Table 21: Uplink Modules Connector Pinout Information for J-EX4200 Switches (continued)
Pin Number
D10
D11
D12
D13
D14
D15
D16
D17
D18
D19
D20
E1
E2
E3
E4
E5
E6
E7
E8
E9
E10
E11
E12
E13
Pin Name
GND
STX27N
GND
STX25N
GND
Uplink_Rst
GND
Uplink_Status_LED0
GND
POWER (12V)
GND
GND
XAUI0_TX0N
XAUI0_TX1P
XAUI0_TX2N
XAUI0_TX3P
XAUI1_TX0N
XAUI1_TX1P
XAUI1_TX2N
XAUI1_TX3P
STX28N
STX27P
STX26N
STX25P
Chapter 3: Component Specifications
45
