Intel® Server Board X38ML
FP_PWR_BTN_R_N
GND
KEY
FM_LED_STATUS_AMB_N
7.5

I/O Connectors

7.5.1

VGA Connector

The following table details the pin-out of the VGA connector:
7.5.2

NIC Connectors

The server board supports two NIC RJ-45 connectors. The following tables detail the pin-out of
the connectors.
Table 56. NIC1-Intel
Revision 1.3
Signal Name Pin
9
11
13
15

Table 55. VGA Connector Pin-out (J8A1)

Signal Name Pin
VGA_RED 1
VGA_GREEN 2
VGA_BLUE 3
RESERVED 4
GND 5
GND 6
GND 7
GND 8
®
82575EB (10/100/1000) Connector Pin-out (JA2A1)
Signal Name Pin
TERM 9
MDI0P 10
MDI0N 11
MDI1P 12
MDI1N 13
MDI2P 14
MDI2N 15
Intel order number E15331-006
Signal Name
FP_RST_BTN_R_N
GND
TEST PAD
FM_LED_STATUS_GRN_N
Signal Name Pin
5V 9
GND 10
RESERVED 11
DDCDAT 12
HSYNC 13
VSYNC 14
DDCCLK 15
Signal Name Pin
MDI3P 16
MDI3N 17
GND 18
GRN_C 19
GRN_A 20
GRN_C/YEL_A 21
GRN_A/YEL_C 22
Connectors and Jumper Blocks
Pin
10
12
14
16
107
