5. USER INTERFACE

5.1. DISPLAY

STATUS BAR
On the top of touchscreen there is the status bar with
the following settings:
1. Date and Time;
2. Charge status Symbol and remaining time;
The status bar color indicates priority of ongoing alarm:
Color Priority
Red High priority alarm
Yellow Medium priority alarm
Blue Low priority alarm
Green Normal operations
If several alarms are simultaneously present with the same priority, the status bar will show the one more recently
actuated.
If several alarms are simultaneously present with different priority, the status bar display will show the higher
priority alarm first then the others in order of priority then appearance.
The touchscreen underlines alarms also by highlighting the parameter concerned (See the alarm section).
CENTRAL PART
The central part of the COLIBRÌ display is composed by:
1. Blood Flow parameter;
2. RPM parameter;
3. Active page title
