Dell PowerConnect J-Series J-EX4200 Ethernet Switch Hardware Guide
Table 21: Uplink Modules Connector Pinout Information for J-EX4200 Switches (continued)
Pin Number
C6
C7
C8
C9
C10
C11
C12
C13
C14
C15
C16
C17
C18
C19
C20
D1
D2
D3
D4
D5
D6
D7
D8
D9
44
Pin Name
XAUI1_RX0P
GND
XAUI1_RX2P
GND
SRX28P
GND
SRX26P
GND
SGMIIRXP
CPU_UPLINK_MDC
Uplink_I2C_SDA
CPU_UPLINK_MDIO
Uplink_P26_LED1
UPLNK_PWR_OK
POWER (12V)
GND
GND
XAUI0_TX1N
GND
XAUI0_TX3N
GND
XAUI1_TX1N
GND
XAUI1_TX3N
