Intel® Server Board X38ML
Setup Item
Build Date N/A
Processor
<ID string from the N/A
Processor>
Core Frequency N/A
Count N/A
Memory
Size N/A
Quiet Boot
Enabled
Disabled
POST Error Pause Enabled
Disabled
System Date [Day of week
MM/DD/YYYY]
System Time [HH:MM:SS]
4.3.2.2 Advanced Screen
The Advanced screen provides an access point to choose to configure several options. On this
screen, the user selects the option that is to be configured. Configurations are performed on the
selected screen, not directly on the Advanced screen.
To access this screen from the Main screen, select Advanced.
Revision 1.3
Options
N/A
N/A
N/A
N/A
N/A
[Enabled] – Display the logo screen
during POST.
[Disabled] – Display the diagnostic
screen during POST.
[Enabled] – Go to the Error
Manager for critical POST errors.
[Disabled] – Attempt to boot and do
not go to the Error Manager for
critical POST errors.
System Date has configurable
fields for Month, Day, and Year.
Use [Enter] or [Tab] key to select
the next field.
Use [+] or [-] key to modify the
selected field.
System Time has configurable
fields for Hours, Minutes, and
Seconds.
Hours are in 24-hour format.
Use [Enter] or [Tab] key to select
the next field.
Use [+] or [-] key to modify the
selected field.
Intel order number E15331-006
Help Text
Information only. Displays the
current BIOS build date.
Information only. Displays the
Intel processor name and the
speed of the CPU. This information
is retrieved from the processor.
Information only. Displays the
current speed of the boot processor
in GHz or MHz.
Information only. Number of
physical processors detected.
Information only. Displays the
total physical memory installed in
the system in MB or GB. The term
physical memory indicates the total
memory discovered in the form of
installed DIMMs.
N/A
The POST error pause takes the
system to the error manager to
review the errors when Major errors
occur. Minor and Fatal error
displays are not affected by this
setting. See Section 6.3.3 for more
information.
N/A
N/A
System BIOS
Comments
27
