GRAUPNER mz-32 HoTT Reference Manual
  1. Manuals
  2. Brands
  3. GRAUPNER Manuals
  4. Remote Control
  5. mz-32 HoTT
  6. Reference manual

GRAUPNER mz-32 HoTT Reference Manual

32 channel 2.4 ghz transmitter
Hide thumbs Also See for mz-32 HoTT:
Table of Contents

Advertisement

Quick Links

See also: Manual
Help
Reference Manual
mz-32 HoTT
32 channel 2.4 GHz transmitter
P/N. S1024, S1024.77

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the mz-32 HoTT and is the answer not in the manual?

Questions and answers

Brad
March 20, 2025

expo sensitivity is it positive or negitive?

0

Subscribe to Our Youtube Channel

Related Manuals for GRAUPNER mz-32 HoTT

Summary of Contents for GRAUPNER mz-32 HoTT

  • Page 1 Help Reference Manual mz-32 HoTT 32 channel 2.4 GHz transmitter P/N. S1024, S1024.77...

  • Page 2: Table Of Contents

    Graupner mz-32 Help Reference Manual TABLE OF CONTENTS MAIN SCREEN WIDGETS ......................... 4 BASE Menu ............................5 MODEL LIST ............................5 MODEL LIST DETAIL ........................... 5 NEW MODEL ............................5 MODEL TYPE ............................6 RF SET .............................. 7 SERVO SET ............................9 SERVO SET DETAIL ..........................
  • Page 3 Graupner mz-32 Help Reference Manual FREE MIXERS DETAIL ........................25 DUAL MIXERS ...........................25 RING LIMITER ...........................26 RING LIMITER DETAIL ........................26 MIX ONLY CHANNEL ..........................27 CHANNEL SEQUENCER ........................27 SPECIAL Menu ............................28 TELEMETRY ............................28 RF STATUS VIEW ..........................28 SETTINGS AND DATA VIEW ........................29 SYSTEM NOTICE ..........................29...

  • Page 4: Main Screen Widgets

    Graupner mz-32 Help Reference Manual MAIN SCREEN WIDGETS The mz-32 home screen is designed around Widgets. There are a total of 6 decks that can be designed with widgets. Each widget fits inside a 1, 2, or 4 presentation block. Navigation between the decks is...

  • Page 5: Base Menu

    Graupner mz-32 Help Reference Manual BASE Menu MODEL LIST In the Model List menu, you can create a new model or select and load an existing one. To create a new model, tap on the number next to the model name. A selection toolbar will show with the available options.

  • Page 6: Model Type

    Graupner mz-32 Help Reference Manual is increased. A selection of Front causes the throttle channel to decrease as the throttle control is increased. Tap on the stick mode to change your stick mode configuration. When done tap on the Create & Apply button, which will create the model and reinitialize the radio to load the new model.

  • Page 7: Rf Set

    Graupner mz-32 Help Reference Manual RF SET In the RF Set menu you will manage all RF and Telemetry communications between the radio and receiver as well as binding your model to the radio. BINDING You can bind in total 4 receivers to the mz-32. The...
  • Page 8 RF Transmit Default is set to off. Tapping the off field will turn the RF to on. If no receiver is found the radio will sound an error and the Graupner front logo will blink in blue. Auto RF On Setting this field to on will activate the RF immediately after the model is loaded bypassing the RF On/Off dialog shown on startup when the Auto RF is switched to Off.

  • Page 9: Servo Set

    Graupner mz-32 Help Reference Manual Telemetry Speed In those situations where, for example, two airplane models are about to be operated at close proximity to another controlled by two separate transmitters, you may choose to reduce or eliminate the telemetry back channel of one of the models to avoid potential interference.

  • Page 10: Control Set

    Graupner mz-32 Help Reference Manual Limit: sets the maximal servo deflection to a value where the servo does not mechanically bind. B04S2 CONTROL SET In the Control Set menu, you can set the controls such as switches, sliders and buttons that will activate and operate each channel.

  • Page 11: Trim Set

    Graupner mz-32 Help Reference Manual B06S2 TRIM SET In the Trim Set menu, you can set the trim behavior for each of your trims, giving you the most optimal configuration for your trim settings. You can have up to 8 different trims for each of your flight controls.

  • Page 12: Dual Rate Expo

    Graupner mz-32 Help Reference Manual DUAL RATE EXPO The D/R Expo menu enables you to set up control rates and exponential rates for each control surface. You can have up to 8 different control rates where each has four different state values.

  • Page 13: Switch Set

    Graupner mz-32 Help Reference Manual SWITCH SET In the Switch Set menu, you can set the switching point for controls, sliders and switches that can be used for activating mixes and controls when a logic control is used. It also allows you to set the trim steps and speed for the digital trims that are used with control surfaces such as ailerons and elevator.

  • Page 14: Timers Set Details

    Graupner mz-32 Help Reference Manual TIMERS SET DETAILS In the Timer detail menu, you can set all the details for your timer. Run Time - Shows the total time the timer has been running. You can reset the time by either tapping on the reset icon or by assigning a control.

  • Page 15: Fail Safe

    Graupner mz-32 Help Reference Manual FAIL SAFE In the Fail-Safe menu, you can setup the positions of your flight controls in case the receivers lose contact with the radio. Next to each channel there is the option to set the failsafe as follows: Hold –...

  • Page 16: Trim View

    Graupner mz-32 Help Reference Manual When the delay checkbox is tagged, servo movements will be delayed with the delay as specified in the delay field. You can delay servo movements between 0.5 and 3 seconds. To start servo testing, tap on the start field.

  • Page 17: Function Menu

    Graupner mz-32 Help Reference Manual FUNCTION Menu PHASE SET With phases you can create selectable custom settings for specific needs/configurations while operating your model. A Phase with the higher number, as displayed in the Pri column, has priority over a lower numbered Phase.

  • Page 18: No Delay Ch

    Graupner mz-32 Help Reference Manual Tapping on the Trim field for a control surface will activate the edit toolbar where the trim value for each phase can be assigned. Make sure you have the phase active for which you want to enter a new value.

  • Page 19: Wing Tail

    Graupner mz-32 Help Reference Manual You can assign a switch (Input control) to activate a mix or control surface setting by tapping on the respective Ctrl field. The values in the fields Rate A and Rate B will determine the amount of deflection for the control surface in the mix.

  • Page 20: Differential

    Graupner mz-32 Help Reference Manual Tapping on the chain link icon will link Rate A and Rate B for the simultaneous change of the values. You can set a fixed offset for the Elevator/Flap and Elevator/Aileron mixes that will deflect the control surface the moment the elevator has reached the offset position.

  • Page 21: Air Brake Detail

    Graupner mz-32 Help Reference Manual AIR BRAKE DETAIL Attitude (pitch) changes due to control surface deflections may need to be compensated with a positive or negative elevator deflection. Tap on the Other menu selection (detail section) to gain access to the Curve type setting. Tap on the Curve type icon to select single point or multi point curves.

  • Page 22: Throttle Curve

    Graupner mz-32 Help Reference Manual THROTTLE CURVE Note: The same settings can be accessed by selecting Base – Control Set and tapping on Throttle Detail. Changes can be made in either section. The Throttle Curve settings allow you to create a throttle behavior based on your preferences.

  • Page 23: Swash Mixer

    Graupner mz-32 Help Reference Manual On the Basic tab you can set the curve to be global or flight phase dependent. F10S1 SWASH MIXER In the Swashplate Mixer menu, you can adjust the mixing ratios for pitch, roll and nick.

  • Page 24: Heli Mixer Detail

    Graupner mz-32 Help Reference Manual HELI MIXER DETAIL In the Heli Mixer Detail menu, you can set the values for the active mix. The values in the fields Rate A and Rate B will determine the amount of deflection for the active channel in the mix.

  • Page 25: Free Mixers Detail

    Graupner mz-32 Help Reference Manual FREE MIXERS DETAIL Tap on the Other menu selection to set the basic values for the mixer. Tapping on the Group icon will toggle the Group setting between global and phase dependent. Tapping on the Action icon will activate or de-activate...

  • Page 26: Ring Limiter

    Graupner mz-32 Help Reference Manual Tap on the edit icon (pencil) to edit the mixer name. The edit toolbar has also options to delete (trash can) a mixer and change its sorting order (up and down arrow icons). Tap on enter icon (check mark) to complete the changes.

  • Page 27: Mix Only Channel

    Graupner mz-32 Help Reference Manual MIX ONLY CHANNEL The Mix Only channel menu allows you to designate a virtual channel that is used only for controlling a mix, without losing the channel for output. For example, if you assign a switch (Input Control) to channel 8, as the master for enabling a mixer input.

  • Page 28: Special Menu

    Graupner mz-32 Help Reference Manual SPECIAL Menu TELEMETRY In the Telemetry menu you can access various functions viewing setting telemetry functions. In case multiple receivers are bound to the transmitter you will need to select the receiver which will be used for the telemetry data. It is possible to switch between receivers for telemetry data or turn Off telemetry entirely.

  • Page 29: Settings And Data View

    Graupner mz-32 Help Reference Manual The dots above the bar mark the worst reception signal levels since the opening of the "RF Status" display. Reset these data points by simply exiting and reentering this display. Additional numeric information about the signal levels is provided on the left.

  • Page 30: User Notice

    In the Sensor Notice menu you can activate additional telemetry notifications which are not listed in the User Notice menu. Each sensor such as the Graupner General Air Module or Vario may generate additional telemetry information which can trigger notifications depending on the preset values for the sensor.

  • Page 31: Control Notice

    Graupner mz-32 Help Reference Manual S04S1 CONTROL NOTICE In the Control Notice menu, you can select switches (Input Control) that will trigger announcements based on their position. Tap on the page icon, next to Help icon, to set the Notice Group as global or phase dependent.

  • Page 32: Voice Notice

    Graupner mz-32 Help Reference Manual VOICE NOTICE In the voice notice menu, you can assign controls to telemetry notifications which can be activated manually with a switch (Input Control) or played sequentially with a preset delay. Tap on the plus sign (only visible if no Voice Notice has been configured) or the number field of an existing Voice Notice to add a Voice Notice.

  • Page 33: Logical Switch

    On condition for the Combi Switch. S09S1 DIGITAL SWITCH The mz-32 HoTT transmitter features 64 digital switches. Each of these 64 Digital Switches can be arbitrarily placed as a widget on one of the widget pages and operated from there.

  • Page 34: Vario Tone

    Graupner mz-32 Help Reference Manual On the receiver side, these digital switches can be assigned to a channel. The mapping of a digital switch to a receiver channel as output can be done either in the “RF Set” menu (Base section) or directly in the receiver using the Telemetry Setting & Data View ASCII menu.

  • Page 35: Trainer

    You can use your Graupner radio for training purposes in a Teacher/Student mode. This operation can be done wireless with two Graupner radios or with a cable between a Graupner radio and other transmitter brands, using the DSC port on the back of the radio.

  • Page 36: Mp3

    Graupner mz-32 Help Reference Manual You can play MP3 files on your mz-32 Transmitter. MP3 files need to be copied to the MP3 folder on the installed SD card. This can be done after placing the mz-32 in Mass Storage mode.

  • Page 37: System Menu

    Stop field, turning the logging function On and Off. It’s important to take advantage of data logging as the mz-32 will record important operational data. In many cases Graupner is not able to provide support to its customers without a log file. The logging can also be started and stopped by pressing the double arrow key (lower key left of screen).

  • Page 38: Display Set

    DSC and/or Data port. The DATA fields control the output protocols available on the DATA port. SUMD – This is Graupner specific protocol. You can set the number of output channels and the channel mapping for your setup.

  • Page 39: Stick Set

    Graupner mz-32 Help Reference Manual S-BOX – View the telemetry information on the screen of a connected Graupner Smart- Box. EXT-M – View the telemetry information on the screen of a connected Smart-Box. CRSF – When a TBS CROSSFIRE module is used the proper version must be selected. If required, you can map the channels.

  • Page 40: Wlan & Gps

    Graupner mz-32 Help Reference Manual done by tapping on the blue icon below Joystick icon. When joystick mode is active no other functions can be selected until that mode has ended. Tapping on the Joystick icon will ask for confirmation to turn off the function.

  • Page 41: Info & Update

    FTP Wireless Update When a new firmware is available on the Graupner update server the FTP blue field will show a red color dot and the latest firmware version number is displayed in the field.

  • Page 42: Disclaimer

    The current version can be found on the Internet at www.graupner.com on the relevant product page. In addition, the company Graupner/SJ has no responsibility or liability for any errors or inaccuracies that may appear in construction or operation manuals.

This manual is also suitable for:

S1024S1024.77

Table of Contents
