Figure 1. Intel - Intel X38ML - Server Board Motherboard Technical Manual

Intel® Server Board X38ML
Ref #
3 NIC2 RJ-45 connector
4 (J3A1) Integrated BMC Force Update
Jumper
5 Serial A DB-9 connector
6 VGA connector
7 Chassis intrusion header
8 ServerEngines* Integrated BMC
9 POST LED
10 2x5 USB header for USB 2 and 3
®
11 Intel 82575EB LAN controller
12 SMBus connector
®
13 Intel 82801IR ICH9R
14 (J6B1) Password Clear jumper
15 PCI Express* x16 riser slot
16 SATA Port 2
The following mechanical drawing shows the physical dimensions of the server board:
Revision 1.3
Description
®

Figure 1. Intel

Server Board X38ML Layout
Intel order number E15331-006
Ref # Description
19 SATA Port 1
20 CMOS battery
21 1x3 Serial B header
22 DIMM socket B2
23 DIMM socket B1
24 DIMM socket A2
25 DIMM socket A1
®
26 Intel X38 MCH
27 LGA775 processor socket
28 2x9 main power connector
29 System fan 1 (8-pin)
30 System fan 2 (8-pin)
31 System fan 3 (8-pin)
32 2x8 front panel connector
Server Board Overview
