2.2.1. TOP PANEL

The top panel is composed by:
1. ON/OFF button;
2. P3to1 disposable pressure sensor connection;
3. Main Power Supply connection;
4. 24V connection;
Connected to the bracket rear side:
5. COLIBRÌ hanging system
Warning
Do not install extra device, different from devices indicated by the manufacturer, on the COLIBRÌ
hanging system.

2.2.2. DISPLAY

The display is composed by:
1. a Led RGB battery;
2. a Led RGB alarm
3. 4 membrane buttons;
4. a 3,5" Touch display;
