Figure 10. Setup Utility - Serial Port Configuration Screen Display; Table 11. Setup Utility - Serial Ports Configuration Screen Fields - Intel X38ML - Server Board Motherboard Technical Manual

System BIOS
Advanced
Serial Port Configuration
Serial A Enable
Address
IRQ
Serial B Enable
Address
IRQ
Figure 10. Setup Utility — Serial Port Configuration Screen Display
Table 11. Setup Utility — Serial Ports Configuration Screen Fields
Setup Item Options
Serial A
Enabled
Enable
Disabled
Address
3F8h
2F8h
3E8h
2E8h
IRQ 3
4
Serial B
Enabled
Enable
Disabled
Address 3F8h
2F8h
3E8h
2E8h
IRQ
3
4
4.3.2.2.5 USB Configuration Screen
The USB Configuration screen provides fields to configure the USB controller options.
To access this screen from the Main screen, select Advanced > USB Configuration.
34
Enabled/Disabled
3F8h/2F8h/3E8h/2E8h
3 or 4
Enabled/Disabled
3F8h/2F8h/3E8h/2E8h
3 or 4
Help Text
Serial port A.
Enable or Disable
Select Serial port A base I/O address.
Select Serial port A base interrupt request (IRQ)
line.
Serial port B.
Enable or Disable
Select Serial port B base I/O address.
Select Serial port B base interrupt request (IRQ)
line.
Intel order number E15331-006
Intel® Server Board X38ML
Comments
N/A
N/A
N/A
N/A
N/A
N/A
Revision 1.3
