery management features You are unable to use • Installing a SIM card most advanced con- trols until the neces- sary drivers utilities are properly in- stalled.

  • Page 61: Advanced Video Controls

    Advanced Controls Advanced Video Controls This section is about making adjustments for the LCD, and switching display devices. Protecting the LCD Do not allow any for- Opening the LCD eign objects (i.e. paper As you open the lid, adjust it so you can look at the screen straight on, without or plastic) to get be- tween the lid/LCD and any glare.

  • Page 62: Video Driver Controls

    Advanced Controls Video Driver Controls The video interface lets you change the screen resolution and color output to whatever is most comfortable/efficient for you. This is a matter of hardware, Screen Resolution/ video memory and the driver for your operating system. The driver interface Area Note shows the available options (see “LCD”...

  • Page 63: Display Properties

    Advanced Controls Display Properties Figure 3 - 2 Advanced Display Properties When the Display Properties control panel is open, click the Advanced (button) to bring up the options tabs. Clicking through these tabs allows you to make any video adjustments you require. 3 - 4 Video Driver Controls...

  • Page 64: Sis Utility Tray/Manager

    Advanced Controls SiS Utility Tray/Manager With the video driver installed additional control panels are available. To get to the control panels do the following: Click Start, point to Settings and click Control Panel (if you are in Cate- gory View choose Appearance and Themes). Double-click Display (icon).
  • Page 65 Advanced Controls You may make changes to the Driver Mode Settings, Video Settings, Gamma Correction Settings, and view General Information, by clicking the appropri- ate tab and adjusting the setting. Some screen examples are shown below. Figure 3 - 4 SiS Utility Tray/ Manager Setting Tabs 3 - 6 Video Driver Controls...

  • Page 66: Video Memory

    Advanced Controls Video Memory The computer does not have dedicated video memory. It makes use of a por- tion of system memory as video memory. By default, the video memory is set Video Memory Usage to 32MB. You may also set it to 16MB or 64MB (maximum) in the BIOS (see 3D Applications, such “Embedded Share Memory (Advanced Menu>Advanced Chipset Control)”...

  • Page 67: Display Devices And Options

    Advanced Controls Display Devices and Options Besides the built-in LCD you can also use an external monitor (connected to the external monitor port on the left of the computer) as your display device. Multiple Display The display options are as follows: Modes &...

  • Page 68: Switching/Enabling Displays (Keyboard)

    Advanced Controls Switching/Enabling Displays (Keyboard) To simply switch display devices, or enable other devices, with the Fn + Dis- play (F6) key combination toggle do the following: Plug the external monitor into the external monitor port on the left of the computer.

  • Page 69: Switching/Enabling Displays (Driver)

    Advanced Controls Switching/Enabling Displays (Driver) “What to Install” on page 4 - 2 With the video driver installed (see ), you also can use its built-in controls to switch between the displays as follows: Plug the external monitor into the external monitor (CRT) port on the left of the computer.

  • Page 70: Mirror Mode

    Advanced Controls Mirror Mode In this mode the display of the two devices is the same. Mirror mode simply shows an exact copy of the Primary display desktop on the Secondary dis- Switching Display play(s). This mode will drive multiple displays with the same content. Use this Modes feature to display the screen through a projector for a presentation etc.

  • Page 71: Multimonitor

    Advanced Controls Multimonitor This mode (not available in Windows 2000) allows a desktop to span the displays to act as a large work area to create a lot more screen area for dis- play. Figure 3 - 7 Multimonitor Setting Setting Multimonitor Mode 1.
  • Page 72 Advanced Controls Configuring Multimonitor Displays You can reconfigure the displays in Multimonitor mode from the Display Properties > Settings control panel (see “Display Properties” on page 3 - Make sure the “Extend my Windows desktop onto this monitor.” check box is checked (it will be checked as default when Multimonitor mode is set.

  • Page 73: Adjusting Monitor Settings

    Advanced Controls Adjusting Monitor Settings If you prefer to use an external monitor you may change its vertical refresh Vertical Refresh Rate rate, color depth and resolution. The vertical refresh rate In Multimonitor Mode of your VGA monitor is Follow the instructions in “Setting Multimonitor Mode”...
  • Page 74 Advanced Controls You may also adjust the refresh rate from the Display Properties control panel after Multimonitor mode has been enabled: Double-click on the VGA monitor icon (in the example below it is the icon as the external monitor is automatically set for Display_1). Click the Monitor tab, and then select the refresh rate.
  • Page 75 Advanced Controls In Mirror or Single Mode To change the refresh rate in Single or Mirror mode you will need to do the following: Setting Changes Follow the instructions in “Switching/Enabling Displays (Driver)” on Some setting changes page 3 - may require you to re- Choose the Mirror or Single option from the Driver mode drop box.
  • Page 76 Advanced Controls You can also adjust the refresh rate from the Display Properties control panel (click Advanced button and choose the Monitor tab): Once the VGA monitor is confirmed as the Primary device, close the Dis- play Properties control panel. Open the Display Properties >...

  • Page 77: Power Management Features

    Advanced Controls Power Management Features To conserve power, especially when using the battery, your notebook comput- er uses ACPI (Advanced Configuration & Power Interface) power man- OS Note agement. Power management conserves power by controlling individual Power management components of the computer (the monitor and hard disk drive) or the whole functions will vary...

  • Page 78: Enabling Power Options

    Advanced Controls Enabling Power Options The Power Options are enabled through the control panel in your Windows system. With other operating systems you may also have some form of power management available, so check your documentation. Figure 3 - 13 Power Options Control Panel You may conserve power through individual components or throughout the...

  • Page 79: Conserving Power (Individual Components)

    Advanced Controls Conserving Power (Individual Components) Turn off Monitor Resuming Operation To conserve power, you can set the monitor to turn off after a specified time. system Turn off Hard Disks resume from Monitor or Hard Disk Standby The computer's hard disk motor will be turned off if the hard disk drive has by pressing a key on not been accessed for a specified period of time.

  • Page 80: Conserving Power (System)

    Advanced Controls Conserving Power (System) With this function you can stop the notebook’s operation and restart where you left off. This system features Standby and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hiber- Figure 3 - 15 on page 3-22 nate tab in the Power Options control panel - Hibernate Mode vs.

  • Page 81: Standby

    Advanced Controls Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU will System Resume stop. All open applications are retained in memory. When you are not using system your computer for a certain length of time, which you specify in the operating resume from Standby...

  • Page 82: Configuring The Power Button

    Advanced Controls Configuring the Power Button The power button may be set to send the computer in to either Standby or Hi- bernate modes (Figure 3 - 16). In Standby mode the LED will flash Sleep Button green, in Hibernate mode the LED will be off. If you are in a power saving mode set to save power through individual components (e.g.

  • Page 83: Battery Information

    Advanced Controls Battery Information Please follow these simple guidelines to get the best use out of your battery. Battery Caution New Battery Danger of explosion if Always completely discharge, then fully charge, a new battery before using it battery is incorrectly (see “Battery FAQ”...

  • Page 84: Battery Faq

    Advanced Controls Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Conserving Battery Don’t turn off the computer by yourself even when you see a message that in- Power dicates the battery is critically low, just let the computer use up all of the bat- To conserve battery...

  • Page 85: Removing And Replacing The Battery

    Advanced Controls Removing and Replacing the Battery Usually you will not need to remove your battery. If you follow the tips given to manage and extend your battery life on the preceding pages your battery should last a long time. However there may be times when you are required to remove, swap or replace the battery.

  • Page 86: Installing The Cdma Or Gprs Sim Card

    Advanced Controls Installing the CDMA or GPRS SIM Card If you have the optional CDMA or GPRS module in your computer you will be able to use the telephone functions. Firstly install your SIM card for your CDMA CDMA or GPRS RUIM service. For most CDMA ser- vices you do not Turn the computer off.
  • Page 87 Advanced Controls Figure 3 - 19 Figure 3 - 19 Slide the SIMLOCK forward ( A) and lift it up ( Figure 3 - 19 SIM Card Installation Figure 3 - 19 Insert the SIM card as illustrated in ( C) and close the SIMLOCK.
  • Page 88 Advanced Controls Figure 3 - 20 The card will only fit one way (note point Figure 3 - 20 SIMLOCK Closed Figure 3 - Close the SIMLOCK by pushing it in the direction of the arrow in Replace the SIM card cover and screw it back in place. Figure 3 - 21 10.
  • Page 89 Advanced Controls 12. Turn the Modem ON. Modem Operation Aboard Aircraft Turning the Modem OFF & ON The use of any porta- ble electronic trans- The default power state for the internal CDMA or GPRS modem is set to OFF. mission devices When your computer ‘Boots Up’...

  • Page 90: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities Overview This chapter deals with installing the drivers and utilities essential to the operation or improvement Assumption of some of the computer’s subsystems. The system We assume that you will install all drivers and utilities takes advantage of some newer hardware compo- from the built-in CD device and it is assigned to “Drive nents for which the latest versions of most available...

  • Page 91: What To Install

    Drivers & Utilities What to Install The Device Drivers & Utilities + User’s Manual CD-ROM contains the drivers and utilities neces- Navigate (Browse..) to D: “In- sary for the proper operation of the computer. You will notice that many of the instructions for driver stall Procedure”...

  • Page 92: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message Install Procedure If you receive a message stating that the driver you Table 4 - 1 - Install Procedure are installing is not authorized (Digital Signature Not Found), just click Yes (Continue Anyway) to Feature Win 2000 Win XP...

  • Page 93: Windows 2000 Professional

    Drivers & Utilities Windows 2000 Professional Audio (Win2000) This section covers driver and utility installation in- structions for Windows 2000 Professional (with 1. Click Start (menu) > Run ... Service Pack 3 installed). 2. Navigate (Browse..) to D:\DRIVERS\AUDIO\Setup.exe and click Open >...

  • Page 94: Modem (Win2000)

    Drivers & Utilities Modem (Win2000) 10.The modem is ready for dial-up configuration. 1. Click Start (menu), point to Settings and click Control Panel. Double-click System (icon) and then click Hardware (tab) > Device Man- Modem Country Selection ager (button). 2. Click “+” next to Other devices (if its sub- Be sure to check if the modem country selection is ap- items are not shown).

  • Page 95: Lan (Win2000)

    Drivers & Utilities LAN (Win2000) 11.The network adapter is ready for configuration. 1. Click Start (menu), point to Settings and click Video (Win2000) Control Panel. Double-click System (icon) and then click Hardware (tab) > Device Man- 1. Click Start (menu) > Run ... ager (button).

  • Page 96: Touchpad (Win2000)

    Drivers & Utilities TouchPad (Win2000) Hot-Key (Win2000) 1. Click Start (menu) > Run ... 1. Click Start (menu) > Run ... 2. Navigate (Browse..) to 2. Navigate (Browse..) to D:\DRIVERS\TOUCHPAD\WIN2000\Setup. D:\DRIVERS\HOTKEY\CNK001.exe and exe and click Open > OK. click Open > OK. 3.

  • Page 97: Windows Xp

    Drivers & Utilities Windows XP click Control Panel then double-click the Sounds & Audio Devices icon). Note: If you do not see Settings, just click Con- This section covers driver and utility installation in- trol Panel. If you are in the Category structions for Windows XP.

  • Page 98: Modem (Winxp)

    Drivers & Utilities Modem (WinXP) 8. Navigate (Browse...) to D:\DRIVERS\MODEM\WinXP and click 1. If you can see the My Computer icon on your OK (button), then click Next (click Continue desktop (if you cannot see the My Computer Anyway if asked if you want to continue at any icon go to step 2)click on it once to select it, time).

  • Page 99: Lan (Winxp)

    Drivers & Utilities LAN (WinXP) 9. Navigate (Browse...) to D:\DRIVERS\LAN\WINXP and click OK 1. If you can see the My Computer icon on your (button), then click Next. desktop (if you cannot see the My Computer 10.Click Finish and close the open windows. icon go to step 2)click on it once to select it, 11.The network adapter is ready for configuration.

  • Page 100: Touchpad (Winxp)

    Drivers & Utilities TouchPad (WinXP) Hot-Key (WinXP) 1. Click Start (menu) > Run ... 1. Click Start (menu) > Run ... 2. Navigate (Browse..) to 2. Navigate (Browse..) to D:\Drivers\TOUCHPAD\WINXP\Setup.exe D:\Drivers\HOTKEY\CNK001.exe and click and click Open > OK. Open > OK. 3.
  • Page 101 Drivers & Utilities 4 - 12 Windows XP...

  • Page 102: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: the POST (Power-On Self Test) malfunction. To correct mistakes, return Configuration: the Setup utility Setup and restore the Setup Defaults with <F9>.

  • Page 103: Important Bios Settings

    BIOS Utilities Important BIOS Settings Generally speaking you should not have to adjust any of the BIOS settings as they will already be set for your computer. However the following is a quick reference to the most important settings you may need to change at some point.

  • Page 104: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to con- duct a POST, including a quick test of the on-board RAM. POST Screen As the POST proceeds, the computer will tell you if there is anything wrong. 1.BIOS information 2.CPU type If there is a problem that prevents the system from booting, it will display a...

  • Page 105: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. QuickBoot Mode choose Fatal Errors QuickBoot Mode (not These stop the boot process and usually indicate there is something seriously available for all mod- wrong with your system.

  • Page 106: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and man- age basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The Figure 5 - 1 prompt (“Press F2 to Enter Setup”) seen in is usually present...

  • Page 107: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When Setup menus you select a heading, a new screen appears. Scroll through the features listed shown in this section on each screen to make changes to Setup.

  • Page 108: Main Menu

    BIOS Utilities Main Menu Figure 5 - 2 PhoenixBIOS Setup Utility Main Menu Main Main Advanced Security Boot Exit Item Specific Help System Time: [22:01:05] System Date: [09/02/2002] <Tab>, <Shift Tab>, or Floppy Type: [Legacy Floppy] <Enter> selects field. Primary Master [FUJITSU MHR] Secondary Master [Samsung CD-RW/DVD-ROM-(SM)]...
  • Page 109 BIOS Utilities Floppy Type You may choose either Legacy Floppy (the floppy drive provided in the ex- ternal IDE drive combination option) or USB Floppy type. Make sure to choose the appropriate drive type as required. Primary Master (Main Menu) Pressing Enter under opens the sub-menu to show the configuration of the HDD that fits into the computer’s HDD bay.

  • Page 110: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Boot Exit Item Specific Help Setup Warning Setting itmes on this menu to incorrect values may cause your system to malfunction. Select the operating system installed on your system which you will use most...
  • Page 111 BIOS Utilities Installed O/S: (Advanced Menu) This item tells the computer what kind operating system you’re using. Embedded Share Memory (Advanced Menu>Advanced Chipset Control) This item tells the computer how much system memory can be shared to be- come available as video memory. By default, the video memory is set to 32MB.
  • Page 112 BIOS Utilities I/O Device Configuration (Advanced Menu) The sub-menus under this line include options to configure the Serial port A and Serial Port B (Infrared). These can be left to the default settings, how- ever you may wish to use certain devices that require settings to be adjusted accordingly.
  • Page 113 BIOS Utilities Mobile CPU SpeedStep (Advanced Menu) Speedstep technology automatically detects whether the notebook is running from AC power or battery power. When the notebook is using AC Power, the CPU will run at full speed. In battery mode the CPU will reduce its clock speed and core voltage.

  • Page 114: Security Menu

    BIOS Utilities Security Menu Figure 5 - 4 PhoenixBIOS Setup Utility Security Menu Main Advanced Security Security Boot Exit Item Specific Help Supervisor Password Is: Clear Supervisor Password Set Supervisor Password [E E nter] controls access to the setup utility. Password on boot: [Disabled] Help...
  • Page 115 BIOS Utilities Set Supervisor Password: (Security Menu) Set a password for access to the Setup utility (this will not affect access to the computer OS, only the Setup utility). Password Warning Password on boot: (Security Menu) If you choose to set a After setting the supervisor password, you can choose Enabled to set a pass- boot password, NEV- ER forget your pass-...

  • Page 116: Boot Menu

    BIOS Utilities Boot Menu Figure 5 - 5 PhoenixBIOS Setup Utility Boot Menu Main Advanced Security Boot Boot Exit Item Specific Help Removable Devices Keys used to view or CD-ROM Drive configure devices: Hard Drive <Enter> expands or collapses devices with Network Boot a + or - <Ctrl+Enter>...
  • Page 117 BIOS Utilities Boot devices usually are hard drives, floppy drives, CD-ROMs and network cards. When you specify a device as a boot device on the Boot Menu, it requires the availability of an operating system on that device. Most home computers come with an operating system already installed on hard-drive C: If you wish to boot from a CD-ROM you will need to add it to the boot order.

  • Page 118: Configuring The Network Boot Protocol

    BIOS Utilities Configuring the Network Boot Protocol The system supports booting from FDD, HDD, CD or LAN (network). To boot from a network, set Network Boot as the first item in the boot order. Fol- Enabling Network low the full instructions in the sidebar to configure the network boot protocol. Boot Go to the Boot Menu.

  • Page 119: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 7 PhoenixBIOS Setup Utility Exit Menu Exit Main Advanced Security Boot Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...

  • Page 120: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or prob- Warranty Warning lems you can contact your service representative for further help. Before you Please check with your begin you will need: service representative...

  • Page 121: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake any upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...

  • Page 122: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive is used to store your data internally in the notebook com- puter. It is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h) (see “Storage”...

  • Page 123: Setting Up A New Hdd

    Upgrading The Computer Place the HDD on a flat surface and remove screws , and gently ease off the connector Pay careful attention to the alignment of the connector pins, and the orientation of the hard disk, when you install the new/upgraded HDD. HDD System To install the new HDD just reverse this process.

  • Page 124: Upgrading The System Memory

    Upgrading The Computer Upgrading the System Memory The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting DDR 200/266MHz. The main Warranty Warning memory can be expanded up to 1024MB. The SO-DIMM modules supported Please check with your are 128Mb, 256Mb, and 512Mb.

  • Page 125: Upgrading The Memory In Socket 2

    Upgrading The Computer Upgrading the Memory in Socket 2 Turn off the computer. Turn the computer over. Remove screws & from the memory socket cover Carefully lift the memory socket cover up and set it aside. If there is a module currently installed which needs to be upgraded/replaced Figure 6 - 3 then remove it.
  • Page 126 Upgrading The Computer Figure 6 - Gently pull the two release latches ( & on the sides of the memory socket toward the front and rear of the computer. Contact Warning Be careful not to touch the metal pins on the module’s connecting edge.

  • Page 127: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a faster/new one you will need to contact your customer service representa- Warranty tive. We recommend that you do not do this yourself, since if it is done incor- The CPU is not a user rectly you may damage the processor or mainboard.

  • Page 128: Troubleshooting

    Troubleshooting Chapter 7: Troubleshooting Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 129: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 130: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g.

  • Page 131: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the Internet.

  • Page 132: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 133 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 134: Power

    Troubleshooting Power Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay; make sure the battery is but it doesn’t work. present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 135 Troubleshooting Problem Possible Cause - Solution A beeping sound is heard The battery power is nearly used up. Connect the AC adapter to your computer. and the low-battery indicator is on. A beep isn’t heard when The battery power is nearly used up and the volume control may be turned down. Adjust the low-battery indicator the volume control and connect the computer with the AC adapter.

  • Page 136: Display

    Troubleshooting Display Problem Possible Cause - Solution Nothing appears on The screen saver is activated. Press any key, or touch the TouchPad. screen and the LED The system is in Hibernate or Standby mode. Press the Fn + Esc key combination (see power indicator , is 3 - 22...
  • Page 137 Troubleshooting Problem Possible Cause - Solution The screen is flickering, The vertical refresh rate is insufficient on your external monitor. Avoid using the or the images aren’t Simultaneous display mode. Use the LCD only or an external monitor only. Switch to a clear.

  • Page 138: Hard Disk & Boot Password

    Troubleshooting Hard Disk & Boot Password Problem Possible Cause - Solution The computer takes Data saved on the hard disk drive may be lost or damaged. Operate the scan disk or disk longer during Startup. defragmenter to check for any lost or damaged data. The computer is waking up from the Hibernate mode.

  • Page 139: Floppy Disk Drive

    Troubleshooting Floppy Disk Drive Problem Possible Cause - Solution The floppy disk drive will The floppy disk is not formatted. Format the disk (you may do this by right-clicking the disk not write data to disk. icon in My Computer in Windows and choosing Format from the menu). Bear in mind that this will erase all data contained on the floppy disk.

  • Page 140: Audio & Cd Device

    Troubleshooting Audio & CD Device Problem Possible Solution The sound cannot be The volume might be set too low. Check the volume control in the Volume Control Panel heard or the volume is in the Windows taskbar, or use the key combination F7 + F8 (see “The Function Keys very low.
  • Page 141 Troubleshooting Problem Possible Solution The CD Device cannot The external IDE device drive is not plugged in correctly to the port on the left (see be accessed. “External IDE Port” on page 1 - 13) of the computer. Check that the connector is fully locked into the port and restart the computer.

  • Page 142: Pc Card

    Troubleshooting PC Card Problem Possible Cause - Solution The system cannot The PC Card is not inserted into the socket or inserted incorrectly. Remove the card and recognize the PC Card. re-insert it aligning the PC Card with the slot. Push the card in until it locks into place. The PC Card or card driver is not compatible with the computer.

  • Page 143: Keyboard And Mouse

    Troubleshooting Keyboard and Mouse Problem Possible Cause - Solution Unwelcome numbers If the LED is lit, then Num Lock is turned ON. Press and release the Num Lock key. appear when typing. I have installed a new You have not installed the driver to enable any extra functions. Make sure you read the external keyboard or documentation that comes with any new external device, and make sure you install the mouse but cannot use all...

  • Page 144: Printer

    Troubleshooting Printer Problem Possible Cause - Solution The printer cannot be The printer is not turned on, is not correctly connected to the computer, or has an internal added to the system or problem. Make sure the printer is on. Check all connections and cables and then try to will not work.

  • Page 145: Operation

    Troubleshooting Operation Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC adapter, press the sleep the screen goes dark. (Fn + Esc) key combination, or press the power button if no LEDs are lit. A software conflict made the system “crash”.

  • Page 146: Appendix A. Specifications

    Appendix A. Specifications Structure Core Logic • PC 99 Compliant • SIS650 chipset BIOS Processor • One 256KB Flash ROM • Mobile Intel Pentium 4 Processor-M (478-pin) • Phoenix BIOS uFC-PGA package 0.13 Micron Process Technology - 1.4/1.5/1.6/1.7/ 1.8/1.9/2.0 GHz •...

  • Page 147: Pc Card Sockets

    Storage Security • External IDE Combo Drive for the following • Security (Kensington® Type) Lock Slot combination options: • BIOS Password 24x CD-ROM & FDD Audio 8x DVD-ROM & FDD • AC'97 2.1 Compliant Interface 8x CD-R/ 4x CD-RW/24x CD-ROM & FDD •...

  • Page 148: Power Management

    Interface Communication • Built-in Touchpad with scrolling function • 56K Plug & Play Fax/Modem V.90 & V.92 com- • One PS2 port pliant • Two USB 2.0 ports • 10M/100M Fast Ethernet (IEEE 802.3 and • One mini- IEEE 1394 port 802.3u Standard Compliant) •...

  • Page 149: Environmental Spec

    Indicator Optional • LED indicators (GSM/GPRS/CDMA, Power/ • Standard smart Li-ion battery pack, 44.4 Watt Sleep, Charger, FDD/ CD-ROM, HDD, Num • Ultra smart Li-ion battery pack, 88.8 Watt Lock, Caps Lock, Scroll Lock) • External IDE Combo Drive Options: Environmental Spec 24x CD-ROM &...
