System Mode
Model Type Selection; Model Copy Function

Model Type Selection

The mx-12 is capable of performing as a helicopter or
airplane radio with full functions for each.
Modulation
(No display when Model name
Model Name (if programmed)
displayed)
Model Number
Model Type Function
Go to Model Copy
menu
Go to Model Name
menu
Toggle between
Model Type and
Data Reset
Accessing the Type Selection Function
1. While pressing the Down and Select keys, switch
the transmitter to the ON position to enter the Model
Setup mode.
2. Press either the Up or Down keys until MODEL
TYPE is displayed in the left portion of the LCD.
3. Pressing either the (+) or (-) key will change the type
of model.
4. Press the Select key to move the cursor to the
Data Reset position.
5. Press the Clear key to reset the memory to the
factory defaults.
6. Press the Down key to access the MODEL NAME
function.
7. Press the Up key to access the MODEL COPY
function.
8. Press the Down and Select keys simultaneously
to exit the MODEL TYPE function.

Model Copy Function

The Copy Selection function enables you to copy all of
the settings of the current model to another model within
the same transmitter. This is very useful when setting
up one aircraft several different ways or when trying an
alternative setup of your current model.
Model Number being programmed
Change model type
selection
Reset Date (when
selected)
Model number to be copied to
Go to Model Copy
menu
Go to Model Type
menu
Accessing the Model Copy Function
1. While pressing the Down and Select keys, move
the transmitter`s power switch to the On position.
2. Press either the Up or Down key until MODEL
COPY appears on the top left of the LCD.
3. The upper number that appears is the current model.
This is important to note as only the current model
will the copied. Press the (+) or (-) keys to select the
desired program (lower number) to copy the current
model to.
4. Next, press the Clear key. The current model will
then be copied to the selected model.
Note: Always make sure that the accepting model is
either free of input or one which you no lon
ger want to retain in your transmitter`s me
mory. Once the copying process has been
completed,the information of the accepting
model is lost and the current model is input as
the new data.
5. Press the Up key to access the MODULATION
function.
6. Press the Down key to access the MODEL TYPE
function.
7. Press the Down and Select keys simultaneously
to exit the MODEL COPY function.
Model Type Function
Change model to
copy to
Perform copy
function
System Mode 37
