Dell PowerConnect J-EX4200 Hardware Manual page 25

Table 6: CLI Equivalents of Terms Used in Documentation for the J-EX4200 Switch
Hardware Item
(CLI) Description (CLI)
Chassis One of the following:
Dell
J-EX4200-24T
Dell
J-EX4200-48T
Dell
J-EX4200-24F
EX4200-24T
EX4200-48T
EX4200-48T
FPC (n) On a standalone
J-EX4200
switches—Abbreviated
name of the Flexible
PIC Concentrator
(FPC)
One of the following:
EX4200-48T
EX4200-48T
EX4200-24F
On a J-EX4200
Virtual
Chassis—Member ID
of the switch within
the Virtual Chassis
PIC (n) Abbreviated name
of the Physical
Interface Card (PIC).
One of the following:
24x 10/100/1000
Base-T
24x 100
Base-FX/1000
Base-X
48x 10/100/1000
Base-T
Chapter 1: Dell PowerConnect J-Series J-EX4200 Switches Overview
Item in
Value (CLI) Documentation
– Switch chassis
Value of n is The switch does not
always 0. have actual FPCs. In
this case, the FPC
refers to the switch
itself.
n is a value in the In this case, the FPC
range of 0-9. number refers to the
member ID assigned
to the switch.
n is a value in the The switch does not
range of 0-1. have actual PIC
devices; see entries
for PIC 0 through
PIC 1 for the
equivalent item on
the switch.
PIC 0 Built-in network
ports on the front
panel of the switch
Additional Information
"Chassis Physical Specifications for
J-EX4200 Switches" on page 5
See the information about interfaces
and interface naming conventions on
J-EX Series Ethernet switches in the
multivolume Dell PowerConnect
J-Series Ethernet Switch Complete
Software Guide for Junos OS at
http://www.support.dell.com/
manuals
.
See the information about Virtual
Chassis and Virtual Chassis
components in the multivolume Dell
PowerConnect J-Series Ethernet Switch
Complete Software Guide for Junos OS
at http://www.support.dell.com/
manuals .
See the information about interfaces
and interface naming conventions on
J-EX Series Ethernet switches in the
multivolume Dell PowerConnect
J-Series Ethernet Switch Complete
Software Guide for Junos OS at
http://www.support.dell.com/
manuals .
"Front Panel of a J-EX4200 Switch" on
page 6
9
