Component Slot Allocation

On the RMX 4000, components have been assigned dedicated slots as defined in the
following table. Slot numbers are located on both the front and rear of the RMX 4000.
Table 1-11
Slot ID/No.
1-4
5
6
7
8
9-11
12
13-16
17
18
19-21
1-28
RMX 4000 Slot Numbering
Card/Component Requirement
MPM+/MPMx Mandatory: At least 1 MPM+/MPMxcard is required. Each
Cards media card also requires either an RTM ISDN or an RTM LAN
card.
Fabric Switch Mandatory
Module
(FSM 4000)
CPU 2 Not Available (NA)
Logo Panel Not Available (NA)
CTNL 4000 unit Mandatory
(CPU 1)
AC Power Supply An RMX with AC power has 3 power supplies installed. A 3rd
power supply is redundant (n+1).
Note: Not used with DC powered systems. DC powered
systems receive Direct Current from the power rail .
Fan Drawer Mandatory
RTM ISDN/RTM Either an RTM ISDN or an RTM LAN card is mandatory in
LAN combination with a Media card. The RTM ISDN/RTM LAN
board must be inserted in a slot opposite any MPM+/MPMx
card.
RTM-IP 4000 Mandatory
Blank Panel Not Available (NA)
Power Modules Mandatory:
With AC power, three power supplies are installed, with the 3rd
redundant.
With DC power, two power supplies are installed with the 2nd
redundant. The center slot (#20) on the rear of the RMX 4000
is disabled and is fitted with blank panel.
Note: Protective bonding conductor size is 14AWG (1.5mm)
within the Power Entry Model.
