FUNCTIONAL CONNECTION
Using the dedicate cable (ECMOLIFE-COLIBRÌ cable EU11108), you can connect the COLIBRÌ system to the
ECMOLIFE System as follow:
1. Check the integrity of ECMOLIFE-COLIBRÌ
cable.
2. Ensure the ECMOLIFE-COLIBRÌ cable to the
dedicated socket of ECMOLIFE connector
panel.
3. Ensure the ECMOLIFE -COLIBRÌ cable to the
24V connector socket (A) of COLIBRÌ top
panel.
4. Using the Colibrì hanging system (B), fix the
Colibrì System on the rear side of ECMOLIFE
console.
5. Turn on the ECMOLIFE console e proceed with
the diagnostic phase.
Warning
•
In case of Primary Unit failure, keep the Primary Emergency Button activated in order to
prevent any electric interference and proceed the treatment using the COLIBRÌ in
standalone configuration.
•
Before starting the support, check that the Backup Unit battery is fully charged
•
Activate the ECMOLIFE Backup Unit only in case of ECMOLIFE Primary Unit and COLIBRÌ
Unit failure.
•
Keep a backup flowmeter sensor ready for use.
•
In case of double fault condition of ECMOLIFE System and COLIBRÌ System, please active
the backup device and proceed with the treatment.
