Page 1 User’s Manual 700 Series Color Mobile Computer...
Page 2 700 Series Color Mobile Computer USER’S MANUAL " " " " " " " " " " " " " " " " " " " " " P/N 961-054-031 Revision A September 2002...
Page 3 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
Page 4: Table Of Contents
........... . About the 700 Series Color Mobile Computer .
Page 5 ............2-44 Getting Books on Your 700 Series Computer ......
Page 6 ..........3-11 700 Series Color Mobile Computer User’s Manual...
Page 7 ........4-31 700 Series Color Mobile Computer User’s Manual...
Page 8 ............4-38 SNMP Configuration on the 700 Series Computer ......
Page 9 ..........6-41 700 Series Color Mobile Computer User’s Manual...
Page 10 ............6-70 700 Series Color Mobile Computer User’s Manual...
Page 11 ......... . 7-39 viii 700 Series Color Mobile Computer User’s Manual...
Page 12 ............A-41 700 Series Color Mobile Computer User’s Manual...
Page 13 ......... . 700 Series Color Mobile Computer User’s Manual...
Page 14 ........INDEX 700 Series Color Mobile Computer User’s Manual...
Page 15 CONTENTS 700 Series Color Mobile Computer User’s Manual...
Page 16: Introduction
Appendix C — Bar Codes Describes some of the more common bar code symbologies and includes bar code labels that can be scanned to configure your 700 Series Computer. 700 Series Color Mobile Computer User’s Manual...
Page 17: About The 700 Series Color Mobile Computer
(2 x 2000 mAh cells), replaceable Lithium-Ion (LiIon) battery. To view the status of this battery from the 700 Series Computer, tap Start → Settings → the System tab → the Power icon to view the current status of both the main battery and the backup battery.
Page 18: Low Battery Shutdown
SECTION 1 Introduction You can also view the battery status for the 700 Series Computer by accessing the Unit Information control panel applet. Tap the Unit Information icon, then tap the Battery Status tab to view the current status. Tap ok to exit this information.
Page 19: Cab Files Within 700C Software Tools Cd
Communications Removeable Card Support To access either the CompactFlash (CF) or SecureDigital (SD) card slot, locate the access door at the top of the 700 Series Computer, remove its two screws, then remove the door. CompactFlash Cards Support is limited to one CompactFlash (CF) Storage Card in the 700 Series Computer, either for storage or for the 802.11b radio.
Page 20: Software Build Version
SECTION 1 Introduction Software Build Version To check to see if your 700 Series Computer has the latest build, select Start → Internet Explorer → the Intermec logo. The latest software build version is displayed beneath the Patent Information title. This information will be useful should you need customer assistance.
Page 21: Related Publications
Introduction SECTION 1 Related Publications To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor. Following are related INTERMEC manuals, CD-ROMs, and part numbers (P/N): 700 Series Color Mobile Computer Quick Start Guide (P/N: 962-054-053) "...
Page 22: Pocket Pc 2002
700 Series Color Mobile Computer, you can keep your most important busi- ness and personal information up-to-date and close at hand. Microsoft Active- Sync increases the power of your 700 Series Computer by allowing you to syn- chronize the information on your desktop or laptop computer with your 700 Series Computer.
Page 23: Premium Versus Professional Editions
SECTION 1 Premium versus Professional Editions Your 700 Series Computer will have either the Premium Edition or the Profes- sional Edition of Pocket PC 2002. Do the following to determine which edition of Pocket PC 2002 is on your unit.
Page 24: Where To Find Information
Where to Find Information This section describes your 700 Series Computer hardware, provides an overview of the programs on your 700 Series Computer, and explains how to connect your 700 Series Computer to a desktop computer, a network, or the Internet. For in- structions on setting up your 700 Series Computer and installing ActiveSync, see the Quick Start Card.
Page 25: Basic Skills
On the pop-up menu that appears, tap the action to be performed. Today Screen When you turn on your 700 Series Computer for the first time each day (or after four hours of inactivity), you will see the Today screen. You can also display it by tapping the Start flag (shown left) and then Today.
Page 26 Notification that one or more e-mail messages were received. If more notification icons need to be displayed than there is room to display them, the Notification icon (shown left) will display. Tap the icon to view all notification icons. 700 Series Color Mobile Computer User’s Manual...
Page 27: Programs
Drag the stylus off the label so that the command is not carried out. The following is a partial list of programs that are on your 700 Series Computer. Look on the Pocket PC Companion CD for additional programs that you can install onto your 700 Series Computer.
Page 28: Navigation Bar And Command Bar
To create a new item in the current program, tap New. To see the name of a but- ton, tap and hold the stylus on the button. Drag the stylus off the button so that the command is not carried out. 700 Series Color Mobile Computer User’s Manual...
Page 29: Pop-Up Menus
Notifications Your 700 Series Computer reminds you in a variety of ways when you have something to do. For example, if you have set up an appointment in Calendar, a...
Page 30: Enter Information On Your 700 Series Computer
700 Series Computer. For more information on ActiveSync, see ActiveSync Help on your desktop computer. Use the input panel to enter information in any program on your 700 Series Computer. You can either type using the soft keyboard or write using Block Recognizer, Letter Recognizer, or Transcriber.
Page 31: Typing With The Soft Keyboard
2. On the soft keyboard that is displayed, tap the keys with your stylus. Using Block Recognizer With Block Recognizer, you can input character strokes using the stylus that are similar to those used on other 700 Series Computers. 1. Tap the arrow next to the Input Panel button, and then Block Recognizer.
Page 32: Writing On The Screen
You can cut, copy, and paste written text in the same way you work with typed text: tap and hold the selected words and then tap an editing command on the pop-up menu, or tap the command on the Edit menu. 700 Series Color Mobile Computer User’s Manual 2-11...
Page 33: Converting Writing To Text
(tap one word at a time). On the pop-up menu, tap Alternates. A menu with a list of alternate words appears. Tap the word you want to use, or tap the writing at the top of the menu to return to the original writing. 2-12 700 Series Color Mobile Computer User’s Manual...
Page 34: Drawing On The Screen
Write the letters of a word closely and leave big gaps between words so that " the 700 Series Computer can easily tell where words begin and end. Hyphenated words, foreign words that use special characters such as ac- "...
Page 35: Selecting A Drawing
Creating a Recording 1. Hold your computer’s microphone near your mouth or source of sound. 2. Press and hold the Record hardware button on your 700 Series Computer until you hear a beep. 3. While holding down the Record button, make your recording.
Page 36: Using My Text
Tap Start → Find. Enter the text you want to find, select a data type, and then tap Go to initiate the search. " NOTE: To quickly find information that is taking up storage space on your 700 Series Computer, select Larger than 64 KB in Type. 700 Series Color Mobile Computer User’s Manual...
Page 37: Customizing Your 700 Series Computer
Pocket PC 2002 SECTION 2 You can also use the File Explorer to find files on your 700 Series Computer and to organize these files into folders. Tap Start → Programs File Explorer. → " NOTE: You can move files in File Explorer by tapping and holding the item you want to move, and then tapping Cut or Copy and Paste on the pop-up menu.
Page 38: Adding Or Removing Programs
Pocket PC 2002 Adding or Removing Programs Programs added to your 700 Series Computer at the factory are stored in ROM (Read Only Memory). You cannot remove this software, and you will never acci- dentally lose ROM contents. ROM programs can be updated using special instal- lation programs with a *.XIP extension.
Page 39: Adding A Program Directly From The Internet
If you do not see the program listed, you can either use File Ex- plorer on the 700 Series Computer to move the program to the Start Menu fold- er, or use ActiveSync on the desktop computer to create a shortcut to the pro- gram and place the shortcut in the Start Menu folder.
Page 40: Microsoft Activesync
Computer. After installation is complete, the ActiveSync Setup Wizard helps you connect your 700 Series Computer to your desktop computer, set up a partnership so you can synchronize information between your 700 Series Computer and your desk- top computer, and customize your synchronization settings. Your first synchro- nization process will automatically begin when you finish using the wizard.
Page 41 SECTION 2 For information about using ActiveSync on your desktop computer, start ActiveSync on your desktop computer, and then see ActiveSync Help. For more information about ActiveSync on your 700 Series Computer, switch to ActiveSync, then tap Start Help. →...
Page 42: Microsoft Pocket Outlook
You can also synchronize this information directly with a Microsoft Exchange server. Each time you synchronize, ActiveSync compares the changes you made on your 700 Series Computer and desktop computer or server and updates both computers with the latest information. For information on using ActiveSync, see ActiveSync Help on the desktop computer.
Page 43: Creating An Appointment
7. When finished, tap OK to return to the calendar. " NOTE: If you select Remind me in an appointment, your 700 Series Computer will remind you ac- cording to the options set in Start → Settings → the Personal tab → Sounds & Remind- ers.
Page 44: Using The Summary Screen
The meeting notice is created automatically and placed in the Outbox folder. For more information on sending and receiving meeting requests, see Calendar Help and Inbox Help on the 700 Series Computer. 700 Series Color Mobile Computer User’s Manual 2-23...
Page 45: Contacts: Tracking Friends And Colleagues
Contacts maintains a list of your friends and colleagues so that you can easily find the information you are looking for, whether you are at home or on the road. Using the 700 Series Computer infrared (IR) port, you can quickly share Contacts information with other 700 Series Computer users.
Page 46: Creating A Contact
View → By Company. The number of contacts that work for that company will be displayed to the right of the company name. Tap Start → Find, enter the contact name, select Contacts for the type, " and then tap Go. 700 Series Color Mobile Computer User’s Manual 2-25...
Page 47: Tasks: Keeping A To Do List
Tasks: Keeping a To Do List Use Tasks to keep track of what you have to do. " NOTE: To change the way information is displayed in the list, tap Tools → Options. 2-26 700 Series Color Mobile Computer User’s Manual...
Page 48: Creating A Task
" NOTE: To quickly create a task with only a subject, tap Entry Bar on the Tools menu. Then, tap Tap here to add a new task and enter your task information. 700 Series Color Mobile Computer User’s Manual 2-27...
Page 49: Using The Summary Screen
Pocket PC 2002 SECTION 2 Using the Summary Screen When you tap a task in the task list, a summary screen is displayed. To change the task, tap Edit. 2-28 700 Series Color Mobile Computer User’s Manual...
Page 50: Notes: Capturing Thoughts And Ideas
If a note is open when you create the recording, it will be in- cluded in the note as an icon. If the note list is displayed, it will be created as a stand-alone recording. 700 Series Color Mobile Computer User’s Manual 2-29...
Page 51: Creating A Note
Messages are copied from the mail folders of Exchange or Outlook on your " desktop computer to the ActiveSync folder in Inbox on your 700 Series Computer. By default, you will receive messages from the past three days only, the first 100 lines of each message, and file attachments of less than 100 KB in size.
Page 52: Connecting Directly To An E-Mail Server
Messages that you receive directly from an e-mail server are linked to your e- mail server rather than your desktop computer. When you delete a message on your 700 Series Computer, it is also deleted from the e-mail server the next time you connect based on the settings you selected in ActiveSync.
Page 53 Change options for direct e-mail server connections in Inbox on your 700 " Series Computer. Tap Tools → Options → the Service tab, then tap the service you want to change. Tap and hold the service and select Delete to remove a service. 2-32 700 Series Color Mobile Computer User’s Manual...
Page 54: Composing Messages
By default, messages are displayed in one of five folders for each service you have created: Inbox, Deleted Items, Drafts, Outbox, and Sent Items. The Deleted Items folder contains messages that have been deleted on the 700 Series Computer. The behavior of the Deleted and Sent Items folders depends on the options you have chosen.
Page 55: Folder Behavior With A Direct Connection To An E-Mail Server
The folders you create and the e-mail messages you move are mirrored on the server. Therefore, messages are available to you anytime you connect to your mail server, whether it is from your 700 Series Computer or desktop computer. This synchronization of folders occurs whenever you connect to your mail server, create new folders, or rename/delete folders when con- nected.
Page 56: Companion Programs
(.DOC), Pocket Word (.PSW), Rich Text Format (.RTF), and Plain Text (.TXT). Pocket Word contains a list of the files stored on your 700 Series Computer. Tap a file in the list to open it. To delete, make copies of, and send files, tap and hold a file in the list.
Page 57: Typing Mode
Word document, using your stylus instead of the mouse to drag through the text you want to select. You can search a document to find text by tapping Edit → Find/Replace. 2-36 700 Series Color Mobile Computer User’s Manual...
Page 58: Writing Mode
“Drawing Mode” on the next page. Written words are converted to graphics (metafiles) when a Pocket Word document is con- verted to a Word document on your desktop computer. 700 Series Color Mobile Computer User’s Manual 2-37...
Page 59: Drawing Mode
In recording mode, embed a recording into your document. Recordings are saved as .WAV files. For more information on recording, see “Basic Skills” on page 2-4. For more information on using Pocket Word, tap Start → Help. 2-38 700 Series Color Mobile Computer User’s Manual...
Page 60: Pocket Excel
Pocket Excel (.PXL) and Excel (.XLS). Pocket Excel contains a list of the files stored on your 700 Series Computer. Tap a file in the list to open it. To delete, make copies of, and send files, tap and hold a file in the list.
Page 61: Tips For Working In Pocket Excel
For more information on using Pocket Excel, tap Start → Help. MSN Messenger " NOTE: MSN Messenger is only available on the Premium Edition of Pocket PC 2002. MSN Messenger on your 700 Series Computer is an instant messaging program that lets you: See who is online. "...
Page 62: Working With Contacts
If you block a contact, you will appear offline but will remain on the blocked contact’s list. To unblock a contact, tap and hold the contact, then tap Unblock on the pop-up menu. 700 Series Color Mobile Computer User’s Manual 2-41...
Page 63: Chatting With Contacts
Chats and select the person whom you were chatting with. To know if the contact you are chatting with is responding, look for the message under the text entry area. For more information on using MSN Messenger, tap Start → Help. 2-42 700 Series Color Mobile Computer User’s Manual...
Page 64: Windows Media Player For Pocket Pc
Use Microsoft Windows Media Player for Pocket PC to play digital audio and vid- eo files that are stored on your 700 Series Computer or on a network. To switch to Windows Media Player for Pocket PC, tap Start → Programs →...
Page 65: Microsoft Reader
Web site. Then, use ActiveSync to copy the book files to your activated 700 Series Computer. The books appear in the Reader Library, where you can tap them in the list to open them.
Page 66: Reading A Book
On a book page, select the text you want to copy. Then, tap Copy Text on the pop-up menu. The text can be pasted into the pro- gram of your choice. 700 Series Color Mobile Computer User’s Manual 2-45...
Page 67: Removing A Book
Series Computer. If a copy of the book is stored on your desktop computer, you can download it again at any time. To remove a book from your 700 Series Computer, tap and hold the title in the Library list, and then tap Delete on the pop-up menu.
Page 68: Favorite Links
Unless you mark the favorite link as a mobile favorite, only the link will be downloaded to your 700 Series Computer, and you will need to connect to your ISP or network to view the content. For more infor- mation on synchronization, see ActiveSync Help on the desktop computer.
Page 69: Using Avantgo Channels
1. In ActiveSync options on the desktop computer, turn on synchronization for the AvantGo information type. 2. In Pocket Internet Explorer on your 700 Series Computer, tap the Favor- ites button to display your list of favorites. 3. Tap the AvantGo Channels link.
Page 70: Viewing Mobile Favorites And Channels
Go. Tap the arrow to choose from previously entered addresses. " NOTE: To add a favorite link while using the 700 Series Computer, go to the page you want to add, tap and hold on the page, and tap Add to Favorites.
Page 71: Getting Connected
Series Computers as well as your desktop computer, a network, or the Internet. You have the following connection options: Use the infrared (IR) port on your 700 Series Computer to send and receive " files between two 700 Series Computers. If this is the method you want to use, see “Transferring Items Using Infrared”...
Page 72: Connecting To An Internet Service Provider
TCP/IP settings " 2. If your 700 Series Computer does not have a built-in modem, install a mo- dem card, or use or use a NULL modem cable and appropriate adapters to connect an external modem to your 700 Series Computer through the serial port.
Page 73: Creating An Ethernet Connection To An Isp
SECTION 2 Creating an Ethernet Connection to an ISP 1. You do not need to create a new connection on your 700 Series Computer. Instead, you must purchase and configure an Ethernet card that is compat- ible with your 700 Series Computer.
Page 74: Creating An Ethernet Connection To Work
Creating an Ethernet Connection to Work 1. You do not need to create a new connection on your 700 Series Computer. Instead, you must purchase and configure an Ethernet card that is compat- ible with your 700 Series Computer.
Page 75: Ending A Connection
Pocket PC 2002 SECTION 2 7. If you want to synchronize your 700 Series Computer, tap Start → ActiveSync. In the Tools menu, tap Options. In the PC tab, select Include PC when synchronizing remotely and connect to, and select your computer’s name.
Page 76 " " There are multiple ways to get an application to your 700 Series Color Mobile Computer; just as there are multiple ways to package the application for deliv- ery. Use any of the following methods to package an application for installation: For very simple applications, the application itself might be the only file "...
Page 77: Installing Applications
Using Microsoft ActiveSync " NOTE: These instructions assume that the 700 Color Management Tools portion of the 700 Series Color (700C) Software Tools CD was installed onto your desktop. The Microsoft ActiveSync tool is located on the 700C Companion CD, which con- tains Microsoft products, such as Outlook and ActiveSync.
Page 78: Using The Ftp Server
The benefit of using FTP is that a script can be created that will automate the process of copying files to the 700 Series Computer. This op- tion is good for when a large number of 700 Series Computers need to be up- dated. See Section 7, “Programming,” for more information.
Page 79: Copying To A Securedigital Storage Card
Before performing this update, please ensure that the 700 Series Computer to be updated has a fully charged battery. A power failure during the update will corrupt the computer flash, thus the computer would not boot. You will have to send the 700 Series Computer to service to recover the computer flash.
Page 80 " “C:\Intermec\Intermec 700 Color Mgmt Tools\Cab Files” 9. When all of the files are pasted, perform a cold-boot on the 700 Series Com- puter. When the computer reboots, wait for the LED on the top left of your keypad to stop blinking. Tap Start → Programs → File Explorer to lo- cate the newly copied executable files, then tap these files to activate their utilities.
Page 81: Updating With A Storage Card
To update the 700 Series Computer image, copy the AUTOFLASH.NB0 file to either a CompactFlash or SecureDigital storage card, insert this card into the 700 Series Computer, then perform a cold-boot (or hard reboot) on the 700 Series Computer. Do the following to automatically update the system software on a 700 Series Computer.
Page 82: How It Works
4 on page 3-5, the following dialog appears with a list of available up- grade files. Select the file to be flashed onto the 700 Series Computer, then tap the appropriate button, then tap EFlash to flash the selected file.
Page 83: File Types
IFTP Server Command Line Syntax EFlash can be invoked as process with the following syntax after logging into a 700 Series Computer using any conventional FTP client that allows interactive mode. The following site command can be used with Microsoft FTP Client: ftp>...
Page 84: Application Migration
" Do the following for the cold-boot procedure: 1. From your desktop, double-click the Intermec CE Imager desktop icon to access the Intermec CEImager application. If this icon is not on your desktop, then double-click the CEIMAGER.EXE executable from the “C:\Intermec\Intermec 700 Color Mgmt Tools\Tools\CEImager”...
Page 85 API to make sure the registry is written to the appropriate card; or you can use the Utilities control panel applet, as follows: a. From the 700 Series Computer, tap Start → Settings → the Utilities icon → the Registry Save tab.
Page 86: Cabinet File Installation
The arrow and tab keys are swapped from the way they were on the 700 " Series Monochrome Computers. Keyboard remapping is available on the 700 Series Color Computer if these keys need to be changed. See page 3-4 for more details. No special SDK is needed to compile applications for the Xscale processor.
Page 87 Installing Applications and Updating System Software SECTION 3 3-12 700 Series Color Mobile Computer User’s Manual...
Page 88 " " The 700 Series Color Mobile Computer can integrate up to three radios in a single unit, and will automatically install the appropriate software for radio use when the unit is powered on. The Intermec CORE application defaults to the most recently used module.
Page 89: Ethernet Communications
" NOTE: Once CORE is running, you can return to it by tapping its icon from the System Tray via the Today screen. Tap Start → Today → the Intermec CORE three-ring icon (circled in the fol- lowing illustration). Network Adapters Your 700 Series Computer can have up to three radios installed.
Page 90: Ethernet Communications
System Tray. When “No network- ing” is selected, then this icon will appear with a red “X” above it. From the 700 Series Computer, tap Start → Settings → the Connections tab → Network Adapters to access the network connections for this unit. Make the changes necessary for your network, then tap ok when finished.
Page 91: Basic
SECTION 4 802.11b Communications The 700 Series Computer can integrate the 802.11b radio module along with ei- ther the GSM/GPRS or the CDMA/1xRTT radio and the Wireless Printing op- tion. The 802.11b radio module accommodates any Wireless LAN (WLAN) re- quirements, such as using WLAN access points for cross-docking or load-planning applications.
Page 92 Leave Use Profile Name for SSID checked for the SSID to use this as- signed profile name. If this is cleared (check mark removed), the SSID will default to using the factory-assigned “INTERMEC” network name. Go to page 4-6 to continue.
Page 93 1–15, through which to handle con- nections (default is 3). Enable Power Management: Check this box to conserve battery power (default), or clear this box to dis- able this feature. 700 Series Color Mobile Computer User’s Manual...
Page 94 Equivalent Privacy) encryption. Click OK to return to the Profiles page. The following securities are available from the Security Method drop-down list. Note that the last three methods are available if you have purchased the security package. Contact your Intermec Representative for more information. 802.11 WEP Encryption "...
Page 95: Certificates
Enter the user ID associated with this certificate. Server Cert CN (Certificate Common Name): Enter the common name of your authentication server. CA List (Certificate Authority): Enter the file location, or path, of the server certificates. 700 Series Color Mobile Computer User’s Manual...
Page 96 Enter the common name of your authentication server. CA List: Enter the file location, or path, of the server certificates. LEAP (Cisco Wireless EAP (Extensible Authentication Protocol)): Enter your unique user name and password to use this protocol. 700 Series Color Mobile Computer User’s Manual...
Page 97 If “802.1x TLS,” “802.1x TTLS,” or “LEAP” were enabled via the Security tab, then this button will appear. Tap this button to configure the available certificates. See “Certificates” on the next page for more information. 4-10 700 Series Color Mobile Computer User’s Manual...
Page 98 Enroll File Name: Enter the file name of the certificate to be enrolled. Store Location: Enter the path where the certificate is to be stored within your 700 Series Computer. Enroll: Tap this to assign the file entered in Enroll File Name to the location spe- cified in Store Location.
Page 99: Import/Export
OK to export the profile, tap ok to close the confirmation screen, then tap OK again to exit the Profile Wizard. 4-12 700 Series Color Mobile Computer User’s Manual...
Page 100: Scan List
Select this option to use the profile defined in the Profiles page, then tap OK to exit the Profile Wizard. When connections are lost, attempts will be made to con- nect to the specified profile. 700 Series Color Mobile Computer User’s Manual 4-13...
Page 101 Move Up or Move Down to move each profile. To remove a profile from the list, tap to select that profile, then tap Delete. 4. Click either ok or Close to return to the Scan List page, then click OK to exit the Profile Wizard. 4-14 700 Series Color Mobile Computer User’s Manual...
Page 102 CDMA/1xRTT radio along with the 802.11b radio and the Wireless Printing op- tion. The WWAN radio option accommodates any Wireless WAN requirements, such as taking the 700 Series Computer off the premises in a delivery vehicle to cover a much larger area.
Page 103: Wan Radio Core Module
SECTION 4 WAN Radio CORE Module The WAN radio CORE module displays helpful information about either the GSM/GPRS radio or the CDMA/1xRTT radio option built into your 700 Series Computer. The following illustrations are for a GSM/GPRS radio. General Below are descriptions and meanings for each piece of information provided via the General tab, reading from top to bottom starting on the left.
Page 104 This indicates whether serial communications passed (“Serial com OK”) or failed (“Serial com FAIL”) in its last transaction. A status of “Serial com FAIL” typically indicates that the 700 Series Computer is unable to estab- lish communication with the radio module installed within.
Page 105 Serial Status: This indicates whether serial communications passed (“PASS”) or failed (“FAIL”) in its last transaction. A status of “FAIL” typically indicates that the 700 Series Computer is unable to establish communication with the ra- dio module installed within. Manufacturer: This lists the name of the manufacturer that developed this radio module, such as “Xircom,”...
Page 106 This provides the last date when this firmware was updated, if available. IMSI # (GSM/GPRS): This shows the IMSI (International Mobile Subscriber Identity) number assigned to the SIM card installed in this 700 Series Computer. Terminal Application Tap Terminal App from the Details page to send standard AT commands. In- formation about these AT commands are available under “AT Command Inter-...
Page 107 SECTION 4 Phone Application With the WAN radio module installed in your 700 Series Computer, you can send and receive telephone calls. Use the speaker on the back of the computer as your earpiece and use the connector on the bottom of the computer for your mouth- piece.
Page 108 COM4. Do the following to initiate this connection and test these commands to your radio: 1. From the 700 Series Computer, select Start → Settings → the Connections tab → the Connections icon. 2. Tap Modify beneath the Internet Settings drop-down list.
Page 109 Tap Advanced to continue. 5. On the Port Settings tab, check Enter dialing commands manually, then tap ok, Next, then Finish to return to the Internet Settings screen with your new connection. 4-32 700 Series Color Mobile Computer User’s Manual...
Page 110 Note that each “AT” command must start with either the “at” or “at+” characters. To see what you typed onscreen, type “ate1” to initiate the AT Echo " command, then press Enter. 700 Series Color Mobile Computer User’s Manual 4-33...
Page 111 Bluetooth qualified module by Socket Communications) along with either the GSM/GPRS or the CDMA/1xRTT radio and the 802.11b radio. This option uses the network to print information stored on the 700 Series Com- puter. “Bluetooth” is the name given to a technology standard using short-range radio links, intended to replace the cables connecting portable and fixed electronic de- vices.
Page 112 “Lim” Limited discovery “No” Not discoverable Connectable: This defines whether the 700 Series Computer is able to accept other de- vices with Bluetooth compatible modules connecting to it. “Yes” if the con- nection is doable, “No” if not. Bondable: This defines the security element of the 700 Series Computer, which is the bondable setting.
Page 113 To extend the number of attempts that a DHCP client makes to get a DHCP address, use the DhcpRetryDialogue and DhcpMaxRetry registry settings. Change the AutoInterval registry key value to make the client retry more often to obtain a DHCP address. 4-36 700 Series Color Mobile Computer User’s Manual...
Page 114: Snmp Configuration
700 Series Color Mobile Computer User’s Manual 4-37...
Page 115 Computer In short, SNMP is an application-layer protocol that facilitates the exchange of management information between network devices. The 700 Series Computer is such an SNMP-enabled device. Use SNMP to control and configure the 700 Se- ries Computer anywhere on an SNMP-enabled network.
Page 116 Defines objects for Intermec SNMP parameters and security methods, such as an SNMP security IP address. ITCTERMINAL.MIB Defines objects for 700 Series parameters, such as key clicks. Object Identifiers Each object has a unique identifier called an OID. OIDs consist of a sequence of integer values represented in dot notation.
Page 117 Subnet Mask). Configuring with SNMP The community string allows an SNMP manager to manage the 700 Series Com- puter with a specified privilege level. The default read-only community string is “public” and “private” is the default read/write community string. See the specif- ic configuration parameter to find its OID.
Page 118 (hLoaderDev != INVALID_HANDLE_VALUE) { if (!DeviceIoControl( hLoaderDev, IOCTL_UNLOAD_NDIS_MINIPORT, NULL, -1, NULL, 0, &bytesReturned, NULL)){ MessageBox(NULL, TEXT(“SYSIO IoControl Failed”),TEXT(“Network loader”),MB_ICONHAND); if (hLoaderDev!=INVALID_HANDLE_VALUE) CloseHandle(hLoaderDev); hLoaderDev = INVALID_HANDLE_VALUE; // bad handle }else { CloseHandle(hLoaderDev); 700 Series Color Mobile Computer User’s Manual 4-41...
Page 119 WEP string. It will typically be set to one, so that the resulting encrypted key will be active. If set to zero, the key can still be stored in the registry, but it will not be used by the driver. 4-42 700 Series Color Mobile Computer User’s Manual...
Page 120 1 = Poor (–100 to –86 dBm) 0 = Out of range (< –100 dBm) Return Value: This function returns a NULL if successful or a non-zero value if an error occurs. 700 Series Color Mobile Computer User’s Manual 4-43...
Page 121 InfrastructureMode [out] Infrastructure setting return value. Valid values are INFRASTRUCTURE_AP and INFRASTRUCTURE_PP. Return Value: This function returns a NULL if successful or a non-zero value if an error occurs. 4-44 700 Series Color Mobile Computer User’s Manual...
Page 122 Valid return values in this variable are CONFIG_01, CONFIG_02, or CONFIG_03. Return Value: This function returns a NULL if successful or a non-zero value if an error occurs. 700 Series Color Mobile Computer User’s Manual 4-45...
Page 123 Peer-to-Peer infrastructure mode. Valid 802.11b channels for North America are 1 through 11. Return Value: This function returns a NULL if successful or a non-zero value if an error occurs. 4-46 700 Series Color Mobile Computer User’s Manual...
Page 124 [in] A setting of “0” will disable power management in the network card. A setting of “1” will enable it. Return Value: This function returns a NULL if successful or a non-zero value if an error occurs. 700 Series Color Mobile Computer User’s Manual 4-47...
Page 125 UpdateNIC_WEP_Key( TCHAR *szEncryptedWEP ); Parameters: WEP_Key [in] Pointer to the buffer where the encrypted key is stored. Return Value: This function returns a NULL if successful or a non-zero value if an error occurs. 4-48 700 Series Color Mobile Computer User’s Manual...
Page 126: Printing Ascii
" " " " " " " The 700 Series Color Mobile Computer works with the following printers from Intermec Technologies. Contact an Intermec Representative for information about these printers. 6820 A full-page, 80-column printer. 6808 A 4-inch belt-mount printer.
Page 127: Irda Printer Driver
IrDA printing is only available on the certain devices and is supported directly by the Windows CE load via the IrSock API provided by the Microsoft Win32 API without need for additional drivers. Intermec 6804, 6805, 6806, 6808 and 6820 and other IrDA printers are supported.
Page 128: Opening The Npcp Driver
If the function returns FALSE, the NPCP error may be retrieved using IOCTL_NPCP_ERROR. See the description on the next page. 700 Series Color Mobile Computer User’s Manual...
Page 129: Npcp Driver I/O Controls
If an error occurs dur- ing the polling process, the operation will return FALSE and the applica- tion can get the extended error code by using IOCTL_NPCP_ERROR. No parameters are required. 700 Series Color Mobile Computer User’s Manual...
Page 130: Npcp Printer Communications
#define HEADFAULT (BYTE)228 // printer head short or driver short error #define PFFAULT (BYTE)229 // paper feed motor fault. #define FRAME_NOT_ACKED 0x8000 // frame was not received by printer and need to be resent. 700 Series Color Mobile Computer User’s Manual...
Page 131: O'neil Printer Driver
The port associated with the device during RegisterDevice() is currently in " use. The DTR device is already open. " The share mode is not set to zero. The device cannot be shared. " Access permissions are not set to GENERIC_WRITE. " 700 Series Color Mobile Computer User’s Manual...
Page 132: Closing The Dtr Driver
1. Use CreateFile(); to open the printer driver. 2. Use WriteFile() to write your data to the printer. Check for errors and that all data were written. 3. Use CloseHandle() to close the driver. 700 Series Color Mobile Computer User’s Manual...
Page 133 Printer Support SECTION 5 700 Series Color Mobile Computer User’s Manual...
Page 134 " " " " The 700 Series Color Mobile Computer is available with imaging or laser scan- ning technologies, including the following: APS linear imager: Reads 1D symbologies and PDF 417 bar codes. Linear imaging using Vista Scanning technology reads low-contrast bar codes, laminated bar codes, and bar codes displayed on CRT or TRT displays.
Page 135: Scanner Control And Data Transfer
700 Series Computer has completed initialization, which occurs during a warm- or cold-boot or after a firmware upgrade. When initialization is complete, the green LED on the 700 Series Computer stops flashing. Changes made to configuration settings remain after a warm boot.
Page 136: Multiple Adc Com Object Support
Scanner Support Multiple ADC COM Object Support A 700 Series Computer may have multiple reader engines to decode different types of ADC data. For example, a bar code reader engine decodes raw bar code data and passes it to a bar code reader COM object. An RFID reader engine de- codes raw RFID tag data and passes it to an RFID tag reader COM object.
Page 137: Read-Ahead Bar Code Data Access
The virtual wedge retrieves scanned Automatic Data Collection (ADC) data and sends it to the keypad driver so that the 700 Series Computer can receive and interpret the data as keypad input. The data can be filtered so that only data conforming to a certain text pattern or symbology will be sent to an application.
Page 138: Filter Expression Values
{min,max} A repetition operator like + or *, [a--z]{1,3} matches a, ab, or aab, except the number of repetitions but not aabc is specified by min and max. 700 Series Color Mobile Computer User’s Manual...
Page 139: Editing Expression Values
When matching is attempted, the first grid expression from left to right that achieves a match will cause the data to be accepted. All pattern expressions and parsed data are in Unicode. 700 Series Color Mobile Computer User’s Manual...
Page 140: Adc Connection
“Gordon, Dexter”. ADC Connection A 700 Series Computer can have both Bar Code and RFID reader engines with each engine supporting multiple connections. Each connection allows an applica- tion to access data or manage a configuration. An application could have multi- ple connections.
Page 141: D Imager Overview
Omni-directional scanning is a feature that does not require configuration. 1D and stacked symbologies as well as 2D matrix symbologies can be scanned with the 700 Series Computer in any orientation. Thus, time is not needed to orient the 700 horizontal as with laser scanners.
Page 142: Image Acquisition Features
X,Y dimension of image to be captured, and the aspect ratio of the bar code. Note the units are in terms of the narrow element width of the bar code. 700 Series Color Mobile Computer User’s Manual...
Page 143 See the following example signature capture label and dimensions. These image acquisition features are provided through the IImage Interface de- fined on page 6-65. Y-axis – X X-axis Bar code height Intelligent bar code units – Y 6-10 700 Series Color Mobile Computer User’s Manual...
Page 144: Create And Delete Adc Com Object Functions
On Windows, this interface decrements the reference count. So alternatively, IUnknown::Release() could be used and must be used if reference counting is performed with IUnknown::AddRef(). On DOS, this function closes all resources associated with the channel. 700 Series Color Mobile Computer User’s Manual 6-11...
Page 145: Iadc Functions
Total number of discarded bytes. Return Values: HRESULT that indicates success or failure. Remarks: The return value indicates whether a read was pending. See Also: IADC::Initialize IADC::QueryAttribute IADC::QueryData IADC::Read IADC::SetAttribute 6-12 700 Series Color Mobile Computer User’s Manual...
Page 146: Iadc::initialize
Data is buffered on behalf of the calling application. Data buffering starts after the first call to IADC::Read (). Return Values: HRESULT that indicates success or failure. See Also: IADC::CancelReadRequest IADC::QueryAttribute IADC::QueryData IADC::Read IADC::SetAttribute 700 Series Color Mobile Computer User’s Manual 6-13...
Page 147: Iadc::queryattribute
[out] Size (in bytes) of the next buffered message. Return Values: A standard status code that indicates success or failure. See Also: IADC::CancelReadRequest IADC::Initialize IADC::QueryAttribute IADC::Read IADC::SetAttribute 6-14 700 Series Color Mobile Computer User’s Manual...
Page 148: Iadc::read
If data is not available, returns quickly. INFINITE Waits until data is available. Return Values: HRESULT that indicates success or failure. See Also: IADC::CancelReadRequest IADC::Initialize IADC::QueryAttribute IADC::QueryData IADC::SetAttribute 700 Series Color Mobile Computer User’s Manual 6-15...
Page 149: Grid
Regular expression that performs data filtering and data editing. See “Grid Data Filtering” on page 6-4 for more information. Return Values: A standard status code that indicates success or failure. See Also: IADC::CancelReadRequest IADC::Initialize IADC::QueryAttribute IADC::QueryData IADC::Read 6-16 700 Series Color Mobile Computer User’s Manual...
Page 150: Ibarcodereadercontrol Functions
[in/out] Total number of discarded buffered labels or tags. pwTotalDiscardedBytes Total number of discarded bytes. Return Values: HRESULT that indicates success or failure. See Also: IBarCodeReaderControl::ControlLED IBarCodeReaderControl::Initialize IBarCodeReaderControl::IssueBeep IBarCodeReaderControl::QueryAttribute IBarCodeReaderControl::Read IBarCodeReaderControl::SetAttribute IBarCodeReaderControl::TriggerScanner 700 Series Color Mobile Computer User’s Manual 6-17...
Page 151 Remarks: This function does not coordinate LED control with the scanner. If the scanner LED control is enabled, function results will be unpredictable. See Also: IBarCodeReaderControl::CancelReadRequest IBarCodeReaderControl::Initialize IBarCodeReaderControl::IssueBeep IBarCodeReaderControl::QueryAttribute IBarCodeReaderControl::Read IBarCodeReaderControl::SetAttribute IBarCodeReaderControl::TriggerScanner 6-18 700 Series Color Mobile Computer User’s Manual...
Page 152: Ibarcodereadercontrol::cancelreadrequest Ibarcodereadercontrol::controlled
Data is buffered on behalf of the calling applications. Data Buffering starts after the first call to IADC::Read (). Return Values: HRESULT that indicates success or failure. See Also: IBarCodeReaderControl::CancelReadRequest IBarCodeReaderControl::ControlLED IBarCodeReaderControl::IssueBeep IBarCodeReaderControl::QueryAttribute IBarCodeReaderControl::Read IBarCodeReaderControl::SetAttribute IBarCodeReaderControl::TriggerScanner 700 Series Color Mobile Computer User’s Manual 6-19...
Page 153: Ibarcodereadercontrol::issuebeep
ITC_CUSTOM_BEEP, // Issue a custom beep. } ITC_BEEP_TYPE; dwNumberOfBeeps [in] Identifies the total number of beeps in rgBeepRequests. Return Values: E_NOTIMPL as this function is not implemented. See Also: IBarCodeReaderControl::CancelReadRequest IBarCodeReaderControl::ControlLED IBarCodeReaderControl::Initialize IBarCodeReaderControl::QueryAttribute IBarCodeReaderControl::Read IBarCodeReaderControl::SetAttribute IBarCodeReaderControl::TriggerScanner 6-20 700 Series Color Mobile Computer User’s Manual...
Page 154: Ibarcodereadercontrol::queryattribute
The following attributes are not supported on the imager: ITC_RDRATTR_TONE_ENABLE ITC_RDRATTR_VOLUME_LEVEL ITC_RDRATTR_TONE_FREQUENCY ITC_RDRATTR_GOOD_READ_BEEPS_NUMBER ITC_RDRATTR_GOOD_READ_BEEP_DURATION Return Values: A standard status code that indicates success or failure. See Also: IBarCodeReaderControl::CancelReadRequest IBarCodeReaderControl::ControlLED IBarCodeReaderControl::Initialize IBarCodeReaderControl::IssueBeep IBarCodeReaderControl::Read IBarCodeReaderControl::SetAttribute IBarCodeReaderControl::TriggerScanner 700 Series Color Mobile Computer User’s Manual 6-21...
Page 155: Ibarcodereadercontrol::read
If you set a timeout, the call will be blocked until data is received. If data not available, returns quickly. INFINITE Waits until data is available. Return Values: HRESULT that indicates success or failure. 6-22 700 Series Color Mobile Computer User’s Manual...
Page 156 SECTION 6 Scanner Support See Also: IBarCodeReaderControl::CancelReadRequest IBarCodeReaderControl::ControlLED IBarCodeReaderControl::Initialize IBarCodeReaderControl::IssueBeep IBarCodeReaderControl::QueryAttribute IBarCodeReaderControl::SetAttribute IBarCodeReaderControl::TriggerScanner 700 Series Color Mobile Computer User’s Manual 6-23...
Page 157: Ibarcodereadercontrol::setattribute
Includes NULL termination. rgbAttrBuffer [in] Contains data for the attribute to be set. Depending on eAttr, the rgbAttrData will be mapped to the appropriate structure as shown in the table on the next page. 6-24 700 Series Color Mobile Computer User’s Manual...
Page 158 Valid range for S9C: 0–2550 ms (Default: 80). Note: The value is divided by 10 for storage. On retrieval, the scanner rounds the value to the near- est 10 ms, then multiplies the value by 10. 700 Series Color Mobile Computer User’s Manual 6-25...
Page 159 The following attributes are not supported on the imager: ITC_RDRATTR_TONE_ENABLE ITC_RDRATTR_VOLUME_LEVEL ITC_RDRATTR_TONE_FREQUENCY ITC_RDRATTR_GOOD_READ_BEEPS_NUMBER ITC_RDRATTR_GOOD_READ_BEEP_DURATION See Also: IBarCodeReaderControl::CancelReadRequest IBarCodeReaderControl::ControlLED IBarCodeReaderControl::Initialize IBarCodeReaderControl::IssueBeep IBarCodeReaderControl::QueryAttribute IBarCodeReaderControl::Read IBarCodeReaderControl::TriggerScanner 6-26 700 Series Color Mobile Computer User’s Manual...
Page 160: Ibarcodereadercontrol::triggerscanner
That is, in one shot mode, the laser turns off when a label is scanned; in auto-trigger mode, the laser remains on. See Also: IBarCodeReaderControl::CancelReadRequest IBarCodeReaderControl::ControlLED IBarCodeReaderControl::Initialize IBarCodeReaderControl::IssueBeep IBarCodeReaderControl::QueryAttribute IBarCodeReaderControl::Read IBarCodeReaderControl::SetAttribute 700 Series Color Mobile Computer User’s Manual 6-27...
Page 161: Is9Cconfig Functions
Scanner Support SECTION 6 IS9CConfig Functions This interface provides methods to set and retrieve the 700 Series Computer bar code configuration. All supported symbologies are initialized to their defaults when the S9C firmware is loaded. GET/SET functions use enumerations as their parameters. In most enumera- tions, there is an enumerator xx_NO_CHANGE (such as ITC_CODE39_NO_CHANGE), where xx refers to a particular enumeration.
Page 162: Is9Cconfig::getcodabar
Pointer to the DWORD location to receive a number indicating number of bytes in rbgLengthBuff[]: 1 byte for ITC_BARCODE_LENGTH or 3 bytes for ITC_BARCODE_FIXED_LENGTH. Return Values: HRESULT that indicates success or failure. 700 Series Color Mobile Computer User’s Manual 6-29...
Page 163: Is9Cconfig::setcodabar
Parameter Default Valid Range Decoding Not Active ITC_CODABAR_DECODING CLSI Library System Not Active ITC_CODABAR_CLSI Start/Stop Not Transmitted ITC_CODABAR_START_STOP Check Digit Not Used ITC_CODABAR_CHECK_DIGIT Bar Code Length Minimum Length = 6 0x00–0xFE ITC_BC_LENGTH_NO_CHANGE 6-30 700 Series Color Mobile Computer User’s Manual...
Page 164: Codabar Enumerations
ITC_CODABAR_CLSI_ACTIVE = 1, ITC_CODABAR_CLSI_NO_CHANGE = 255 } ITC_CODABAR_CLSI; typedef enum tagCodabarCheckDigit ITC_CODABAR_CHECK_NOTUSED, // Default ITC_CODABAR_CHECK_XMIT, ITC_CODABAR_CHECK_NOTXMIT, ITC_CODABAR_CHECK_NO_CHANGE = 255 } ITC_CODABAR_CHECK_DIGIT; typedef enum tagBarcodeLengthId ITC_BARCODE_LENGTH = 0, ITC_BARCODE_FIXED_LENGTH, ITC_BARCODE_LENGTH_NO_CHANGE = 255 } ITC_BARCODE_LENGTH_ID; 700 Series Color Mobile Computer User’s Manual 6-31...
Page 165 [in] Identifies the Start/Stop option. eSSChars [in] Identifies the Start/Stop character. eCheck [in] Identifies the Check digit. dwLength [in] Identifies the bar code length. Return Values: HRESULT that indicates success or failure. 6-32 700 Series Color Mobile Computer User’s Manual...
Page 166: Code 39 Default Settings
} ITC_CODE39_START_STOP; typedef enum tagCode39StartStopChars ITC_CODE39_SS_CHARS_DOLLARSIGN, ITC_CODE39_SS_CHARS_ASTERISK, // Default ITC_CODE39_SS_CHARS_BOTH, ITC_CODE39_SS_CHARS_NO_CHANGE = 255 } ITC_CODE39_SS_CHARS; typedef enum tagCode39CheckDigit ITC_CODE39_CHECK_NOTUSED, // Default ITC_CODE39_CHECK_MOD43_XMIT, ITC_CODE39_CHECK_MOD43_NOTXMIT, ITC_CODE39_CHECK_FRENCH_CIP_XMIT, ITC_CODE39_CHECK_FRENCH_CIP_NOTXMIT, ITC_CODE39_CHECK_ITALIAN_CPI_XMIT, ITC_CODE39_CHECK_ITALIAN_CPI_NOTXMIT, ITC_CODE39_CHECK_NO_CHANGE = 255 } ITC_CODE39_CHECK_DIGIT; 700 Series Color Mobile Computer User’s Manual 6-33...
Page 167: Code 93 Default Settings
Code 93 Enumerations Use this when the bar code length does not require any change. typedef enum tagCode93Decoding ITC_CODE93_NOTACTIVE = 0, // Default ITC_CODE93_ACTIVE = 1, ITC_CODE93_NO_CHANGE = 255 } ITC_CODE93_DECODING; #define ITC_BC_LENGTH_NO_CHANGE 255. 6-34 700 Series Color Mobile Computer User’s Manual...
Page 168 [in] Identifies the CIP 128. byFNC1 [in] Identifies the FNC1 separator character, usually any ASCII value. dwLength [in] Identifies the bar code length. Return Values: HRESULT that indicates success or failure. 700 Series Color Mobile Computer User’s Manual 6-35...
Page 169: Code 128/Ean 128 Default Settings
Include ]C1 Custom Id Transmitted Z]C1<data> Z<data> Remove ]C1 Custom Id Transmitted Z<data> Z<data> where “X” is the symbology identifier; “Y” is the modifier character; “Z” is the 1 byte symbology identifier 6-36 700 Series Color Mobile Computer User’s Manual...
Page 170 Pointer to the DWORD location to receive a number indicating number of bytes in rbgLengthBuff[]: 1 byte for ITC_BARCODE_LENGTH or 3 bytes for ITC_BARCODE_FIXED_LENGTH. Return Values: HRESULT that indicates success or failure. 700 Series Color Mobile Computer User’s Manual 6-37...
Page 171: Interleaved 2 Of 5 Default Settings
HRESULT that indicates success or failure. Interleaved 2 of 5 Default Settings Parameter Default Valid Range Decoding Not Active ITC_INTERLEAVED2OF5_DECODING Check Digit Not Used ITC_INTERLEAVED2OF5_CHECK_DIGIT Bar Code Length Minimum Length = 6 0x00–0xFE ITC_BC_LENGTH_NO_CHANGE 6-38 700 Series Color Mobile Computer User’s Manual...
Page 172: Interleaved 2 Of 5 Enumerations
ITC_INTERLEAVED2OF5_NO_CHANGE = 255 } ITC_INTERLEAVED2OF5_DECODING; typedef enum tagInterleaved2of5CheckDigit ITC_INTERLEAVED2OF5_CHECK_NOTUSED, // Default ITC_INTERLEAVED2OF5_CHECK_MOD10_XMIT, ITC_INTERLEAVED2OF5_CHECK_MOD10_NOTXMIT, ITC_INTERLEAVED2OF5_CHECK_FRENCH_CIP_XMIT, ITC_INTERLEAVED2OF5_CHECK_FRENCH_CIP_NOTXMIT, ITC_INTERLEAVED2OF5_CHECK_NO_CHANGE = 255 } ITC_INTERLEAVED2OF5_CHECK_DIGIT; typedef enum tagBarcodeLengthId ITC_BARCODE_LENGTH = 0, ITC_BARCODE_FIXED_LENGTH, ITC_BARCODE_LENGTH_NO_CHANGE = 255 } ITC_BARCODE_LENGTH_ID; 700 Series Color Mobile Computer User’s Manual 6-39...
Page 173: Matrix 2 Of 5 Default Settings
ITC_MATRIX2OF5_NOTACTIVE = 0, // Default ITC_MATRIX2OF5_ACTIVE = 1, ITC_MATRIX2OF5_NO_CHANGE = 255 } ITC_MATRIX2OF5_DECODING; #define ITC_BC_LENGTH_NO_CHANGE 255. This definition can be used when the bar code length does not require any change. 6-40 700 Series Color Mobile Computer User’s Manual...
Page 174: Is9Cconfig::getmsi
ITC_MSI_CHECK_MOD10_XMIT, // Default ITC_MSI_CHECK_MOD10_NOTXMIT, ITC_MSI_CHECK_DOUBLEMOD10_XMIT, ITC_MSI_CHECK_DOUBLEMOD10_NOTXMIT, ITC_MSI_CHECK_NO_CHANGE = 255 } ITC_MSI_CHECK_DIGIT; #define ITC_BC_LENGTH_NO_CHANGE 255. This definition can be used when the bar code length does not require any change. 700 Series Color Mobile Computer User’s Manual 6-41...
Page 175 [out] Pointer to the ITC_PDF417_FILE_SIZE location to receive the file size. pePdfChecksum [out] Pointer to the ITC_PDF417_CHECKSUM location to receive the checksum. Return Values: HRESULT that indicates success or failure. 6-42 700 Series Color Mobile Computer User’s Manual...
Page 176: Pdf 417 Default Settings
Not Transmitted ITC_PDF417_SEGMENT_COUNT *Time Stamp Not Transmitted ITC_PDF417_TIME_STAMP *Sender Not Transmitted ITC_PDF417_SENDER *Address Not Transmitted ITC_PDF417_ADDRESSEE *File Size Not Transmitted ITC_PDF417_FILE_SIZE *Check Sum Not Transmitted ITC_PDF417_CHECKSUM * These are Macro PDF Optional Fields. 700 Series Color Mobile Computer User’s Manual 6-43...
Page 177: Pdf 417 Enumerations
ITC_PDF417_FILE_SIZE_NOTXMIT = 0, // Default ITC_PDF417_FILE_SIZE_XMIT = 1, ITC_PDF417_FILE_SIZE_NO_CHANGE = 255 } ITC_PDF417_FILE_SIZE; typedef enum tagPdf417Checksum ITC_PDF417_CHECKSUM_NOTXMIT = 0, // Default ITC_PDF417_CHECKSUM_XMIT = 1, ITC_PDF417_CHECKSUM_NO_CHANGE = 255 } ITC_PDF417_CHECKSUM; 6-44 700 Series Color Mobile Computer User’s Manual...
Page 178: Is9Cconfig::getplessey
ITC_PLESSEY_CHECK_NOTXMIT = 0, // Default ITC_PLESSEY_CHECK_XMIT = 1, ITC_PLESSEY_CHECK_NO_CHANGE = 255 } ITC_PLESSEY_CHECK_DIGIT; #define ITC_BC_LENGTH_NO_CHANGE 255. This definition can be used when the bar code length does not require any change. 700 Series Color Mobile Computer User’s Manual 6-45...
Page 179 Pointer to the DWORD location to receive a number indicating number of bytes in rbgLengthBuff[]: 1 byte for ITC_BARCODE_LENGTH or 3 bytes for ITC_BARCODE_FIXED_LENGTH. Return Values: HRESULT that indicates success or failure. 6-46 700 Series Color Mobile Computer User’s Manual...
Page 180: Standard 2 Of 5 Default Settings
Standard 2 of 5 Default Settings Parameter Default Valid Range Decoding Not Active ITC_STANDARD2OF5_DECODING Format Identicon ITC_STANDARD2OF5_FORMAT (6 Start/Stop bars) Check Digit Not Used ITC_STANDARD2OF5_CHECK_DIGIT Bar Code Length Minimum Length = 6 0x00–0xFE ITC_BC_LENGTH_NO_CHANGE 700 Series Color Mobile Computer User’s Manual 6-47...
Page 181: Standard 2 Of 5 Enumerations
ITC_STANDARD2OF5_FORMAT_IDENTICON, // Default ITC_STANDARD2OF5_FORMAT_COMPUTER_IDENTICS, ITC_STANDARD2OF5_FORMAT_NO_CHANGE = 255 } ITC_STANDARD2OF5_FORMAT; typedef enum tagStandard2of5CheckDigit ITC_STANDARD2OF5_CHECK_NOTUSED, // Default ITC_STANDARD2OF5_CHECK_XMIT, ITC_STANDARD2OF5_CHECK_NOTXMIT, ITC_STANDARD2OF5_CHECK_NO_CHANGE = 255 } ITC_STANDARD2OF5_CHECK_DIGIT; typedef enum tagBarcodeLengthId ITC_BARCODE_LENGTH = 0, ITC_BARCODE_FIXED_LENGTH, ITC_BARCODE_LENGTH_NO_CHANGE = 255 } ITC_BARCODE_LENGTH_ID; 6-48 700 Series Color Mobile Computer User’s Manual...
Page 182: Is9Cconfig::gettelepen
ASCII ITC_TELEPEN_FORMAT Telepen Enumerations typedef enum tagTelepenDecoding ITC_TELEPEN_NOTACTIVE = 0, // Default ITC_TELEPEN_ACTIVE = 1, ITC_TELEPEN_NO_CHANGE = 255 } ITC_TELEPEN_DECODING; typedef enum tagTelepenDecoding ITC_TELEPEN_FORMAT_ASCII, // Default ITC_TELEPEN_FORMAT_NUMERIC, ITC_TELEPEN_FORMAT_NO_CHANGE = 255 } ITC_TELEPEN_FORMAT; 700 Series Color Mobile Computer User’s Manual 6-49...
Page 183: Is9Cconfig::getupcean
EAN-8 check digit. ean13Check [out] Pointer to the ITC_EAN13_CHECK_DIGIT location to receive the EAN-13 check digit. upcANumSystem [out] Pointer to the ITC_UPCA_NUMBER_SYSTEM location to receive the UPC-A number system. 6-50 700 Series Color Mobile Computer User’s Manual...
Page 184: Is9Cconfig::setupcean
[in] Identifies the UPC-A number system. upcENumSystem [in] Identifies the UPC-E number system. upcAReencode [in] Identifies the UPC-A reencoding. upcEReencode [in] Identifies the UPC-E reencoding. ean8Reencode [in] Identifies the EAN-8 reencoding. 700 Series Color Mobile Computer User’s Manual 6-51...
Page 185: Upc/Ean Default Settings
ITC_EAN8_DEACTIVATE, ITC_EAN8_ACTIVATE, // Default ITC_EAN8_NO_CHANGE = 255 } ITC_EAN8_SELECT; typedef enum tagEan13Select ITC_EAN13_DEACTIVATE, ITC_EAN13_ACTIVATE, // Default ITC_EAN13_NO_CHANGE = 255 } ITC_EAN13_SELECT; typedef enum tagUpcEanAddonDigits ITC_UPCEAN_ADDON_NOT_REQUIRED, // Default ITC_UPCEAN_ADDON_REQUIRED, ITC_UPCEAN_ADDON_NO_CHANGE = 255 6-52 700 Series Color Mobile Computer User’s Manual...
Page 186 ITC_UPCA_XMIT_AS_EAN13, // Default ITC_UPCA_XMIT_AS_UPCA, ITC_UPCA_XMIT_NO_CHANGE = 255 } ITC_UPCA_REENCODE; typedef enum tagUpcEReencode ITC_UPCE_XMIT_AS_UPCE, // Default ITC_UPCE_XMIT_AS_UPCA, ITC_UPCE_XMIT_NO_CHANGE = 255 } ITC_UPCE_REENCODE; typedef enum tagEan8Reencode ITC_EAN8_XMIT_AS_EAN8, //Default ITC_EAN8_XMIT_AS_EAN13, ITC_EAN8_XMIT_NO_CHANGE = 255 } ITC_EAN8_REENCODE; 700 Series Color Mobile Computer User’s Manual 6-53...
Page 187: Is9Cconfig2 Functions
IS9CConfig2 Functions This interface is derived from the IS9CConfig interface and provides additional methods that can be used to set and retrieve the 700 Series Computer’s bar code configuration. All supported symbologies are initialized to their defaults when the S9C firmware is loaded.
Page 188: Code 11 Default Settings
ITC_CODE11_CHK_VERIFY_ONEDIGIT = 1, ITC_CODE11_CHK_VERIFY_TWODIGIT = 2, // Default ITC_CODE11_CHK_VERIFY_NO_CHANGE = 255 } ITC_CODE11_CHECK_VERIFICATION; typedef enum tagCode11CheckDigit ITC_CODE11_CHECK_NOTXMIT = 0, // Default ITC_CODE11_CHECK_XMIT = 1, ITC_CODE11_CHECK_NO_CHANGE = 255 } ITC_CODE11_CHECK_DIGIT; 700 Series Color Mobile Computer User’s Manual 6-55...
Page 189: Is9Cconfig2::Getcustomsymids
[in] Identifies the number of symbology identifiers to update in the pStructSymIdPair buffer. Return Values: HRESULT that indicates success or failure. 6-56 700 Series Color Mobile Computer User’s Manual...
Page 190: Custom Identifier Assignments
EAN-8 0xFF 0x00–0xFF EAN-13 0x00–0xFF Interleaved 2 of 5 0x00–0xFF Matrix 2 of 5 0x00–0xFF 0x00–0xFF PDF 417 0x00–0xFF Plessey 0x00–0xFF Standard 2 of 5 0x00–0xFF Telepen 0x00–0xFF UPC-A 0x00–0xFF UPC-E 0x00–0xFF 700 Series Color Mobile Computer User’s Manual 6-57...
Page 191: Is9Cconfig2::Setglobalamble
Only one setting can be updated at a time. rgbBuffer [in] Contains the buffer for the postamble or preamble setting to be updated. dwBufferSize [in] Identifies number of bytes in rgbBuffer. Return Values: HRESULT that indicates success or failure. 6-58 700 Series Color Mobile Computer User’s Manual...
Page 192: Postamble And Preamble Defaults
HRESULT that indicates success or failure. PDF 417 Extended: Micro PDF 417 Default Settings Parameter Default Valid Range Decoding Not Active ITC_MICRO_PDF417_DECODING Code 128 Emulation Not Active ITC_MICRO_PDF417_CODE128_EMULATION * These are Micro PDF 417 parameters. 700 Series Color Mobile Computer User’s Manual 6-59...
Page 193: Is9Cconfig2::Getsymidxmit
Example of the transmitted label: [preamble] [Custom ID] <data> [postamble] Activate AIM symbology identifier transmission for all ITC_ID_XMIT_AIM = 2 symbologies. Example of the transmitted label: [preamble] [AIM symbology ID] <data> [postamble] }ITC_SYMBOLOGY_ID_XMIT; 6-60 700 Series Color Mobile Computer User’s Manual...
Page 194: Is9Cconfig3 Functions
This enables or disables the QRCode symbology. Parameter Description 0x55 Disable this symbology. 0x55 Enable this symbology. Datamatrix Symbology This enables or disables the Datamatrix symbology. Parameter Description 0x54 Disable this symbology. 0x54 Enable this symbology. 700 Series Color Mobile Computer User’s Manual 6-61...
Page 195: Iscp::getconfig
[in] Number of bytes in rgbCommandBuff. rgbReplyBuff [in, out, size_is] Results of request in array of bytes. dwReplyBuffMaxSize [in] Maximum size of rgbReplyBuff. pdwReplyBuffSize [in, out] Number of bytes placed in rgbReplyBuff. 6-62 700 Series Color Mobile Computer User’s Manual...
Page 196: Aim Symbology Id Defaults
Interpretation (data characters 92 are not doubled). Code 128 emulation: implied FNC1 in first position. Code 128 emulation: implied FNC1 after initial letter or pair of digits. Code 128 emulation: no implied FNC1. 700 Series Color Mobile Computer User’s Manual 6-63...
Page 197 Combined data packet comprising 13 digits from EAN-13, UPC-A, or UPC-E symbol and 2 or 5 digits from add-on symbol. EAN-8 data packet IMPORTANT: The “symbology_id” character letter must be uppercase for the above definitions. 6-64 700 Series Color Mobile Computer User’s Manual...
Page 198: Iimage Interface
Width of signature capture image region in intelligent bar code units. uiHeight Height of the signature capture image region in intelligent bar code units. iResolution Number of pixels per intelligent bar code unit. 700 Series Color Mobile Computer User’s Manual 6-65...
Page 199 A bar code has not yet been decoded or the last bar code decoded was not a signature capture symbology. ITC_IMGBUFF_TOO_SMALL_E pImgBuffer is too small to contain the signature captured image. ITC_INV_PARAMETER_E One of the parameters is invalid. S_DEVICE_NOT_OPENED_E The device had not been opened. 6-66 700 Series Color Mobile Computer User’s Manual...
Page 200: Iimage::readsigcapfile
A bar code has not yet been decoded or the last bar code decoded was not a signature capture symbology. ITC_FILE_OPEN_E The file could not be opened. ITC_INV_PARAMETER_E One of the parameters is invalid. S_DEVICE_NOT_OPENED_E The device had not been opened. 700 Series Color Mobile Computer User’s Manual 6-67...
Page 201: Iimage::readimage
ITC_TIMEOUT_E Timeout. ITC_INV_PARAMETER_E One of the parameters is invalid. S_DEVICE_NOT_OPENED_E The device had not been opened. Remarks: The image is returned in pImgBuffer in the caller specified format. 6-68 700 Series Color Mobile Computer User’s Manual...
Page 202: Iimage::stop
Status code indicating success or failure as follows: S_OK Imager started. S_IMG_NOT_PRESENT_E The unit does not contain an imager. S_DEVICE_NOT_OPENED_E The device had not been opened. Remarks: This function stops the image continuously capturing images. 700 Series Color Mobile Computer User’s Manual 6-69...
Page 203: Iimage::open
S_OK Imager closed. S_DEVICE_NOT_OPENED_E The device had not been opened. Remarks: This function releases the imager device so that other applications can open it. An IImage::Release() will also close the imager device. 6-70 700 Series Color Mobile Computer User’s Manual...
Page 204 Scanner Support Data Collection Configuration Scanner settings for the 700 Series Computer can be configured via the Data Collection control panel applet. From the 700 Series Computer, tap Start → Settings → the System tab → the Data Collection icon. See Appendix A, “Control Panel Applets”...
Page 205 Scanner Support SECTION 6 6-72 700 Series Color Mobile Computer User’s Manual...
Page 206: Creating Cab Files
" " " " " " " " The following programming information pertains to the 700 Series Color Mobile Computer: Creating CAB Files " FTP Server (page 7-12) " Full Screen (page 7-19) " Kernel I/O control functions (page 7-20) "...
Page 207: Creating An .Inf File
String consisting of letters, digits, or other printable characters. Enclose value in double quotation marks ““”” if the corresponding string key is used in an item that requires double quotation marks. No string_keys is okay. EXAMPLE: [Strings] reg_path = Software\Microsoft\My Test App 700 Series Color Mobile Computer User’s Manual...
Page 208: Cedevice]
BuildMin. BuildMax: build_number Numeric value returned by OSVERSIONINFO.dwBuildNumber. The .CAB file is valid for the currently connected device if the version of this device is less than or equal to BuildMax. 700 Series Color Mobile Computer User’s Manual...
Page 209: Defaultinstall]
During installation, if installation on the device fails to call the file’s exported DllRegisterServer function, the file’s exported DllUnregisterServer function will not be called during removal. EXAMPLE: [DefaultInstall] AddReg = RegSettings.All CEShortcuts = Shortcuts.All 700 Series Color Mobile Computer User’s Manual...
Page 210: Sourcedisknames]
; Required section [SourceDisksFiles] begin.wav = 1 end.wav = 1 sample.hlp = 1 [SourceDisksFiles.SH3] ; Uses the SourceDisksNames.SH3 identification of 2. sample.exe = 2 [SourceDisksFiles.MIPS] ; Uses the SourceDisksNames.MIPS identification of 2. sample.exe = 2 700 Series Color Mobile Computer User’s Manual...
Page 211 The source_filename parameter is optional if it is the same as destination_filename. copyfile_list_section: flags The numeric value that specifies an action to be done while copying files. The table on the next page shows values supported by Windows CE. 700 Series Color Mobile Computer User’s Manual...
Page 212: Addreg]
0x hexadecimal prefix. FLG_ADDREG_TYPE_DWORD 0x00010001 REG_DWORD data type. The noncompatible format in the Win32 Setup .INF documentation is supported. 700 Series Color Mobile Computer User’s Manual...
Page 213: Ceshortcuts]
; Required section 1 = ,“App files” ,,c:\appsoft\... 2 = ,”Font files” ,,c:\WinNT\Fonts 3 = ,”CE Tools” ,,c:\windows ce tools\wce212\6110ie\mfc\lib\x86 [SourceDisksFiles] ; Required section rpm.exe = 1,C:\Appsoft\program\wce212\WCEX86Rel6110 wcestart.ini = 1 rpmce212.ini = 1 700 Series Color Mobile Computer User’s Manual...
Page 214 ; Uses the path in DestinationDirs. ;Sample App,0,sample.exe,%InstallDir% ; The path is explicitly specified. [Files.App] rpm.exe,,,0 rpm.ini,rpmce212.ini,,0 mfcce212.dll,,,0 olece212.dll,,,0 olece211.dll,,,0 rdm45wce.dll,,,0 picfmt.dll,,,0 fmtctrl.dll,,,0 ugrid.dll,,,0 simple.dll,,,0 psink.dll,,,0 pslpwce.dll,,,0 npcpport.dll,,,0 ;dexcom.dll,,,0 [Files.DataBase] rpmdata.dbd,,,0 [Files.Fonts] tahoma.ttf,,,0 [Files.BitMaps] 700 Series Color Mobile Computer User’s Manual...
Page 215: Using Installation Functions In Setup.dll
" NOTE: Use [DefaultInstall] → CESelfRegister (page 7-4) in the .INF file to point to SETUP.DLL. 7-10 700 Series Color Mobile Computer User’s Manual...
Page 216: Creating Cab Files With Cab Wizard
Do not create a .CAB file with the MAKECAB.EXE file included with Win- " dows CE. You must use CABWIZ.EXE, which uses MAKECAB.EXE to gen- erate the .CAB files for Windows CE. Do not set the read-only attribute for .CAB files. " 700 Series Color Mobile Computer User’s Manual 7-11...
Page 217: Ftp Server
Sets the device name. Used by Intermec management software. - Fvalue Disables the default Intermec account. A value of “0” disables the account. Default is “1”. " NOTE: Disabling the default account without providing a working access control list on the server will result in a device that will not accept any FTP connections.
Page 218 Terminates session. RETR Retrieves a file. Removes a directory. RNFR Specifies rename--from file name. RNTO Specifies rename--to file name. STOR Stores a file. SYST Shows the operating system type of server system. 700 Series Color Mobile Computer User’s Manual 7-13...
Page 219 Usage: QUOTE SITE BOOT [WARM | COLD] COPY Copies a file from one location to another. (SITE COPY) Usage: QUOTE SITE COPY [source] [destination] EXAMPLE: QUOTE SITE COPY ‘\Storage Card\one.dat’ ‘\Storage Card\two.dat’ 7-14 700 Series Color Mobile Computer User’s Manual...
Page 220 The banner returned in the parenthetical portion of its greeting shows the ver- sion number of the FTP Server as well as the MAC address, serial number and OS of the machine hosting the server. 700 Series Color Mobile Computer User’s Manual 7-15...
Page 221: Stopping The Ftp Server From Your Application
FTP Server will encrypt this file to keep the information safe from unauthorized users. This file is encrypted when the FTP Server is started so a file that is placed onto the 700 Series Computer after the FTP Server starts will require a restart of the FTP Server to take effect.
Page 222: Autostart Ftp
Programming Autostart FTP This automatically starts the FTP Server (FTPDCE.EXE) when the 700 Series Computer is powered on. This is provided with the NDISTRAY program, which displays the popup menu that currently allows you to load and unload the net- work drivers.
Page 223 5. Load the FTP Server, establish a connection, then suspend and resume. The server should still be running, but the FTP connection to the client should be dropped. 7-18 700 Series Color Mobile Computer User’s Manual...
Page 224: Full Screen
Make changes to the registry to configure the device. " Should you want your 700 Series Computer to display a full screen, keep in mind that your computer is Pocket-PC certified by Microsoft Corporation. Check out resources on programming for the Pocket PC, using the following links. These instructions give full instructions on how to display full screen.
Page 225: Kernel I/O Controls
If SPI_GETPLATFORMTYPE is specified in lpInBuf, then the “PocketPC\0” Unicode string is returned. If SPI_GETOEMINFO is specified in lpInBuf, then the “Intermec 700\0” Unicode string is returned. nOutBufSize The size of lpOutBuf in bytes. Must be large enough to hold the string returned.
Page 226: Ioctl_Hal_Itc_Read_Parm
This IOCTL returns the device’s display type. One byte is returned in the buffer pointed to by the lpOutBuffer parameter. ITC_NVPARM_EDG_IP This IOCTL returns the device Ethernet debug IP address. Four bytes are returned in the buffer pointed to by the lpOutBuffer parameter. 700 Series Color Mobile Computer User’s Manual 7-21...
Page 227 This IOCTL reads the state of the WAN ring indicator flag. A BOOLEAN DWORD is returned in the buffer pointed to by lpOutBuffer that indicates the polarity of the WAN RI signal. TRUE indicates active high. FALSE indicates active low. 7-22 700 Series Color Mobile Computer User’s Manual...
Page 228 WAN radio hardware installed. The maximum possible value returned is ITC_DEVID_WANRADIO_MAX. The current definitions are: ITC_DEVID_WANRADIO_NONE No WAN radio installed. ITC_DEVID_WANRADIO_SIERRA_SB555 CDMA Sierra Wireless radio. ITC_DEVID_WANRADIO_XIRCOM_GEM3503 GSM/GPRS Intel (Xircom) radio. ITC_DEVID_WANRADIO_SIEMENS_MC45 GSM/GPRS Siemens radio. 700 Series Color Mobile Computer User’s Manual 7-23...
Page 229 A BOOLEAN DWORD is returned in the buffer pointed to by lpOutBuffer. TRUE indicates that the SIM card protection software is installed. FALSE indicates that no SIM card protection software is installed. 7-24 700 Series Color Mobile Computer User’s Manual...
Page 230: Ioctl_Hal_Itc_Write_Sysparm
“modem” or “serial“ positions. lpOutBuf must point to a buffer that contains a byte value of either DOCK_MODEM or DOCK_SERIAL as defined in OEMIOCTL.H; the value specifies the position the switch is to be set. 700 Series Color Mobile Computer User’s Manual 7-25...
Page 231 This IOCTL sets the threshold for the frontlight ambient sensor. This can be a value from 0 (always off) to 255. lpOutBuf must point to a buff- er that contains a byte value of the desired setting. 7-26 700 Series Color Mobile Computer User’s Manual...
Page 232: Ioctl_Hal_Get_Deviceid
The number of bytes returned by the function. Return Values: Returns TRUE if function succeeds. Returns FALSE if the function fails. GetLastError() may be used to get the extended error value. 700 Series Color Mobile Computer User’s Manual 7-27...
Page 233: Ioctl_Hal_Get_Oal_Verinfo
The size of VERSIONINFO in bytes. lpBytesReturned Returns sizeof(PVERSIONINFO). Return Values: Returns TRUE if function succeeds. Returns FALSE if the function fails. GetLastError() may be used to get the extended error value. 7-28 700 Series Color Mobile Computer User’s Manual...
Page 234 The size of VERSIONINFO in bytes. lpBytesReturned The number of bytes returned to lpOutBuf. Return Values: Returns TRUE if function succeeds. Returns FALSE if the function fails. GetLastError() may be used to get the extended error value. 700 Series Color Mobile Computer User’s Manual 7-29...
Page 235: Ioctl_Hal_Coldboot
DWORD nInBufSize, LPVOID lpOutBuf, DWORD nOutBufSize, LPDWORD lpBytesReturned ); Parameters: lpInBuf Should be set to NULL. lpInBufSize Should be set to zero. lpOutBuf Should be NULL. nOutBufSize Should be zero. Return Values: None. 7-30 700 Series Color Mobile Computer User’s Manual...
Page 236: Ioctl_Hal_Get_Reset_Info
The number of bytes returned by the function. Return Values: Returns TRUE if function succeeds. Returns FALSE if the function fails. GetLastError() may be used to get the extended error value. 700 Series Color Mobile Computer User’s Manual 7-31...
Page 237 DWORD nInBufSize, LPVOID lpOutBuf, DWORD nOutBufSize, LPDWORD lpBytesReturned ); Parameters: lpInBuf Should be set to NULL. lpInBufSize Should be set to zero. lpOutBuf Should be NULL. nOutBufSize Should be zero. Return Values: None. 7-32 700 Series Color Mobile Computer User’s Manual...
Page 238: Ioctl_Processor_Information
Should be set to sizeof(PROCESSOR_INFO) in bytes. lpBytesReturned Returns sizeof(PROCESSOR_INFO); Return Values: Returns TRUE if function succeeds. Returns FALSE if the function fails. GetLastError() may be used to get the extended error value. 700 Series Color Mobile Computer User’s Manual 7-33...
Page 239 Should be set to 0. lpBytesReturned Returns sizeof(PROCESSOR_INFO); Return Values: Returns TRUE if function succeeds. Returns FALSE if the function fails. GetLastError() may be used to get the extended error value. 7-34 700 Series Color Mobile Computer User’s Manual...
Page 240: Ioctl_Hal_Reboot
IOCTL_HAL_COLDBOOT Invoking the KernelIOControl function with IOCTL_HAL_COLDBOOT forces a cold reboot. This resets the 700 Series Computer and reloads Windows CE as if a power-up had been performed. The contents of the Windows CE RAM-based ob- ject store are discarded. See page 7-30.
Page 241: Remapping The Keypad
Use caution when remapping the keypad. Improper remapping may render the keypad unus- able. Data within the 700 Series Computer could also be lost, should any problems occur. Applications have the ability to remap keys on the 700 Color Keypad. This will allow applications to enable keys that would otherwise not be available, such as the [F1] function key.
Page 242: How Key Values Are Stored In Registry
Do not remap scan codes 0x01, 0x41, 0x42, 0x43, 0x44. Remapping these scan codes could render your 700 Series Computer unusable until a cold-boot is performed. If you wish to disable a certain key, remap its scan code to 0x00.
Page 243: Scan Codes
0x1A 0x1B 0x1C ENTER 0x1D 0x1E None 0x1F–0x40 Charge Detect 0x41 LCD Frontlight 0x42 Ambient Light 0x42 Threshold Crossed 0x42 Headset Detected 0x43 Keypad Backlight 0x44 Ambient Light 0x44 Threshold Crossed 0x44 7-38 700 Series Color Mobile Computer User’s Manual...
Page 244: Sample View Of Registry Keys
[HKEY_LOCAL_MACHINE\HARDWARE\DEVICEMAP\KEYBD] ”ResumeMask”=dword:7 ”Vkey”=hex: 00,00,0B,05,02,03,C1,07,04,03,BE,00,34,00,00,00,\ 25,00,00,00,08,00,03,02,00,00,1B,00,28,00,31,00,\ 37,00,01,02,00,00,26,00,27,00,32,00,38,00,30,00,\ 35,00,00,00,01,03,33,00,39,00,0D,00,36,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,07,05,01,05,03,05,02,05 ”VkeyGold”=hex: 00,00,0B,05,02,03,C1,07,04,03,BE,00,34,00,00,00,\ 09,01,00,00,BF,00,03,02,00,00,BD,00,75,00,72,00,\ 21,00,01,02,00,00,76,00,09,00,73,00,38,01,5B,00,\ 35,00,00,00,BB,01,09,05,22,00,32,01,36,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,07,05,01,05,03,05,02,05 ”VkeyAlpha”=hex: 00,00,0B,05,02,03,C1,07,04,03,BE,00,47,00,00,00,\ 25,00,00,00,08,00,03,02,00,00,1B,00,28,00,02,02,\ 50,00,01,02,00,00,26,00,27,00,41,00,54,00,20,00,\ 4A,00,00,00,01,03,44,00,57,00,0D,00,4D,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,\ 00,00,07,05,01,05,03,05,02,05 700 Series Color Mobile Computer User’s Manual 7-39...
Page 245 Programming SECTION 7 7-40 700 Series Color Mobile Computer User’s Manual...
Page 246: Configuration Parameters
" " This appendix contains information about the Data Collection, SNMP, and User Information Control Panel applets that may be on your 700 Series Color Mobile Computer. SNMP and Data Collection settings that can appear under Settings are depen- dent on what hardware configuration is done for each 700 Series Computer at the time of shipment.
Page 247: Changing A Parameter Setting
Syntax lists the two-character code for the parameter, if the parameter is configurable by scanning a bar code or by sending parameters through a network. Both Syntax and Options list acceptable values for the parame- ter. Default settings are noted in italic. 700 Series Color Mobile Computer User’s Manual...
Page 248: Data Collection Control Panel Applet
" NOTE: Icons are shown to the left. To access the settings from the 700 Series Computer, tap Start → Settings → the System tab → the Data Collection icon to access its control panel applet. Use the left and right arrows to scroll through the tabs along the bottom of the control panel applet, then tap a tab to access its menus.
Page 249: Symbologies
Control Panel Applets APPENDIX A Symbologies You can change bar code symbology parameter settings in your 700 Series Computer via the Data Collection control panel applet. The following parameters are for bar code symbologies. Additional information about the more common bar code symbologies are in Appendix C, “Bar Code Symbologies.” Note that these parameters are listed in the order of their appearance within this tab.
Page 250 Italian CPI not transmitted Bar code length Any length (default) Minimum length Minimum length 000–254 Minimum length 1–254 (6) " NOTE: If “1” is selected for Bar code length, then Minimum length is entered. 700 Series Color Mobile Computer User’s Manual...
Page 251: Standard 2 Of
If “1” is selected for Bar code length, then Minimum length is entered. If “2” is selected for Bar code length, then Fixed length 1, Fixed length 2, or Fixed length 3 is entered. 700 Series Color Mobile Computer User’s Manual...
Page 252: Codabar
If “1” is selected for Bar code length, then Minimum length is entered. If “2” is selected for Bar code length, then Fixed length 1, Fixed length 2, or Fixed length 3 is entered. 700 Series Color Mobile Computer User’s Manual...
Page 253: Upc/Ean
0 UPC E transmitted as UPC E (default) 1 UPC E transmitted as UPC A EAN 8 re-encoding 0 EAN 8 transmitted as EAN 8 (default) 1 EAN 8 transmitted as EAN 13 700 Series Color Mobile Computer User’s Manual...
Page 254: Code 93 Length
Options (active only if Code 93 is active): Bar code length Any length (default) Minimum length Minimum length 001–254 Minimum length 1–254 (6) " NOTE: If “1” is selected for Bar code length, then Minimum length is entered. 700 Series Color Mobile Computer User’s Manual...
Page 255: Code 128
Tap the Code 128 parameter, then select an option to change this parameter setting. Tap (+) to expand either the Code 128 Options or Code 128 FNC1 character parameters. SNMP OID: 1.3.6.1.4.1.1963.15.3.3.1.1.9.1 Options: Not active (default) Active A-10 700 Series Color Mobile Computer User’s Manual...
Page 256: Code 128 Options
Options: EAN 128 ]C1 Identifier Remove Include (default) CIP 128 French Pharmaceutical Not active (default) Active Bar code length Any length (default) Minimum length Minimum length 001–254 Minimum length 1–254 (6) 700 Series Color Mobile Computer User’s Manual A-11...
Page 257: Code 128 Fnc1 Character
Tap (+) to expand the Code 128 parameter, then type the ASCII characters to be set for the Code 128 FNC1 character parameter. SNMP OID: 1.3.6.1.4.1.1963.15.3.3.1.1.21.1 Options: Any ASCII character (default is the GS function character — ID hex) A-12 700 Series Color Mobile Computer User’s Manual...
Page 258: Plessey
Bar code length Any length (default) Minimum length Minimum length 001–254 Minimum bar code length 1–254 (6) " NOTE: If “1” is selected for Bar code length, then Minimum length is entered. 700 Series Color Mobile Computer User’s Manual A-13...
Page 259 Double Mod 10 not transmitted Bar code length Any length Minimum length (default) Minimum length 001–254 Minimum length 1–254 (6) " NOTE: If “1” is selected for Bar code length, then Minimum length is entered. A-14 700 Series Color Mobile Computer User’s Manual...
Page 260 Tap the PDF 417 parameter, then select an option to change this parameter setting. Tap (+) to access either the Macro PDF Options parameter or the Micro PDF 417 parameter. SNMP OID: 1.3.6.1.4.1.1963.15.3.3.1.1.17.1 Options: Not active Active (default) 700 Series Color Mobile Computer User’s Manual A-15...
Page 261: Macro Pdf
Macro PDF Macro PDF is used when a long message requires more than one PDF 417 label. Note that this is not available when you use an imager with your 700 Series Com- puter. Select Buffered to store a multi-label PDF 417 message in the Sabre buff- "...
Page 262: Micro Pdf 417
417 (page A-15). A limited set of symbology sizes is available, together with a fixed level of error correction for each symbology size. Note that this is not avail- able when you use an imager with your 700 Series Computer. Action:...
Page 263: Interleaved 2 Of 5
Interleaved 2 of 5 (I 2 of 5) is a high--density, self--checking, continuous, numeric symbology used mainly in inventory distribution and the automobile industry. " NOTE: An Interleaved 2 of 5 bar code label must be at least three characters long for the 700 Series Computer to scan and decode correctly. Action:...
Page 264: Matrix 2 Of 5
Matrix 2 of 5 Matrix 2 of 5 is a numerical symbology. Note that this is not available when you use an imager with your 700 Series Computer. Action: Tap (+) to expand the Matrix 2 of 5 parameter, select the setting to be changed, then tap an option to change this setting or select an option from the drop-down list.
Page 265: Telepen
APPENDIX A Telepen Telepen is an alphanumeric, case-sensitive, full ASCII symbology. Note that this is not available when you use an imager with your 700 Series Computer. Action: Tap (+) to expand the Telepen parameter, select the setting to be changed, then tap an option to change this setting.
Page 266 Code 11 is a high density, discrete numeric symbology that is extensively used in labeling telecommunications components and equipment. Note that this is not available when you use an imager with your 700 Series Computer. Action: Tap (+) to expand the Code 11 parameter, select the setting to be changed, then tap an option to change this setting.
Page 267 Kanji character set. It can encode up to 2509 numeric or 1520 alphanumeric characters and offers three levels of error detection. Note that this is not avail- able when you use a laser scanner with your 700 Series Computer. Action:...
Page 268 Maximum capacity of a symbol is 2335 alphanumeric characters, 1556 8-bit byte characters or 3116 numeric digits. Note that this is not available when you use a laser scanner with your 700 Series Computer. Action: Tap (+) to expand the Datamatrix parameter, select the setting to be changed, then tap an option to change this setting or select an option from the drop-down list.
Page 269: Symbology Id
APPENDIX A Symbology Options To access the settings from the 700 Series Computer, tap Start → Settings → the System tab → the Data Collection icon to access its control panel applet. Use the right and left arrows to scroll to the Symbology Options tab, then tap this tab to access its parameters.
Page 270: Code 128 User Id
If “1” was selected in the Symbology ID parameter, you can set your own ASCII character to identify Code 39 bar code data. Note that this is not available when you use an imager with your 700 Series Computer. Action: Tap (+) to expand the Symbology ID parameter, select the Code 39 user ID parameter, then enter a user ID value to change this parameter setting.
Page 271: Interleaved 2 Of 5 User Id
If “1” was selected in the Symbology ID parameter, you can set your own ASCII character to identify Interleaved 2 of 5 bar code data. Note that this is not avail- able when you use an imager with your 700 Series Computer. Action:...
Page 272: Plessey User Id
If “1” was selected in the Symbology ID parameter, you can set your own ASCII character to identify UPC-A (Universal Product Code) bar code data. Note that this is not available when you use an imager with your 700 Series Computer. Action: Tap (+) to expand the Symbology ID parameter, select the UPC A user ID parameter, then enter a user ID value to change this parameter setting.
Page 273: Telepen User Id
If “1” was selected in the Symbology ID parameter, you can set your own ASCII character to identify EAN-13 (European Article Numbering) bar code data. Note that this is not available when you use an imager with your 700 Series Computer. Action: Tap (+) to expand the Symbology ID parameter, select the EAN 13 user ID parameter, then enter a user ID value to change this parameter setting.
Page 274 If “1” was selected in the Symbology ID parameter, you can set your own ASCII character to identify Code 11 bar code data. Note that this is not available when you use an imager with your 700 Series Computer. Action: Tap (+) to expand the Symbology ID parameter, select the Code 11 user ID parameter, then enter a user ID value to change this parameter setting.
Page 275: Prefix
Tap the Prefix parameter, then enter a prefix value to change this parameter setting. SNMP OID: 1.3.6.1.4.1.1963.15.3.3.4.1.29.1 Options: Acceptable values are up to 20 ASCII characters. Embedded null (<NUL >) characters are not allowed. Default is no characters (disabled). A-30 700 Series Color Mobile Computer User’s Manual...
Page 276 Tap the Suffix parameter, then enter a suffix value to change this parameter setting. SNMP OID: 1.3.6.1.4.1.1963.15.3.3.4.1.30.1 Options: Acceptable values are up to 20 ASCII characters. Embedded null (<NUL >) characters are not allowed. Default is no characters (disabled). 700 Series Color Mobile Computer User’s Manual A-31...
Page 277: Beeper Volume
APPENDIX A Beeper/LED/Buttons To access the settings from the 700 Series Computer, tap Start → Settings → the System tab → the Data Collection icon to access its control panel applet. Use the right and left arrows to scroll to the Beeper/LED/Buttons tab, then tap this tab to access its parameters.
Page 278: Beeper Frequency
Control Panel Applets Beeper Frequency Sets the frequency for the good read beep. Note that this is not available when you use an imager with your 700 Series Computer. Action: Tap the Beeper frequency parameter, then enter a frequency value to change this parameter setting.
Page 279: Good Read Beeps
Good Read Beeps Sets the number of good read beeps. Note that this is not available when you use an imager with your 700 Series Computer. Action: Tap the Good read beeps parameter, then select an option to change this parameter setting.
Page 280: Good Read Beep Duration
Good Read Beep Duration Sets the duration of the good read beep. Note that this is not available when you use an imager with your 700 Series Computer. Action: Tap the Good read beep duration parameter, then enter a duration value to change this parameter setting.
Page 281: Record Button
APPENDIX A Record Button This allows the configuration of the left scan button on the 700 Series Computer to either activate the scanner or the Record feature via a Pocket PC application. See Section 2, “Pocket PC 2002,” for more information about recording a message.
Page 282: Virtual Wedge
Control Panel Applets Virtual Wedge To access the settings from the 700 Series Computer, tap Start → Settings → the System tab → the Data Collection icon to access its control panel applet. Use the right and left arrows to scroll to the Virtual Wedge tab, then tap this tab to access its parameters.
Page 283: Preamble
AD command with quotes. If you do not use quotes as described here, the 700 Series Computer will interpret the char- acters as another configuration command. See the following example:...
Page 284 AE command with quotes. If you do not use quotes as described here, the 700 Series Computer will interpret the char- acters as another configuration command. See the following example:...
Page 285 APPENDIX A Grid Sets the virtual wedge grid, which filters the data coming from this 700 Series Computer. The data server supports data filtering, which allows you to selective- ly send scanned data. The virtual wedge grid is similar to the “format” argu- ment of the C Runtime Library scan function.
Page 286: Code
Tap the Code Page parameter, then select an option to change this parameter setting. SNMP OID: 1.3.6.1.4.1.1963.15.3.2.1.1.6.1 Options: The only acceptable value for the code page parameter is “1252,” which is the default. 700 Series Color Mobile Computer User’s Manual A-41...
Page 287 Simple Network Management Protocol (SNMP) parameters include identification information, security encryption, security community strings, and traps. To access the settings from the 700 Series Computer, tap Start → Settings → the System tab → the SNMP icon to access its control panel applet.
Page 288: Read Only Community
Control Panel Applets Security To access the settings from the 700 Series Computer, tap Start → Settings → the System tab → the SNMP icon → the Security tab to access its parameters. The following are parameters that affect encryption and community strings.
Page 289: Read/Write Community
Read/Write Community Sets the read/write community string, which is required for processing of SNMP set requests by this 700 Series Computer. An SNMP packet with this name as the community string will also process SNMP get and next requests. Action: Tap the Read/Write Community parameter, then enter a community string to change this parameter setting.
Page 290: Read Encryption
Tap the Read Encryption parameter, then select an option to change this parameter setting. SNMP OID: 1.3.6.1.4.1.1963.10.5.1.4.0 Options: SNMP get and get next packets must be encrypted Off SNMP packets do not have to be encrypted (default) 700 Series Color Mobile Computer User’s Manual A-45...
Page 291: Write Encryption
SNMP packets that are received with the read/write community string have to be encrypted or the packet will not be authorized. You need to use software from Intermec Technologies that supports encryption. " NOTE: To enable security encryption, you also need to set the Security Encryption Key (page A-47).
Page 292: Encryption Key
Control Panel Applets Encryption Key Identifies the key that this 700 Series Computer uses to encrypt or decipher SNMP packets. Encryption is used only by software provided by Intermec Technologies. If encryption is enabled, SNMP management platforms will not be able to communicate with the 700 Series Computer.
Page 293: Traps
APPENDIX A Traps To access the settings from the 700 Series Computer, tap Start → Settings → the System tab → the SNMP icon → the Traps tab to access its parameters. The following are authentication and threshold parameters for traps. Note that these are listed in the order of their appearance within the Traps tab.
Page 294 If the threshold is reached, the trap will not be sent. Action: Tap the Threshold parameter, then enter a threshold value to change this parameter setting. SNMP OID: 1.3.6.1.4.1.1963.10.5.2.3.0 Options: Any positive integer value. Default is 10. 700 Series Color Mobile Computer User’s Manual A-49...
Page 295: Contact
Control Panel Applets APPENDIX A Identification To access the settings from the 700 Series Computer, tap Start → Settings → the System tab → the SNMP icon → the Identification tab to access its parameters. The following are parameters for contact, location, and name information for support purposes.
Page 296: Name
APPENDIX A Control Panel Applets Name Sets the assigned name for this 700 Series Computer. Action: Tap the Name parameter, then enter the name of your 700 Series Computer to change this parameter setting. SNMP OID: 1.3.6.1.2.1.1.5.0 Options: The identification name may be up to 255 ASCII characters. Default is no characters or blank.
Page 297: Location
Control Panel Applets APPENDIX A Location Sets the identification location for this 700 Series Computer, such as “Shipping.” Action: Tap the Location parameter, then enter the location of where your 700 Series Computer to change this parameter setting. SNMP OID: 1.3.6.1.2.1.1.6.0...
Page 298: Unit Information Control Panel Applet
Intermec Content is enabled, the Plus region is enabled and installed, and a laser scanner is installed. To access the settings from the 700 Series Computer, tap Start → Settings → the System tab → the Unit Information icon to access its control panel applet.
Page 299: Versions
Control Panel Applets APPENDIX A Versions You can view the latest software build version on your 700 Series Computer by accessing the Unit Information control panel applet. To access the settings from the 700 Series Computer, tap Start → Settings →...
Page 300: Cab Files
Below is a list of CAB files from Intermec Technologies that are available for your 700 Series Computer with their latest developer or released version of the software build. Should you need to add any of these to your 700 Series Comput- er, contact an Intermec representative.
Page 301 BarCodeMFCClient: The bar code reader control that collect bar code information from the 700 Series Computer, configures the scanner, and provides audio or visu- al feedback when data arrives. ITCAXUtilityEX: Utility functions that performs a warm-boot or a cold-boot on the 700 Se- ries Computer and assumes control over the suspend/resume function.
Page 302: Battery Status
APPENDIX A Control Panel Applets Battery Status You can view the battery status for your 700 Series Computer by accessing the Unit Information control panel applet. To access the settings from the 700 Series Computer, tap Start → Settings →...
Page 303 Control Panel Applets APPENDIX A A-58 700 Series Color Mobile Computer User’s Manual...
Page 304: Data Collection
Panel Applets.” Configuration parameters are also configurable using a Unit Manager applica- tion which accesses the 700 Series Computer through a web browser on your desktop PC via the SRDEVMGMT.CAB file. To use the Unit Manager, install this CAB file from the 700C Software Tools CD- ROM.
Page 305: Symbology Id
These are listed in alphabetical order. Beeper Frequency (page A-33) " Beeper Volume (page A-32) " Good Read Beep Duration (page A-35) " Good Read Beeps (page A-34) " Record Button (page A-36) " 700 Series Color Mobile Computer User’s Manual...
Page 306: Snmp
Identification tab to access the following parameters. Options for these parameters are listed on the page provided. These are listed in alphabeti- cal order. Contact (page A-50) " Location (page A-52) " Name (page A-51) " 700 Series Color Mobile Computer User’s Manual...
Page 307: Date/Time
SNMP OID: Date: 1.3.6.1.4.1.1963.15.501.2.1.0 Time: 1.3.6.1.4.1.1963.15.501.2.2.0 Options: Date Year 0000–999 (1999) Month 1–12 (6) 1–31 (1) Time Hour 0–23 (0) Minute 0–59 (00) Second 0–59 (00) 700 Series Color Mobile Computer User’s Manual...
Page 308: Backlight Timeout
SNMP OID: 1.3.6.1.4.1.1963.15.13.1.0 Syntax: DFdata where data is any of the following: 10 seconds 30 seconds 1 minute (default) 120 2 minutes 180 3 minutes 240 4 minutes 300 5 minutes 700 Series Color Mobile Computer User’s Manual...
Page 309: Key Clicks
Unit Manager APPENDIX B Key Clicks Enables or disables the keypad clicks. The 700 Series Computer emits a click each time you press a key or decode a row of a two-dimensional symbology. Action: Click the Keypad tab, then select an option from the Key clicks drop-down list.
Page 310: Automatic Shutoff
Unit Manager Automatic Shutoff Sets the length of time the 700 Series Computer remains on when there is no ac- tivity. When you turn on the 700 Computer, it either resumes exactly where it was when you turned it off or boots and restarts your application.
Page 311: Volume
Click the Speaker tab, then select an option from the Volume drop-down list. SNMP OID: 1.3.6.1.4.1.1963.15.3.1.3.0 Syntax: BVdata where data is any of the following: Very quiet Quiet Normal (default) Loud Very loud 700 Series Color Mobile Computer User’s Manual...
Page 312: Audio Volume
See Appendix A, “Control Panel Applets” for more information about the Virtual Wedge Postamble and Virtual Wedge Preamble commands. To change the Beep Volume to Off, you can send this string to the 700 Series Computer EXAMPLE 1: through the network:...
Page 313: Set Time And Date
Unit Manager APPENDIX B Set Time and Date This command sets the date and time on the 700 Series Computer. The default date and time is June 1, 1999 at 12:00 AM. From the network, send the following: /+ yyyymmddhhmmss where acceptable values for the date are: 0000–9999...
Page 314: Bar Code Symbologies
" This appendix contains a brief explanation of some of the bar code symbologies that the 700 Series Color Mobile Computer decodes and explains some of the general characteristics and uses of these bar code types. It also includes several bar code labels that can be scanned into your 700 Series Computer.
Page 315 If MOD 10 or MOD 11 check digits are enabled, the digit falls at the end of a bar code data string. Each check digit enabled extends the bar code data string length by one character. The 700 Series Computer recognizes eleven of the most widely used bar code symbologies. With bar code symbologies, like languages, there are many differ- ent types.
Page 316: Codabar
Codabar has 18 different dimen- sions for bar and space widths. So many different dimensions often result in la- bels printed out of specification and cause Codabar printing equipment to be more expensive. 700 Series Color Mobile Computer User’s Manual...
Page 317: Encoded Code 39 (Full Ascii)
ASCII characters. Programming for this symbology can be for any length that the application re- quires. The application program for the 700 Series Computer handles symbology that is at least one character but no more than 32 characters in length.
Page 318: Code 128
UCC/EAN-128 Shipping Container Labeling is a versatile tool that can ease movement of products and information. The Shipping Container Labeling bar code can take any form and usually has meaning only within the company or fa- cility where applied. 700 Series Color Mobile Computer User’s Manual...
Page 319: I 2 Of 5 (Interleaved)
The two characters are interleaved as one. Messages encoded with this symbolo- gy have to use an even number of characters since two numeric characters al- ways get interleaved together. 700 Series Color Mobile Computer User’s Manual...
Page 320: Msi Code (Variant Of Plessey)
Check. For start and stop checks, MSI employs a single bit pair of 1 as a start symbol and a single bit pair of 0 as a stop symbol. MSI reverses the 1-2-4-8 BCD pattern for bit pair weighting to 8-6-2-1. 700 Series Color Mobile Computer User’s Manual...
Page 321: Bar Code Labels
Bar Codes APPENDIX C Bar Code Labels You can change some settings on your 700 Series Computer by scanning the fol- lowing Code 39 bar code labels. You can use the Unit Manager application to set the Automatic Shutoff, Volume, Backlight Timer, or Key Clicks parameters (starting on page B-4).
Page 322: Automatic Shutoff
Backlight Timeout 1 Minute (d f (default) *$+DF60* *$+DF120* *$+DF120* Backlight Timeout 2 Minutes *$+DF120* *$+DF180* *$+DF180* Backlight Timeout 3 Minutes *$+DF180* *$+DF240* *$+DF240* Backlight Timeout 4 Minutes *$+DF240* *$+DF300* *$+DF300* Backlight Timeout 5 Minutes *$+DF300* 700 Series Color Mobile Computer User’s Manual...
Page 323: Virtual Wedge Grid, Preamble, Postamble
For Virtual Wedge Postamble, the first part of the bar code would be below, fol- lowed by a string of up to 31 characters (no <NUL>) and an asterisk. Default is no characters. Parameter information is on page A-39. *$+AE *$+AE *$+AE C-10 700 Series Color Mobile Computer User’s Manual...
Page 324 IssueBeep, 6-20 GetAuthenticationMode(), 4-20 CloseHandle() QueryAttribute, 6-21 GetBSSID(), 4-16 DTR printing, 5-6, 5-7 Read, 6-22 GetCodabar, IS9CConfig, 6-29 IrDA printing, 5-1 SetAttribute, 6-24 NPCP printing, 5-2, 5-3 GetCode11, IS9CConfig2, 6-55 TriggerScanner, 6-27 700 Series Color Mobile Computer User’s Manual Index-1...
Page 325: Radioconnect()
SetI2of5, IS9CConfig, 6-38 functions, 6-17 SetMatrix2of5, IS9CConfig, 6-40 SetMSI, IS9CConfig, 6-41 WriteFile() SetNetworkMode(), 4-18 DTR printing, 5-6, 5-7 SetPDF417, IS9CConfig, 6-43 IrDA printing, 5-1 KernelIoControl(), 7-20 SetPDF417Ext, IS9CConfig2, 6-59 NPCP printing, 5-2, 5-3 Index-2 700 Series Color Mobile Computer User’s Manual...
Page 326 4-4 Adding programs configuration profiles, 4-15 ActiveSync, 2-17 Backlight timeout CORE module, 4-23 Pocket Internet Explorer, 2-18 bar code configuration, C-9 network type, 4-6 Pocket PC, 2-17 configuration parameter, B-5 700 Series Color Mobile Computer User’s Manual Index-3...
Page 327 AutoCab, 3-11 Bluetooth compatibility, network support, VN_CLASS_BOOTSTRAP, 7-22 EFlash, 3-8 4-34 VN_CLASS_KBD, 7-22 IFTP server, 3-8 Bluetooth Device Manager, documenta- Clock Common Object Resource Environment. tion, 4-34 Pocket PC settings, 2-16 See CORE Index-4 700 Series Color Mobile Computer User’s Manual...
Page 328 ID, A-28 Programs panel, 4-1 telepen, A-20 trap Today screen, 4-2 telepen user ID, A-28 authentication, A-48 Bluealps module, 4-34 UPC--E user ID, A-27 threshold, A-49 Bluetooth, 4-34 UPC--A user ID, A-27 700 Series Color Mobile Computer User’s Manual Index-5...
Page 329 Embedded modules, SB555, 4-25 ISCP::GetConfig, 6-62 IS9CConfig::GetUpcEan, 6-50 Encoded Code 39 ISCP::SetConfig, 6-62 IS9CConfig::SetUpcEan, 6-51 concatenation, C-4 dwDataBufferSize eAttr full ASCII, C-4 IADC::Read, 6-15 IBarCodeReaderControl::QueryAttri- IBarCodeReaderControl::Read, 6-22 bute, 6-21 Ending a connection, 2-54 Index-6 700 Series Color Mobile Computer User’s Manual...
Page 330 4-12 SYST, 7-13 I 2 of 5. See Interleaved 2 of 5 TYPE, 7-14 I/O controls, NPCP driver, 5-4 USER, 7-14 XCUP, 7-14 I_Mode, UpdateNIC_Infrastructure- Factory repair, 1-6 XCWD, 7-14 Mode(), 4-47 700 Series Color Mobile Computer User’s Manual Index-7...
Page 331 3-8 transfer items using, 2-50 IOCTL_NPCP_ERROR, 5-4 receiving information, 2-50 iid, ITCDeviceOpen, 6-11 sending information, 2-50 IOCTL_NPCP_FLUSH, 5-4 IImage interface, 6-65 InfrastructureMode, GetRegistryInfras- IOCTL_PROCESSOR_INFORMATION, Image, acquisition features, 6-9 tructureMode(), 4-44 7-33 Index-8 700 Series Color Mobile Computer User’s Manual...
Page 332 ITC_NVPARM_WAN_RADIOTYPE, 7-23 ITC_DHDEVFLAG_NODATA, ITCDevi- driver registry settings, 7-37 ceOpen, 6-11 ITC_NVPARM_WAN_RI, 7-22 planes, 7-36 remapping, 7-36 ITC_DHDEVFLAG_READAHEAD ITC_RDRATTR_GOOD_READ_BEEP_D sample registry keys, 7-39 IADC::Initialize, 6-13 URATION, IBarCodeReaderCon- IBarCodeReaderControl::Initialize, 6-19 trol::SetAttribute, 6-24 Knowledge Central, 1-6 700 Series Color Mobile Computer User’s Manual Index-9...
Page 333 2-52 supported symbologies, 6-9 IOCTL_HAL_GET_DEVICE_INFO, MP3 files, Windows Media Player, 2-43 symbologies not available, Datamatrix, 7-20 A-22, A-23 IOCTL_HAL_GET_DEVICEID, 7-27 MSDN library, 7-16 LEAP, 802.1x profile, security informa- tion, 4-9 Index-10 700 Series Color Mobile Computer User’s Manual...
Page 334: Getwepstatus()
PowerMode(), 4-21 pdwReplyBuffSize driver I/O controls, 5-4 NDIS_RADIO_POWER_UNKNOWN, ISCP::GetConfig, 6-62 installation, 5-2 GetPowerMode(), 4-21 ISCP::SetConfig, 6-62 LPT9, 5-2 NDIS_RADIO_SCANNING, GetAssoci- opening driver, 5-3 pdwTotalDiscardedBytes, IADC::Cancel- ationStatus(), 4-19 reading from driver, 5-3 ReadRequest, 6-12 700 Series Color Mobile Computer User’s Manual Index-11...
Page 335 Control::CancelReadRequest, 6-17 creating a document, 2-35 pImgBuffer drawing mode, 2-38 pwTotalDiscardedMessages IImage::ReadImage, 6-68 Pocket PC icon, 2-6 IADC::CancelReadRequest, 6-12 IImage::ReadSigCapBuffer, 6-66 recording mode, 2-38 IBarCodeReaderControl::CancelRea- Planes, keypad, 7-36 tips, 2-40 dRequest, 6-17 Index-12 700 Series Color Mobile Computer User’s Manual...
Page 336 A-49 rgbBuffer backlight timeout, B-5 control primitives, 4-37 IADC::QueryAttribute, 6-14 date/time, B-4 multiple retrievals, 4-38 IS9CConfig2::GetGlobalAmble, 6-58 key clicks, B-6 retrieval, 4-38 IS9CConfig2::SetGlobalAmble, 6-58 volume, B-8 using the protocol, 4-37 700 Series Color Mobile Computer User’s Manual Index-13...
