A guide for technically qualified persons
Intel
Server Board S815EBM1
®
Quick Start Guide
Emissions Disclaimer ................................................................... 2
Safety Cautions ............................................................................ 2
Items Provided on the Bootable CD-ROM................................... 2
Safety and Regulatory Compliance .............................................. 3
Processor ...................................................................................... 3
Memory........................................................................................ 3
Power Supply ............................................................................... 4
Back Panel Connectors................................................................. 7
Front Panel Connectors ................................................................ 8
Jumpers ........................................................................................ 9
Installing Processors.................................................................... 10
Installing Memory ....................................................................... 13
Installing the I/O Shield .............................................................. 14
Installing the Server Board.......................................................... 15
Connecting the IDE Drives.......................................................... 16
................................................................................ 17
Translations of this guide are available at:
Übersetzungen dieses Handbuchs sind erhältlich bei:
Versiones traducidas de esta guía se encuentran disponibles en:
Des traductions de ce guide sont disponibles à l'adresse:
Le versioni tradotte di questa Guida sono disponibili presso:
As traduções deste guia estão disponíveis em:
http://support.intel.com/support/motherboards/server/S815EBM1/manual.htm
All rights reserved. No part of this document may be copied, or reproduced in any form, or by
any means without prior written consent of Intel.
Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including,
but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Intel assumes no responsibility for any errors that may appear in this document. Intel makes
no commitment to update nor to keep current the information contained in this document.
Intel, Pentium and Celeron are trademarks or registered trademarks of Intel Corporation or its
subsidiaries in the United States and other countries.
†
Other names and brands may be claimed as the property of others.
Copyright © 2001, 2002 Intel Corporation.
Order Number: A67055-004
Advertisement
Table of Contents
Related Manuals for Intel S815EBM1 - Server Board Motherboard
Summary of Contents for Intel S815EBM1 - Server Board Motherboard
-
Page 1: Table Of Contents
All rights reserved. No part of this document may be copied, or reproduced in any form, or by any means without prior written consent of Intel. Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. -
Page 2: Before You Begin
Emissions Disclaimer To ensure EMC compliance with your local regional rules and regulations, the final configuration of your end system product may require additional EMC compliance testing. For more information please contact your local Intel Representative. ® See the Intel Server Board S815EBM1 Product Guide for product Safety and EMC regulatory compliance information. -
Page 3: Safety And Regulatory Compliance
Safety and Regulatory Compliance See the Intel Server Board S815EBM1 Product Guide for product Safety and EMC regulatory compliance information. Intended uses: This product was evaluated for use in servers that will be installed in offices, computer rooms, and similar locations. Other uses require further evaluation. -
Page 4: Power Supply
If the Wake On LAN (WOL) and Instantly Available technology features are used, ensure that the power supply current required depends on the wake devices supported. Please see the S815EBM1 Technical Product Specification for more details. Intel Server Board S815EBM1 Quick Start Guide... -
Page 5: Server Board Components
Server Board Components Devices Devices Reset IR Module J9H4 HD LED 2-pin alternate power LED/Sleep connector J9H3 Ground Power LED Connection OM13571 Intel Server Board S815EBM1 Quick Start Guide... - Page 6 Front panel switch/LED connector Chassis intrusion connector Alternate front panel power LED connector System fan (fan 2) BIOS configuration jumper block Wake on LAN technology connector W. 4 Mbit Firmware Hub (FWH) PCI expansion slots Intel Server Board S815EBM1 Quick Start Guide...
-
Page 7: Back Panel Connectors
PS/2 keyboard, purple USB port 1 USB port 3 Parallel port, burgundy VGA port, blue Serial port A, teal RJ-45 LAN connector with LED display USB port 0 USB port 2 Intel Server Board S815EBM1 Quick Start Guide... -
Page 8: Front Panel Connectors
Front Panel Connectors J9H4 J9H3 OM12281 Chassis intrusion connector Reserved Reset switch Hard drive activity LED Power LED On/Off Switch No connect Ground +5 V Intel Server Board S815EBM1 Quick Start Guide... -
Page 9: Jumpers
Configure After the POST runs, Setup runs automatically. The maintenance menu is displayed. Recovery None The BIOS attempts to recover the BIOS configuration. A recovery diskette is required. Intel Server Board S815EBM1 Quick Start Guide... -
Page 10: Installation Procedures
Before installing a processor, make sure that it is compatible with this board by checking this URL: http://support.intel.com/support/motherboards/server/S815EBM1/ compat.htm Also note that the thermal solution provided with this board is designed only for use with processors that have an IHS. Intel Server Board S815EBM1 Quick Start Guide... - Page 11 Intel Server Board S815EBM1 Quick Start Guide...
- Page 12 Intel Server Board S815EBM1 Quick Start Guide...
-
Page 13: Installing Memory
The three DIMM sockets are arranged as Banks 0, 1, and 2 as shown. If installing a single DIMM, install it in Bank 0. If installing two DIMMs, install them in Banks 0 and 1. OM12202 Intel Server Board S815EBM1 Quick Start Guide... -
Page 14: Installing The I/O Shield
[20 0.254] DTL M SHT 2 6.390 [162.3] O.039 DTL D DTL P SHT 2 SHT 2 8X R0.5 MIN .884 [22.45] 0.276 [7.012] .000 .465 [11.811] .567 .567 [14.4] [14.4] Pictorial View OM12390 Intel Server Board S815EBM1 Quick Start Guide... -
Page 15: Installing The Server Board
Refer to your chassis manual for specific instructions on installing and removing the server board. Secure the server board to the chassis standoffs using six screws. Insert the screws into the mounting holes as shown in the following figure. OM12203 Intel Server Board S815EBM1 Quick Start Guide... -
Page 16: Connecting The Ide Drives
The connectors are gray and black and are labeled P2 and P3. If only installing one drive, only the end connector of the two closely-spaced connectors should be attached to the drive (i.e. the one labeled P3). OM12205 Intel Server Board S815EBM1 Quick Start Guide... -
Page 17: Getting Help
Credit card calls billed at U.S. $25 per incident, levied in local currency at the applicable credit card exchange rate plus applicable VAT (Intel reserves the right to change pricing for telephone support at any time without notice). - Page 18 Technical Training & Support If you are registered in the Intel Product Dealer Program (North America), the Genuine Intel Dealer Program (Asia-Pacific Region), or the Intel Product Integrator Program (Europe/Latin America), you are eligible for technical training and support. In U.S. and Canada: 1-800-538-3373, ext. 442 (M–F, 5:00 am–5:00 pm, PST) In Europe: contact your distributor or fax your details to European Literature on +44 (0) 1793 513142.
