Polycom DOC2709A Hardware Manual page 21

4
5
The number of screws to install depends on the rack width.
6
The RMX 4000 must be lifted into the rack by two people.
The installation is complete.
Polycom, Inc.
Repeat steps 2 and 3 for the right rack rail runner.
Install the flat head screw
(item 7) in the middle of the telescopic rack rail runner for added stability as
shown in Figure 1-5.
Figure 1-5 Detail of Left Rail Runner (front internal view)
Repeat step 5 for the right rack rail runner.
Figure 1-6 RMX 4000 Bolt installation
(item 5), flat washer
Chapter 1-Hardware Description
(item 6) and nut spring
1-13
