System Mode
Model Selection; Model Name Entry
Model Selection
The mx-12 system offers memory for ten completely
separate models. Therefore, it is possible to have a
mixture of helicopter and airplane setups retained in
memory. It is also recommended that the Model Name
Entry function be used in conjunction with each model
setup. Another very useful function of the Model Selec-
tion function is the ability to set one aircraft up several
different ways. This is helpful when multi-task perfor-
mance is desired.
Model Number (1~20) Type
Modulation
Model Name (If programmed)
Go to model name
menu
Go to Wing Type or
Swash Plate menu
Toggle between
Model and Timer
Accessing the Model Select Function
1. While pressing the Down and Select keys, switch the
transmitter to the ON position to enter the Model
select mode.
2. Model Select will be displayed on the upper left
portion of the LCD. If not, press the Up or Down
key until MODEL SEL is displayed.
3. Pressing the (+) or (-) key will select among each of
the ten models available. Notice that as each model
is selected, its name appears in the LCD.
4. Once the desired model is displayed on the left,
36 System Mode
pressing the Down and Channel keys simultane-
ously will exit the Model Selection function and
establish the model displayed as the new current
model.
5. Press the Select key to select the timer function to
clear the Total Timer. Press the Clear key to clear
the Total timer.
6. Press the Down key to access the WING TYPE
function.
7. Press the Up key to access the MODEL NAME
function.
8. Press the Down and Select keys simultaneously
to exit the MODEL SEL function.

Model Name Entry

The mx-12 allows on 8-digit name to be input for each
of the ten models available. The current model will be
displayed in the Normal display.
Change selected
character
Clear Timer
(when selected)
Model number
Go to Model
Type menu
Go to Model
Select menu
Select
character
Accessing the Model Select Function
1. While pressing the Down and Select keys, switch the
transmitter to the ON position to enter the Model
2. Press the Up or Down key until MODEL NAME is
3. Press either the Up or Down key to select the first
4. Press the Select key to advance the character
5. Repeat this procedure until all eight characters have
6. Press the Down key to access the MODEL SEL
7. Press the Up key to access the MODEL TYPE
8. Press the Down and Select keys simultaneously to
Selectable character:
Type Modulation
Model name beeing programmed
Change selected
character
Reset selected
character to blank
space
select mode.
displayed.
character for the model name.
selection to the next character.
been selected.
function.
Selection function.
exit the MODEL NAME function.
