System BIOS
Setup Item
Hard Disk Order
CDROM Order
Floppy Order
Network Device Order
BEV Device Order
4.3.2.5.1 Hard Disk Order Screen
The Hard Disk Order screen provides a way to control the hard disks.
To access this screen from the Main screen, select Boot Options > Hard Disk Order.
Hard Disk #1
Hard Disk #2
Figure 18. Setup Utility — Hard Disk Order Screen Display
Setup Item
Hard Disk #1 Available hard
disks
Hard Disk #2 Available hard
disks
4.3.2.5.2 CDROM Order Screen
The CDROM Order screen provides a way to control the CD-ROM devices.
44
Options
N/A Set hard disk boot order by selecting
the boot option for this position.
N/A Set CDROM boot order by selecting
the boot option for this position.
N/A Set floppy disk boot order by selecting
the boot option for this position.
N/A Set network device boot order by
selecting the boot option for this
position. Add-in or onboard network
devices with a PXE option ROM are
two examples of network boot devices.
N/A Set the Bootstrap Entry Vector (BEV)
device boot order by selecting the boot
option for this position.
BEV devices require their own
proprietary method to load an OS using
a bootable option ROM. BEV devices
are typically found on remote program
load devices.
Table 19. Setup Utility — Hard Disk Order Fields
Options
Set hard disk boot order by selecting the boot
option for this position.
Set hard disk boot order by selecting the boot
option for this position.
Intel order number E15331-006
Help Text
Boot Options
< Available Hard Disks >
< Available Hard Disks >
Help Text
Intel® Server Board X38ML
Comments
Displays when more than
one hard disk drive is in the
system.
Displays when more than
one CD-ROM drive is in the
system.
Displays when more than
one floppy drive is in the
system.
Displays when more than
one of these devices is
available in the system.
Displays when more than
one of these devices is
available in the system.
Comments
N/A
N/A
Revision 1.3
