Dell PowerConnect J-Series J-EX4200 Ethernet Switch Hardware Guide
Related
Documentation
132
Stop Bits—1
DCD State—Disregard
To connect and configure the switch from the console:
Connect the console port on the rear panel of the switch to a laptop or PC using the
1.
RJ-45 to DB-9 serial port adapter. The RJ-45 cable and RJ-45 to DB-9 serial port
adapter are supplied with the switch.
At the Junos OS shell prompt
2.
Enter the hostname. This is optional.
3.
Enter the root password you plan to use for this device. You are prompted to re-enter
4.
the root password.
Enter yes to enable services like Telnet and SSH. By default, Telnet is not enabled and
5.
SSH is enabled.
NOTE: When Telnet is enabled, you will not be able to log in to a J-EX
Series switch through Telnet using
only for SSH access.
Use the Management Options page to select the management scenario:
6.
Configure in-band management
Use the default VLAN.
Create a new VLAN—If you select this option, you are prompted to specify the
VLAN name, VLAN ID, management IP address, and default gateway. Select the
ports that must be part of this VLAN.
Configure out-of-band management
management interface. Use this IP address to connect to the switch.
Specify the SNMP Read Community, Location, and Contact to configure SNMP
7.
parameters. These parameters are optional.
Specify the system date and time. Select the time zone from the list. These options
8.
are optional.
The configured parameters are displayed. Enter
The configuration is committed as the active configuration for the switch. You can now
log in with the CLI or the J-Web interface to continue configuring the switch. If you use
the J-Web interface to continue configuring the switch, the Web session is redirected to
the new management IP address. If the connection cannot be made, the J-Web interface
displays instructions for starting a J-Web session.
Connecting and Configuring a J-EX Series Switch (J-Web Procedure) on page 133
Installing and Connecting a J-EX4200 Switch on page 87
, type .
root% ezsetup
root credentials. Root login is allowed
. In this scenario you have the following two options:
. Specify the IP address and gateway of the
to commit the configuration.
yes
