Invacare® LiNX
This is the initial amount of time the switch must be pressed and held before the mouse speeds up. This setting is used in conjunction with
Initial Mouse Movement and Maximum Cursor settings.
D
This setting controls the amount of time the directional switches must be activated before the cursor will move. This is to allow for
inadvertent switch closures. Note: This applies to directional switches only.
E
This setting controls the amount of time the Left and Right Click switch must be held before it will latch. Once the latch is no longer required,
press the Right Click or Left Click switch for the same length of time to deactivate the latch.
F
Switch 11 and 12 should be in the DOWN position when using with the Head Array for 3 switch mouse emulation.
G
OFF: Original mouse speed, better for PC.
ON: Increases mouse speed by 1/3, better for MAC.
Numbers 0 to 6 describe the action the mouse should perform.
Letters A to F describe the direction of the input, which leads to the mouse action.
86
Dip switch 7 & 8: Switch delay
disabled
Dip switch 9 & 10: Latch delay
disabled
Dip switch 11 & 12: Cursor movement options
3 switch
OFF
0.5 sec
1.0 sec
4 switch
ON
1.0 sec
2.0 sec
4 switch 5 switch
2.0 sec
4.0 sec
1637423-K
