RealPresence Collaboration Server (RMX) 4000 LEDs

The RMX includes LEDs located on the front panel and rear panel. In the front panel, the
LEDs reflect the state of the components. The LEDs on the rear panel indicate the state of the
external connections and the status of the RTM-IP 4000 card.

RealPresence Collaboration Server (RMX) 4000 Front Panel LEDs

The following items appear on the RMX 4000 front panel:
Table 1-12
Component
Fan Status
Power Module/Rail
Status (AC only)
Fabric Switch Module
(FSM 4000)
Polycom, Inc.
RMX 4000 Front Panel LED's
LED ID
AC
DC (OK)
DC
(FAIL)
ERR
RDY
ACT
LED Color Description
Green OK.
Red Warning - Fan or power failure.
Green OK.
Red Error - Problem with power supply. When the
power cable is unplugged, the FAIL LED is lit
2-3 seconds before turning OFF.
Green OK.
Red Error - Problem with power supply. When the
power cable is unplugged, the FAIL LED is lit
2-3 seconds before turning OFF.
OFF - all In case of a power failure (main/cable/
module) all LED's are OFF.
LED's
Red ON - Major error on card.
Flashes - During card startup.
Green ON - The card has completed startup
successfully.
Flashes - During card startup.
Orange Not in use.
