MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
E
Button Diagrams
Figure E–7.
5
4
3
Icom
2
Voice
1
Icom
Ring
5
Behind Switch Mode:
One prime line is assigned
to button 3
MLX 5- and 10-Button Telephone Button Diagram
(Key and Behind Switch Modes)
10
9
8
7
6
10
Issue 1
February 1998
Page E-5
