RealPresence Collaboration Server (RMX) 4000 Hardware Guide
Table 1-12
Component
MPM+/MPMx Card
CNTL 4000 Unit
1-30
RMX 4000 Front Panel LED's (Continued)
LED ID
ERR
RDY
ACT
HS
ERR
RDY
ACT
HD
LED Color Description
Red ON - Major error on card.
Flashes - During card startup.
Green ON - The card has completed startup
successfully, after the ERR, RDY & ACT
LED's have stopped flashing.
Flashes - During card startup.
Amber ON - At least one participant is connected to a
conference.
Flashes - During card startup.
Blue Flashes - Shut down process initiated by
lightly pulling the CPU ejector levers. This
LED flashes in synchronization with the CNTL
4000's card's HS LED.
ON - Card is in a power down mode.
Card removal Initiated - The card can be
removed safely once the CPU ejector levers
are fully open.
Card Insertion Initiated - If during the startup
phase the blue HS LED remains lit, please
ensure that the card is properly seated in the
chassis. If this problem persists, contact your
next level of support.
Red ON - Major system error. In case of an active
alarm this light is ON, and the RDY green is
OFF.
OFF - Normal.
Flashes - During system startup.
Green ON - CPU card has successfully completed
startup. This light turns green after completing
the entire system configuration.
OFF - Turns OFF when the ERR red LED is
activated.
Flashes - During system startup.
Amber ON - At least one endpoint is connected to the
system.
Flashes - During system startup.
Red OFF - Normal.
Flashes - Hard disk is active.
