Figure 12. Setup Utility - Pci Configuration Screen Display; Table 13. Setup Utility - Pci Configuration Screen Fields - Intel X38ML - Server Board Motherboard Technical Manual

Intel® Server Board X38ML
Advanced
PCI Configuration
Dual Monitor Video
Onboard NIC ROM
NIC 1 MAC Address
NIC 2 MAC Address
Figure 12. Setup Utility — PCI Configuration Screen Display
Setup Item
Dual Monitor Video Enabled
Disabled
Onboard NIC ROM
Enabled
Disabled
NIC 1 MAC Address No entry
allowed
NIC 2 MAC Address No entry
allowed
4.3.2.3 Security Screen
The Security screen provides fields to enable and set the user and administrative password and
to lock the front panel buttons so they cannot be used.
To access this screen from the Main screen, select the option Security.
Revision 1.3
Enabled/Disabled
Enabled/Disabled
<MAC #>
<MAC #>
Table 13. Setup Utility — PCI Configuration Screen Fields
Options
Both the onboard video controller and an add-in
video adapter will be enabled for system video.
The onboard video controller will be the primary
video device.
Load the embedded option ROM for the onboard
network controllers.
Warning: If [Disabled] is selected, NIC1 and NIC2
cannot be used to boot or wake the system.
N/A
N/A
Intel order number E15331-006
Help Text
System BIOS
Comments
N/A
N/A
Information only. 12 hex
digits of the MAC address.
Information only. 12 hex
digits of the MAC address.
37
