Transmitter description

Transmitter callouts
Hovering Pitch Trim (For HELI)
Flap Trim (For AIRPLANE)
Throttle Hold SW (For HELI)
Flap Mixing SW (For AIRPLANE)
Elevator D/R SW
Trainer SW
Elevator Rudder Stick
Elevator Trim
Rudder Trim
On/Off SW
Entry Key
Antenna
Neck Strap
Eyelet
LCD Display
Control stick length adjustment
To adjust the stick lenght, use the 2mm Allen wrench
(supplied with your mx-12 transmitter) to unlock the set
screw. Turn the wrench counterclockwise to loosen the
Hovering Throttle Trim screw. Then turn the stick clockwise to shorten or coun-
(for HELI)
terclockwise to lenghten. After the control stick lenght
Rocker SW
has been adjusted to suit your flying style, tighten the
(for AIRPLANE)
2mm set screw. If you desire longer sticks, GRAUPNER
Carrying Bar
offers a stick that is approximately one inch longer than
standard. This stick, crafted from bar stock aluminum, is
available at your local GRAUPNER dealer.
Flight Mode SW
(for HELI)
Gear SW (for
HELI+AIRPLANE
Aileron D/R SW
TIGHTEN
Throttle Cut SW
Neck strap attachment
An eyelet is provided on the face of the mx-12 transmit-
Throttle (Pitch)
ter that allows you to connect a Neck Strap. This hook
-Aileron Stick
has been positioned so that your transmitter has the
best possible balance when you use the neck strap.
Throttle Trim
Aileron Trim
Entry Key
SET SCREW
LOOSEN
