- Page 1 ® Intel Server Board S815EBM1 Product Guide ® A Guide for Technically Qualified Assemblers of Intel Identified Subassemblies/Products Order Number: A67054-003...
- Page 2 Disclaimer Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Intel assumes no responsibility for any errors that may appear in this document.
-
Page 3: Table Of Contents
Front Panel Connectors....................9 Server Board Connector and Component Locations..........10 Processors ........................ 11 Memory ........................11 ® Intel 82815E Graphics Memory Controller Hub (GMCH) ......... 12 ® Intel 82801BA I/O Controller Hub (ICH2) ..............13 Firmware Hub (FWH)....................13 Input/Output (I/O) Controller .................. - Page 4 Setting the BIOS Configuration Jumper................35 Clearing the Passwords...................... 36 Configuration Software and Utilities ® Updating the BIOS with the Intel Express BIOS Update Utility ......... 37 ® Updating the BIOS with the Intel Flash Memory Update Utility ......... 37 Preparing for the Update ...................
- Page 5 5 Technical Reference Server Board Connectors ....................67 Baseboard Connectors ....................68 Power and Hardware Control Connectors ............68 Add-In Board and Peripheral Interface Connectors ........... 69 Server Board Resources ....................70 Memory Map ......................70 DMA Channels ......................70 I/O Map ........................
- Page 6 27. ATAPI CDROM Drives Submenu................. 61 28. Exit Menu........................62 29. Beep Codes ......................... 63 30. BIOS Error Messages ....................64 31. System Memory Map ....................70 32. DMA Channels......................70 33. I/O Map........................71 34. Interrupts ........................72 Intel Server Board S815EBM1 Product Guide...
-
Page 7: Description
Processors Support for either an Intel Pentium III processor in a Flip Chip Pin Grid Array ® (FC-PGA and FC-PGA2) package or an Intel Celeron processor in a FC-PGA ™ package. • Three 168-pin Dual Inline Memory Module (DIMM) sockets Memory •... -
Page 8: Back Panel Connectors
C. USB port 1 D. USB port 3 Parallel port, burgundy VGA port, blue G. Serial port A, teal H. RJ-45 LAN connector with LED display USB port 0 USB port 2 Figure 1. Back Panel Connectors Intel Server Board S815EBM1 Product Guide... -
Page 9: Front Panel Connectors
Front Panel Connectors Figure 2 shows the location of the front panel connectors. J9H4 J9H3 OM12281 Chassis intrusion connector Reserved C. Reset switch D. Hard drive activity LED Power LED On/Off switch G. No connect H. Ground +5 V Figure 2. Front Panel Connectors Description... -
Page 10: Server Board Connector And Component Locations
J9H3 Ground Power LED Connection OM13571 Back panel connectors M. Intel 82801BA I/O Controller Hub (ICH2) Processor fan connector (fan 1) N. SMSC LPC47M132 Super I/O controller ® C. Intel 82815E GMCH O. Serial port B connector D. 370-pin processor socket... -
Page 11: Processors
Processors The board supports a single Intel Pentium III processor or Intel Celeron processor above 533 MHz. Processors are not included with the server board and must be purchased separately. The processor connects to the server board through a PGA370 socket. The board supports the processors listed in Table 2. -
Page 12: Intel ® 82815E Graphics Memory Controller Hub (Gmch)
…will operate at 100 MHz Intel Celeron processor (100 MHz) …will operate at 100 MHz …will operate at 100 MHz Intel Pentium III processor (100 MHz) …will operate at 100 MHz …will operate at 100 MHz Intel Pentium III processor (133 MHz) …will operate at 100 MHz... -
Page 13: Intel ® 82801Ba I/O Controller Hub (Ich2)
® Intel 82801BA I/O Controller Hub (ICH2) The Intel 82801BA ICH2 has these features: • 33 MHz Peripheral Component Interface (PCI) Local Bus slots supporting PCI specification, Rev 2.2. • Support for the Low Pin Count (LPC) interface. • Integrated IDE controller (supports Ultra ATA-66/100 mode and Ultra DMA 33 mode). -
Page 14: Pci Enhanced Ide Interface
The supervisor password gives unrestricted access to view and change all Setup options. If only the supervisor password is set, pressing <Enter> at the password prompt of Setup gives the user restricted access to Setup. Intel Server Board S815EBM1 Product Guide... -
Page 15: Speaker
Jumperless configuration; the LAN subsystem is completely software configurable ® Intel 82562ET Platform LAN Connect Device The Intel 82562ET LAN component provides an interface to the back panel RJ-45 connector with integrated LEDs. The Intel 82562ET provides the following functions: • Basic 10/100 Ethernet LAN connectivity •... -
Page 16: Rj-45 Lan Connector Leds
For Wake on LAN technology, the 5 V standby line for the power supply must be capable of providing adequate +5 V standby current. Failure to provide adequate standby current when implementing Wake on LAN technology can damage the power supply. Intel Server Board S815EBM1 Product Guide... -
Page 17: Wake On Ring
CAUTION If the standby current necessary to support multiple wake events from the PCI and/or USB buses exceeds power supply capacity, the server board may lose register settings stored in memory, etc. Wake on Ring The operation of Wake on Ring can be summarized as follows: •... - Page 18 Intel Server Board S815EBM1 Product Guide...
-
Page 19: Upgrading
2 Upgrading Tools and Supplies Needed • † Phillips (cross head) screwdriver (#1 bit and #2 bit) • Jumper removal tool or needle nosed pliers • Pen or pencil • Antistatic wrist strap and conductive foam pad (recommended) Warnings and Cautions These warnings and cautions apply throughout this chapter. -
Page 20: Memory
Memory CAUTION ® To be fully compliant with all applicable Intel SDRAM memory specifications, the boards require DIMMs that support the Serial Presence Detect (SPD) data structure. You can access the PC Serial Presence Detect Specification at: http://www.intel.com/design/chipsets/memory/ The boards have three 168-pin DIMM sockets arranged as banks 0, 1, and 2 as shown in Figure 4. -
Page 21: Removing Dimms
3. Remove the server’s cover and locate the DIMM sockets (see Figure 4). OM12202 Figure 4. DIMM Socket Locations 4. Make sure the clips at either end of the DIMM socket(s) are pushed outward to the open position. 5. Holding the DIMM by the edges, remove it from its anti-static package. 6. -
Page 22: Installing The I/O Shield
SHT 2 6.390 [162.3] O.039 DTL D DTL P SHT 2 SHT 2 8X R0.5 MIN .884 [22.45] 0.276 [7.012] .000 .465 [11.811] .567 .567 [14.4] [14.4] Pictorial View OM12390 Figure 5. I/O Shield Dimensions Intel Server Board S815EBM1 Product Guide... -
Page 23: Installing The Server Board
Installing the Server Board Refer to your chassis manual for instructions on installing the server board. Six screws secure the server board to the chassis. Figure 6 shows the locations of the mounting screw holes. ✏ NOTES You will need a Phillips (#2 bit) screwdriver. Refer to Page 73 for regulatory requirements and installation instructions and precautions. -
Page 24: Installing A Processor
3. Aligning the pins of the processor with the socket, insert the processor into the socket (see Figure 7, A and C). 4. Close the handle completely (see Figure 7, D). OM11065 Figure 7. Installing the Processor in the Processor Socket Intel Server Board S815EBM1 Product Guide... -
Page 25: Attaching The Heatsink To The Processor
5. Place the fan heatsink on top of the processor (see Figure 8). OM09415 Figure 8. Attaching the Heatsink to the Processor 6. Attach the fan heatsink clips to the processor socket (see Figure 9). OM09416 Fan Heatsink Clip Processor Socket Figure 9. -
Page 26: Removing The Processor
1. Observe the safety and ESD precautions at the beginning of this chapter. 2. Disconnect the processor fan cable. 3. Detach the fan heatsink clips. 4. Remove the heatsink. 5. Raise the socket handle completely. 6. Remove the processor. Intel Server Board S815EBM1 Product Guide... -
Page 27: Installing A 1 Ghz Processor Heatsink
To install a 1 GHz processor, follow the instructions given on page 24, Figure 7. Follow the instructions below to install the fan heatsink to the processor: 1. -
Page 28: Placing The Plastic Clip Over The Fan Heatsink
3. When properly aligned, each edge of the plastic clip should click into place. Hold the clip handle (see Figure 13, A) and very slowly lower the handle until the clip secures the fan heatsink to the processor socket. OM11062 Figure 13. Lowering the Plastic Clip Handle Intel Server Board S815EBM1 Product Guide... -
Page 29: Attaching The Fan To The Fan Heatsink
4. Clip the fan (A) over the fan heatsink (B) as illustrated in Figure 14. OM11061 Figure 14. Attaching the Fan to the Fan Heatsink 5. Connect the processor fan cable to the processor fan connector (see Figure 15). J1B1 J1B1 OM11175 Figure 15. -
Page 30: Removing The 1 Ghz Processor
(see Figure 16). OM11069 Figure 16. Removing the Fan Heatsink 6. Remove the fan heatsink. 7. Raise the processor socket handle completely. 8. Remove the processor. Intel Server Board S815EBM1 Product Guide... -
Page 31: Replacing The Battery
Replacing the Battery When your server is turned off, a lithium battery maintains the time-of-day clock and the keeps the values in CMOS RAM. The location of the server board battery is shown in Figure 17 on page 33. The battery should last about seven years whereupon it begins to lose voltage. When the voltage drops below a certain level, the BIOS Setup program settings stored in CMOS RAM (for example, the date and time) might not be accurate. - Page 32 Haverá risco de explosão se a bateria for substituída por um tipo de bateria incorreto. As baterias devem ser recicladas nos locais apropriados. A eliminação de baterias usadas deve ser feita de acordo com as regulamentações ambientais da região. (Brazilian Portuguese) Intel Server Board S815EBM1 Product Guide...
-
Page 33: Removing The Battery
To replace the battery, follow these steps: 1. Observe the safety and ESD precautions at the beginning of this chapter. 2. Turn off all peripheral devices connected to the server. Disconnect the server’s power cord from the AC power source (wall outlet or power adapter). 3. -
Page 34: Connecting The Ide Cable
Attach the cable end with the two closely spaced connectors (B), which are gray and black and are labeled P2 and P3, to the drives. • If connecting only one IDE drive, be sure to connect the drive to the gray connector (P3). OM12205 Figure 18. Connecting the IDE Cable Intel Server Board S815EBM1 Product Guide... -
Page 35: Setting The Bios Configuration Jumper
Setting the BIOS Configuration Jumper CAUTION Always turn off the power and unplug the power cord from the server before changing the jumper. Moving the jumper with the power on may result in unreliable server operation. J9G2 OM12206 Figure 19. BIOS Configuration Jumper Block Location This three-pin jumper block, shown in Figure 19, enables all server board configurations to be done in BIOS Setup. -
Page 36: Clearing The Passwords
10. Turn off the server. Disconnect the server’s power cord from the AC power source. 11. Remove the server cover. 12. To restore normal operation, place the jumper on pins 1-2 as shown below. Intel Server Board S815EBM1 Product Guide... -
Page 37: Configuration Software And Utilities
Updating the BIOS with the Intel Express BIOS Update Utility With the Intel Express BIOS Update utility you can update the system BIOS while in the † Windows environment. The BIOS file is included in an automated update utility which combines the functionality of the Intel Flash Memory Update Utility and the ease-of use of Windows-based installation wizards. -
Page 38: Obtaining The Bios Update File
New BIOS files • BIOS recovery files • Intel Flash Memory Update Utility You can obtain the BIOS update file through your server supplier or from the Intel World Wide Web site: http://support.intel.com/support/motherboards/server/ ✏ NOTE Review the instructions distributed with the update utility before attempting a BIOS update. -
Page 39: Creating A Bootable Diskette
Example: sys a: To create a bootable diskette using a non-DOS system: 1. Obtain the BIOS update file through your server supplier or from the Intel World Wide Web site: http://support.intel.com/support/motherboards/server/ 2. Copy the BIOS update file to a temporary directory on your hard disk. -
Page 40: Updating The Bios
8. In Setup, enter the settings you wrote down before beginning the BIOS upgrade. 9. To save the settings, press <F10>. 10. To accept the settings, press <Enter>. 11. Turn off the server and reboot. Intel Server Board S815EBM1 Product Guide... -
Page 41: Recovering The Bios
Recovering the BIOS It is unlikely that anything will interrupt the BIOS update, however, if an interruption occurs, the BIOS could be damaged. The following steps explain how to recover the BIOS if an update fails. The following procedure uses recovery mode for the Setup program. See page 35 for more information on Setup modes. -
Page 42: Using The Setup Program
Service (BIS)* components available features features controls Setup credentials, and through the program configures chipset options extended configuration memory settings * For information about the BIS, refer to the Intel Web site at: http://developer.intel.com/design/security/index1.htm Intel Server Board S815EBM1 Product Guide... -
Page 43: Maintenance Menu
Table 7 shows the function keys available for menu screens. Table 7. BIOS Setup Program Function Keys BIOS Setup Program Function Key Description <←> or <→> Selects a different menu screen <↑> or <↓> Moves cursor up or down <Tab> Moves cursor to the next field <Enter>... -
Page 44: Extended Configuration Submenu
Selects the number of clock cycles between addressing Delay a row and addressing a column. • 2 • Auto • 3 SDRAM RAS# Precharge Selects the length of time required before accessing a new row. • 2 • Auto Intel Server Board S815EBM1 Product Guide... -
Page 45: Main Menu
System Time Hour, minute, and Specifies the current time. second System Date Day of week Specifies the current date. Month/day/year ✏ NOTE Additional language support available. For more information visit Intel’s support web site at: www.support.intel.com/support/motherboards/server/S815EBM1. Configuration Software and Utilities... -
Page 46: Advanced Menu
No options Specifies type of connected IDE device. Diskette Configuration No options When selected, displays the Diskette Configuration submenu. Event Log Configuration No options Configures Event Logging. When selected, displays the Event Log Configuration submenu. Intel Server Board S815EBM1 Product Guide... -
Page 47: Pci Configuration Submenu
PCI Configuration Submenu To access this submenu, select Advanced on the menu bar, then PCI Configuration. Advanced Maintenance Main Security Power Boot Exit PCI Configuration Boot Configuration Peripheral Configuration IDE Configuration Diskette Configuration Event Log Configuration The submenu represented by Table 12 is for configuring the IRQ priority of PCI slots individually. Table 12. -
Page 48: Boot Configuration Submenu
Yes clears the PCI/PnP configuration data stored in flash memory on the next boot. • Off Numlock Specifies the power-on state of the Numlock feature on the numeric keypad of the keyboard. • On Intel Server Board S815EBM1 Product Guide... -
Page 49: Peripheral Configuration Submenu
Peripheral Configuration Submenu To access this submenu, select Advanced on the menu bar, then Peripheral Configuration. Advanced Maintenance Main Security Power Boot Exit PCI Configuration Boot Configuration Peripheral Configuration IDE Configuration Diskette Configuration Event Log Configuration The submenu represented in Table 14 is used for configuring server peripherals. Table 14. -
Page 50: Ide Configuration Submenu
• Both • Disabled Hard Disk Pre-Delay Specifies the hard disk drive pre-delay. • 3 Seconds • 6 Seconds • 9 Seconds • 12 Seconds • 15 Seconds • 21 Seconds • 30 Seconds continued Intel Server Board S815EBM1 Product Guide... -
Page 51: Primary/Secondary Ide Master/Slave Submenus
Table 15. IDE Configuration Submenu (continued) Primary IDE Master No options Reports type of connected IDE device. When selected, displays the Primary IDE Master submenu. Primary IDE Slave No options Reports type of connected IDE device. When selected, displays the Primary IDE Slave submenu. Secondary IDE No options Reports type of connected IDE device. - Page 52 • Mode 4 (Note) Cable Detected None Displays the type of cable connected to the IDE interface: 40-conductor or 80-conductor (for ATA-66/100 devices). Note: These configuration options appear only if an IDE device is installed. Intel Server Board S815EBM1 Product Guide...
-
Page 53: Diskette Configuration Submenu
Diskette Configuration Submenu To access this menu, select Advanced on the menu bar, then Diskette Configuration. Advanced Maintenance Main Security Power Boot Exit PCI Configuration Boot Configuration Peripheral Configuration IDE Configuration Diskette Configuration Event Log Configuration The submenu represented by Table 17 is used for configuring the diskette drive. Table 17. -
Page 54: Event Log Configuration Submenu
• No Clear All Event Logs Clears the event log after rebooting. • Yes • Disabled Event Logging Enables logging of events. • Enabled Mark Events As Read [Enter] Marks all events as read. Intel Server Board S815EBM1 Product Guide... -
Page 55: Security Menu
Security Menu To access this menu, select Security from the menu bar at the top of the screen. Security Maintenance Main Advanced Power Boot Exit The menu represented by Table 19 is for setting passwords and security features. Table 19. Security Menu If no password entered previously: Feature... -
Page 56: Power Menu
PCI power management event. • Power-On • Stay Off On Modem Ring In APM mode only, specifies how the server responds to an incoming call on an installed modem when the power is off. • Power-On Intel Server Board S815EBM1 Product Guide... -
Page 57: Apm Submenu
APM Submenu To access this menu, select Power on the menu bar, then APM. Maintenance Main Advanced Security Power Boot Exit ACPI The submenu represented in Table 21 is for setting the APM features. Table 21. APM Submenu Feature Options Description •... -
Page 58: Boot Menu
Specifies the boot sequence from the available hard disk drives. Removable Devices No options Specifies the boot sequence from the available removable devices. ATAPI CDROM Drives No options Specifies the boot sequence from the available ATAPI CD-ROM drives. Intel Server Board S815EBM1 Product Guide... -
Page 59: Boot Device Priority Submenu
After the predefined boot device types (removable devices, hard drives, and ATAPI CD-ROM drives), the entries in this list will reflect as many boot entry vector (BEV) boot devices (for example, Intel UNDI, PXE devices) and SCSI CD-ROM drives as are installed, up to the five BEV boot devices supported by the BIOS. -
Page 60: Hard Disk Drives Submenu
This boot device submenu appears only if at least one boot device of this type is installed. This list will display up to four removable devices, the maximum number of removable devices supported by the BIOS. Intel Server Board S815EBM1 Product Guide... -
Page 61: Atapi Cdrom Drives Submenu
ATAPI CDROM Drives Submenu To access this menu, select Boot on the menu bar, then ATAPI CDROM Drives. Maintenance Main Advanced Security Power Exit Boot Boot Device Priority Hard Disk Drives Removeable Devices ATAPI CDROM Drives The submenu represented in Table 27 is for setting ATAPI CDROM drive priority. Table 27. -
Page 62: Exit Menu
Setup values from flash memory. If this memory is corrupted, the BIOS reads the custom defaults. If no custom defaults are set, the BIOS reads the factory defaults. Discard Changes Discards changes without exiting Setup. The option values present when the server was turned on are used. Intel Server Board S815EBM1 Product Guide... -
Page 63: Solving Bios Problems
4 Solving BIOS Problems The board reports POST errors in two ways: • By sounding a beep code • By displaying an error message on the monitor BIOS Beep Codes The BIOS beep codes are listed in Table 29. The BIOS also issues a beep code (one long tone followed by two short tones) during POST if the video configuration fails, or if an external ROM module does not properly checksum to zero. -
Page 64: Bios Error Messages
NVRAM was invalid and has been updated. Updated Failed NVRAM was invalid but was unable to be updated. Keyboard Error Error in the keyboard connection. Make sure keyboard is connected properly. KB/Interface Error Keyboard interface test failed. continued Intel Server Board S815EBM1 Product Guide... - Page 65 Table 30. BIOS Error Messages (continued) Error Message Explanation Memory Size Decreased Memory size has decreased since the last boot. If no memory was removed, then memory may be bad. Memory Size Increased Memory size has increased since the last boot. If no memory was added, there may be a problem with the system.
- Page 66 Intel Server Board S815EBM1 Product Guide...
-
Page 67: Technical Reference
5 Technical Reference Server Board Connectors CAUTION Many of the baseboard and front panel connectors provide operating voltage (+5 V DC and +12 V DC, for example) to devices inside the server chassis, such as fans and internal peripherals. These connectors are not overcurrent protected. Do not use these connectors for powering devices external to the server chassis. -
Page 68: Baseboard Connectors
Power and Hardware Control Connectors Figure 21 shows the power and hardware connectors. OM12209 Processor fan (fan 1) Power C. Chassis fan (fan 2) D. Wake on LAN technology Figure 21 . Power and Hardware Control Connectors Intel Server Board S815EBM1 Product Guide... -
Page 69: Add-In Board And Peripheral Interface Connectors
Add-In Board and Peripheral Interface Connectors Figure 22 shows the add-in board and peripheral interface connectors. OM12210 PCI slot 3 PCI slot 2 C. PCI slot 1 D. Diskette drive Primary IDE Secondary IDE Figure 22. Add-in Board and Peripheral Interface Connectors Technical Reference... -
Page 70: Server Board Resources
8 or 16 bits Parallel port 8 or 16 bits Diskette drive 8 or 16 bits Parallel port (for ECP or EPP) 8 or 16 bits DMA controller 16 bits Open 16 bits Open 16 bits Open Intel Server Board S815EBM1 Product Guide... -
Page 71: I/O Map
7 bits Secondary IDE channel status port 0378 - 037F 8 bytes LPT1 03B0 - 03BB 12 bytes Intel 82815E GMCH / AGP 03C0 - 03DF 32 bytes Intel 82815E GMCH / AGP 03E8 - 03EF 8 bytes COM3 03F0 - 03F5... -
Page 72: Interrupts
User available Onboard mouse port (if present, else user available) Reserved, math coprocessor Primary IDE (if present, else user available) Secondary IDE (if present, else user available) Default, but can be changed to another IRQ. Intel Server Board S815EBM1 Product Guide... -
Page 73: Regulatory And Integration Information
The S815EBM1 has been has been tested and verified to comply with the following electromagnetic compatibility (EMC) regulations when installed a compatible Intel host system. For information on compatible host system(s) refer to Intel’s Server Builder website or contact your local Intel representative. -
Page 74: Product Certification Markings
The S815EBM1 board has the following product certification markings: • UL joint US/Canada Recognized Component mark: consists of small c followed by a stylized backward UR and followed by a small US. Includes adjacent UL file number for Intel server boards: E210882 (component side). •... -
Page 75: Installation Precautions
Installation Precautions When you install and test the server board, observe all warnings and cautions in the installation instructions. To avoid injury, be careful of: • Sharp pins on connectors • Sharp pins on printed circuit assemblies • Rough edges and sharp corners on the chassis •... -
Page 76: Ensure Chassis And Accessory Module Certifications
The suitability of this product for other applications or environments, (such as medical, industrial, alarm systems, test equipment, etc.) may require further evaluation. Intel Server Board S815EBM1 Product Guide...
