Intel® Server Board X38ML
®
Intel Core™2 Duo Processor E6750
-
®
Intel Core™2 Duo Processor E6700
-
®
Intel Core™2 Duo Processor E6600
-
®
Intel Core™2 Duo Processor E4600
-
®
Intel Core™2 Duo Processor E6840
-
®
Intel Core™2 Duo Processor E4500
-
®
Intel Core™2 Duo Processor E6420
-
®
Intel Core™2 Duo Processor E6400
-
®
Intel Core™2 Duo Processor E4400
-
®
Intel Core™2 Duo Processor E6320
-
®
Intel Core™2 Duo Processor E6300
-
®
Intel Core™2 Duo Processor E4300.
-
Supports 800/1066/1333MHz FSB
-
®
Intel X38 chipset components
®
Intel X38 MCH Memory Controller Hub
®
Intel ICH9R I/O Controller
Memory subsystem
-
DDR2 667/800 MHz, unbuffered ECC memory or non-ECC memory.
Two memory channels, two DIMM sockets per channel
8 GB supported
Video
-
o 32 MB DDR2 667 MHz video memory
o External VGA connector
PCI Express* connector
-
One PCI Express* x16 connector supporting PCI Express* riser card
HDD Interface
-
o Four SATA II, 300 Gb/s ports
USB
-
o Two external USB 2.0 ports on rear I/O panel
o Two internal USB 2.0 headers
LAN
-
o Dual Gigabit Ethernet device connects to PCI Express* x4 interface on the
ICH9R
o Two 10/100/1000 Base-TX Interfaces through RJ45 Connectors
System management
-
o Processor on-die temperature monitoring through Platform Environmental
Control Interface (PECI)
o Board temperature measurement
o Fan speed monitoring and control
o Voltage monitoring
o IPMI-based server management
Revision 1.3
Intel order number E15331-006
Server Board Overview
3
