10.3.

AMBULANCE POWER MODULE

During road ambulance transport, in case of low
battery and/or main supply not available, the device
can be powered from the 24V Ambulance socket to its
relevant 24V socket.
In order to avoid any electrical interference between
COLIBRÌ System and ambulance on board systems,
the dedicated Ambulance Power Module interface
EU3953 must be used.
Using its clip hanging system, Ambulance Power Module can be mounted on the side rails of COLIBRÌ Console.
Figures below describe module connectors
24V POWER MODULE connector
Warning
•
Do not connect the 24V connection directly to the Ambulance 24V power source.
•
Check the integrity of Ambulance Power Module before using the module.
•
In case of Ambulance Power Module failures, disconnect the Ambulance Power Module
and connect a charged auxiliary battery.
•
Ambulance Power Module meets ECE R10 regulation requirements.
44
24V Ambulance connector
