4.16 Operating Powered Seating Functions
Powered seating functions, such as powered elevating legrests or powered recline, are carried out as described below.
4.16.1 Through Seating Cards
By default, every seating card displays a single powered seating f unction. Different configurations are listed below. Contact
your p rovider to change the configuration.
Choose the seating card with the seating function you want to operate, refer to 4.3 Selecting Functions, page 23.
D
C
1. Give forward or reverse demand to operate seating function.
When a motion becomes active, navigation button disappears A, the active direction of the motion B is displayed, the
other becomes inactive C and drive inhibit / lockout icon D is displayed in the status bar.
Motion is deactivated as soon as demand is released or when motion reaches its end-of-travel.
B
A
Displayed Symbols And Their Meanings
Seat tilt
Recline
1637423-K
Seat lifter
Stand function
Left or central l egrest
Right legrest
4 Usage
Bothlegrests
Recline and l egrests
