Dell PowerConnect J-Series J-EX4200 Ethernet Switch Hardware Guide

Field-Replaceable Units in J-EX4200 Switches

Related
Documentation

Chassis Status LEDs in J-EX4200 Switches

16
Field-replaceable units (FRUs) are components that you can replace at your site. The
field-replaceable units (FRUs) in J-EX4200 switches are:
Power supply
Fan tray
Uplink module
SFP transceiver
SFP+ transceiver
NOTE: Uplink modules are not part of the standard package and must be
ordered separately.
The power supply, fan tray, uplink module, and transceivers are hot-removable and
hot-insertable: You can remove and replace them without powering off the switch or
disrupting switch functions.
NOTE: If you have a service contract, register any addition, change, or upgrade
of hardware components at
in significant delays if you need replacement parts. This note applies if you
change the type of power supply or add a new type of uplink module. It does
not apply if you replace these components with the same type of component.
Uplink Modules in J-EX4200 Switches on page 25
Installing a Power Supply in a J-EX4200 Switch on page 106
Removing a Power Supply from a J-EX4200 Switch on page 140
Installing a Fan Tray in a J-EX4200 Switch on page 107
Removing a Fan Tray from a J-EX4200 Switch on page 141
Installing an Uplink Module in a J-EX4200 Switch on page 108
Removing an Uplink Module from a J-EX4200 Switch on page 142
Installing a Transceiver in a J-EX Series Switch on page 110
Removing a Transceiver from a J-EX Series Switch on page 144
The front panel of a J-EX4200 switch has three LEDs on the far right side of the panel,
next to the LCD panel (see Figure 6 on page 17).
. Failure to do so can result
http://www.dell.com
