RealPresence Collaboration Server (RMX) 4000 Hardware Guide
Table 1-13
Component
ShMG (Shelf
Manager) LEDs

RTM LAN

The following LEDs appear on the RTM LAN:
Table 1-14
Function Name
LAN 1 & 2 LEDs
H.S. LED
1-32
RTM-IP 4000 LEDs (Continued)
LED
LED Color
Name
ERR Red
ACT Amber
RDY Green
HS Blue
RMX 4000 RTM LAN LEDs
LED
LED Color
Name
1 Gb Amber
LNK Green
Blue
Description
ON - Major error on RTM-IP 4000 card.
Flashes - During system startup.
ON - Packet flow to and from the MCU chassis.
Flashes - During system startup.
ON - RTM-IP 4000 card has successfully completed
startup.
Flashes - During system startup.
Hot Swap not supported.
OFF - Normal.
Flashes for a second during initial power up.
Description
ON when 1Gb connection is online, flickers with
Packet activity.
ON with an active network connection, flickers with
Packet activity.
OFF - Normal.
Flashes - During the startup of a media card and
control 4000 unit. Also flashes when the RTM LAN
card is powered down.
ON - RTM LAN card may be removed.
