2.2.3. RIGHT PANEL

The right panel is composed by:
1. External Battery connection #1;
2. External Battery connection #2;
3. WiFi Antenna;

2.2.4. LEFT PANEL

The left panel is composed by:
1. Flowmeter/Air sensor connection;
2. USB;
3. Emergency switch.
Warning
•
Only USB standard model is supported by the device.
•
Do not connect any USB devices supplied by own power sources.
