For Helicopter - GRAUPNER MX-12 - PROGRAMMATION Manual

Connections and installations

For Helicopter

BATTERY
SWITCH HARNESS
CHARGING JACK
RECEIVER
ANTENNA
R700 RECEIVER
WARNING
Do not cut or fold the antenna!
GYRO
GEAR
CHANNEL
AUX1
PITCH SERVO
GEAR
RUDD
RUDDER SERVO
ELEV
ELEVATOR SERVO
AILE
AILERON SERVO
THRO
THROTTLE SERVO
Connections and installations 13
