Eurosets COLIBRI SYSTEM Instructions For Use Manual page 54

P High RPM
Negative Blood
P
Flow
P Low Pdrain
P High Pdrain
P Low Pin
P High Pin
P Low Pout
P High Pout
P Low DP
P High DP
P Air Detected
54
Measured/selected RPM value is bigger
than maximum value sets in Alarm Page
Measured blood flow is less than 0.00
LPM
Measured drainage pressure is less than
minimum value sets in Alarm Page
Measured drainage pressure is bigger
than maximum value sets in Alarm Page
Measured pre-oxygenator pressure is
less of minimum value sets in Alarm Page
Measured pre-oxygenator pressure is
bigger than maximum value sets in Alarm
Page
Measured post-oxygenator pressure is
less than minimum value sets in Alarm
Page
Measured post-oxygenatoer pressure is
bigger than maximum value sets in Alarm
Page
Calculated pressure drop value is less
than minimum value sets in Alarm Page
Calculated pressure drop value is bigger
than maximum value sets in Alarm Page
Air Bubble is detected
Check any case which may compromise the flow are presents.
Ensure appropriate RPM alarms are set.
High
Consider to decreased LPM (if LPM control is enable) to decrease
the flow if appropriate.
Check for and resolve a physiological or mechanical cause.
High
Consider to increased RPM to increase the flow if appropriate.
Check for and resolve a physiological or mechanical cause. Ensure
appropriate pressure alarms are set. Consider recalibrating the
Medium
transducer if alert cannot be explained by conventional
troubleshooting.
Check for and resolve a physiological or mechanical cause. Ensure
appropriate pressure alarms are set. Consider recalibrating the
Medium transducer if alert cannot be explained by conventional
troubleshooting. Consider reducing RPM to reduce the pressure if
appropriate.
Check for and resolve a physiological or mechanical cause. Ensure
appropriate pressure alarms are set. Consider recalibrating the
Medium
transducer if alert cannot be explained by conventional
troubleshooting.
Check for and resolve a physiological or mechanical cause. Ensure
appropriate pressure alarms are set. Consider recalibrating the
Medium transducer if alert cannot be explained by conventional
troubleshooting. Consider reducing RPM to reduce the pressure if
appropriate.
Check for and resolve a physiological or mechanical cause. Ensure
appropriate pressure alarms are set. Consider recalibrating the
Medium
transducer if alert cannot be explained by conventional
troubleshooting.
Check for and resolve a physiological or mechanical cause. Ensure
appropriate pressure alarms are set. Consider recalibrating the
Medium transducer if alert cannot be explained by conventional
troubleshooting. Consider reducing RPM to reduce the pressure if
appropriate.
Check for and resolve a physiological or mechanical cause. Ensure
Medium
appropriate pressure drop alarms are set.
Check for and resolve a physiological or mechanical cause. Ensure
Medium
appropriate pressure drop alarms are set.
The device is able to detect air bubble higher than 65 µL. Check any
leakage on tubing set are present.
High
This error may occur at the beginning of priming phase, when the
tubing are empty.
en
