LCD Panel Menus

Table 7: LCD Panel Menu Options in J-EX4200 Switches
Menu Description
IDLE In the Idle menu:
Press Enter
ADM (administrative status)
DPX (duplex)
Power over Ethernet (PoE)
SPD (speed)
See "Network Port LEDs in J-EX4200 Switches" on page 18 for information on the Status LED modes.
Press
Menu
In the maintenance mode, the second line displays one of the following options that you
can use to configure and troubleshoot the switch:
System halt
System reboot
Load rescue
Request VC port (for a switch that is a member of a Virtual Chassis)
Factory default
System EZSetup
The LCD panel has three menus: Idle, Status, and Maintenance. Toggle between the LCD
panel menus by pressing the
the Enter button.
Table 7 on page 13 describes the LCD panel menu options.
to cycle through the Status LED modes:
to exit the Idle menu and go to the Status menu.
Menu button. Navigate through the menu options by pressing
