Chapter 5 Graphical User Interface Reference

Figure 5-18 Add SNMP Trap Host Example

5.
6.
7.
Note
8.
78-13124-05
Type the host IP address into the IP Address text box. If you wish the trap
messages to be sent to a community other than the default community, enter
the community name in the Community text box. Select the desired version
of SNMP from the SNMP Version list box.
Click OK to add the trap host.
Set the desired traps by selecting the Enable option buttons and typing
appropriate values in the Threshold/Hysteresis Low and Hysteresis High
text boxes. If you wish to use only one trap point, enter a value only in the
Threshold/Hysteresis Low text box.
Additional information is presented in the online Help for
this tab. Click Help in the top right corner of the window.
Click Update to set the configuration.
Cisco 11000 Series Secure Content Accelerator Configuration Guide
General Configuration Examples
5-21
