Figure 9. Setup Utility - Ata Controller Configuration Screen Display - Intel X38ML - Server Board Motherboard Technical Manual

System BIOS
Setup Item
Current Memory N/A
Speed
DIMM_# N/A
Memory Correction
ECC
Non-ECC
4.3.2.2.3 SATA Controller Configuration Screen
The SATA Controller Configuration screen provides fields to configure SATA hard drives. It also
provides information on the hard disk drives installed.
To access this screen from the Main screen, select Advanced | SATA Controller.
Advanced
SATA Controller Configuration
Onboard SATA Controller
Configure SATA as
► SATA Port 0
► SATA Port 1
► SATA Port 2
► SATA Port 3
Figure 9. Setup Utility — ATA Controller Configuration Screen Display
32
Options Help Text
N/A
N/A
N/A
Enabled/Disabled
IDE/AHCI/ RAID
Not Installed/<Drive Info.>
Not Installed/<Drive Info.>
Not Installed/<Drive Info.>
Not Installed/<Drive Info.>
Intel order number E15331-006
Intel® Server Board X38ML
Comments
Information only. Displays speed the
memory is running at.
Displays the state of each DIMM socket
present on the board. Each DIMM socket
field reflects one of the following possible
states:
Installed: There is a DIMM installed
in this slot.
Not Installed: There is no DIMM
installed in this slot.
Failed: The DIMM installed in this
slot is faulty/malfunctioning.
N/A
Revision 1.3
