Intel® Server Board X38ML
Console Redirection
Console Redirection
Flow Control
Baud Rate
Terminal Type
Legacy OS Redirection
Figure 15. Setup Utility — Console Redirection Screen Display
Table 16. Setup Utility — Console Redirection Configuration Fields
Setup Item
Console Redirection
Disabled
Serial A
Serial B
Flow Control
None
RTS/CTS
Baud Rate 9600
19.2K
38.4K
57.6K
115.2K
Terminal Type PC-ANSI
VT100
VT100+
VT-UTF8
Legacy OS
Disabled
Redirection
Enabled
Revision 1.3
Server Management
Disabled/Serial A/Serial B
None/RTS/CTS
9.6k/19.2k/38.4k/57.6k/115.2k
PC-ANSI/VT100/VT100+/VT-UTF8
Disabled/Enabled
Options
Console redirection allows a serial port to be used for
server management tasks.
[Disabled] - No console redirection.
[Serial Port A] - Configure serial port A for console
redirection.
[Serial Port B] - Configure serial port B for console
redirection.
Enabling this option will disable the Quiet Boot logo
screen during POST.
Flow control is the handshake protocol.
Setting must match the remote terminal application.
[None] - Configure for no flow control.
[RTS/CTS] - Configure for hardware flow control.
Serial port transmission speed. Setting must match
the remote terminal application.
Character formatting used for console redirection.
Setting must match the remote terminal application.
This option will enable legacy OS redirection (i.e.,
DOS) on the serial port. If it is enabled the associated
serial port will be hidden from the legacy OS.
Intel order number E15331-006
Help Text
System BIOS
Comments
N/A
N/A
N/A
N/A
N/A
41
