TERMS AND DEFINITIONS ..............9 IR DEVICE CODES ..................25 INFRARED SETUP, PROGRAMMING AND USAGE ......10 DEALER: keep this manual. The procedures in this manual MUST be performed by a qualified technician. For more information regarding Invacare products, parts, and services, please visit www.invacare.com.
Caution indicates a potentially hazardous situation which, if not avoided, may result in property damage or minor injury or both. IMPORTANT Indicates a hazardous situation that could result in damage to property if it is not avoided. Gives useful tips, recommendations and information for efficient, trouble-free use. Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Page 4
Invacare warrants all electronics and electrical components (excluding batteries), motors, powered seating actuators and gearboxes to be free from defects in materials and workmanship for a period of one (1) year from the date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty.
Page 5
Invacare warrants all electronics and electrical components (excluding batteries) to be free from defects in materials and workmanship for a period of two (2) years from the date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty. If within such warranty periods any such product component shall be proven to be defective, the product component shall be repaired or replaced, at Invacare's option with refurbished or new parts.
- otherwise, injury or damage may result. ACCESSORIES WARNING Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. NOTICE THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
If the wheelchair does not perform to specifications, turn the wheelchair Off IMMEDIATELY and re-enter setup specifications. Repeat this procedure until the wheelchair performs to specifications. Updated versions of this manual are available on www.invacare.com. Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
2.0.0 or later on the color MPJ+. The new Invacare IR/Mouse Module is an accessory that can be ordered with new power wheelchairs, or added to existing power wheelchairs using MK6i electronics and an expandable (4 drive mode) system. Standard features include both infrared control and computer (PC and Mac) mouse emulation.
Secure all cabling and wires to the power wheelchair base. Programming the IR/Mouse Module Programming should only be completed by qualified individuals. Programming can be accomplished using a Professional SD-Card, the MK6i Remote Hand Held Programmer (HHP), or the MK5 Remote HHP.
Page 11
Scroll down to <IR CONTROL>, then scroll across to desired drive for IR use and press <SELECT> Choose 3-QUAD or 4-QUAD to activate the IR Control in that drive. Refer to IR Device Features on page 16. Press <SAVE>, then press <SAVE> again as prompted. Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Page 12
IR control (Turning on 3-Quad or 4-Quad) for individual drives. Turn off the power to the wheelchair. Insert the Basic SD-Card into the MK6i Display (or Joystick) Turn on the wheelchair. Use the down arrow (Display), or reverse command (MPJ+), to scroll down to IR SETTINGS.
Page 13
FIGURE 2 Learning the Key LEARNED KEYS. The feature allows the learnt codes to be cleared and can be used at any time. Realize that performing this feature erases all learned keys for all devices. Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
IR next screen. Mode. The following screen shot from the MK6i Display Unit indicates that the IR Control Mode is in Drive 4. If IR Control is set to 3-QUAD, use the right command to scroll right to the next device or continue scrolling to wrap around to the GO BACK icon.
Page 15
Left driver command to execute the feature. Executing the GO BACK feature allows the user to select a different device or exit IR mode. Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
(These features repeat when held active.) Color MPJ+ Keypad Access (TV-ENH Only) allows the user to enter a 1, 2, 3 or 4 digit chan- nel directly. Input Source (TV-ENH Only) 3 Favorite Channels (TV-ENH Only) Invacare® MK6i™IR Control/ Mouse Emulation Part No 1160891...
Page 17
7 IR Device Features DEVICE TYPE FEATURE SYMBOL FEATURE DESCRIPTION MONOCHROME DISPLAY COLOR MPJ+ DVD AND VCR Power On/Off Play Monochrome Display Stop Rewind/Fast Forward Color MPJ+ Select Menu Up, Down, Left, Right Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Page 18
Color MPJ+ Next Directory Entry Previous Directory Entry AUDIO DEVICE Power On/Off Volume Up/Down Monochrome Display (These features repeat when held active.) Channel Up/Down (These features repeat when held active.) Color MPJ+ Invacare® MK6i™IR Control/ Mouse Emulation Part No 1160891...
Page 19
The following turn on/off each device Color MPJ+ CABLE OR SATELLITE Power On/Off Volume Up/Down Monochrome Display (These features repeat when held active.) Channel Up/Down (These features repeat when held active.) Color MPJ+ Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Mouse Emulation Programming The MK6i Driver control used with an expandable system can be programmed to use the mouse in any drive. All programming for mouse control is in the “Performance Adjust” menu.
Page 21
If the parameter is zero, the mouse speed does not ramp up. High Speed Factor Used with High Speed Delay to increase mouse speed movement when moving cursor across the PC desktop. Choices are NONE, 2X, 4X and 8X. Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Page 22
• True 3-quadrant driver controls (i.e., ASL Head Array) can have mouse functions reassigned (i.e., Forward command for mouse click, left and right commands for mouse movement). • Mouse axis re-assignment does not change driving axis selections (driving axis assignment selected in separate performance adjustment). Invacare® MK6i™IR Control/ Mouse Emulation Part No 1160891...
Page 23
The left driver command emulates clicking the left mouse button. A sustained left command will select an icon or type an insertion point to allow for dragging. A second left command will deselect. Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Page 24
"MouseTool 3.13" Donationware ($20 to any charity of choice) http://www.quillmouse.com/ "Quill NIB" $49.00 http://www.infogrip.com/product_view.asp?RecordNumber=219&sbcolor=006600&optiontxt=Search "Dragger" $95 http://www.infogrip.com/product_view.asp?RecordNumber=988&sbcolor=006600&optiontxt=Search "PointSmart" $99 (Mouse Driver Enhancement Software) http://www.infogrip.com/product_view.asp?RecordNumber=222&sbcolor=006600&optiontxt=Search "SmartClick" $109 http://www.gusinc.com/dwell.html Gus Dwell Cursor $125 http://www.madentec.com/products/magic-cursor.php "MagicCursor 2000" $230 Free demo Invacare® MK6i™IR Control/ Mouse Emulation Part No 1160891...
Page 60
088, 128, 132, 136, WINERSAT WINTERGARTEN US DIGITAL WISI 074, 085, 086, 087, USDTV 088, 132, 135, 138 VARIOSAT WOORISAT VARIOSTAT WORLDSAT VEGA XRYPTON VENTANA XSAT 142, 152 VIA DIGITAL ZAUNKONIG VIASAT Invacare® MK6i™IR Control/ Mouse Emulation Part No 1160891...
Page 61
2036 ALIENWARE 1272 POPCORN HOUR 2260 APPLE 2615 ROKU 1486, 2371 CYBERPOWER 1272 SLING MEDIA 2612 GATEWAY 1272 SUREWEST 1481 HEWLETT 1272 VUDU 2298 PACKARD WESTERN 2558 HOWARD 1272 DIGITAL COMPUTERS 1272 Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Page 62
0739, 0740 NETWORK TOSHIBA 1272 SYSTEMS TOUCH 1272 HUMAX 0739 VIEWSONIC 1272 HUSH 1972 VOODOO 1272 IBUYPOWER 1972 XBOX 2049 LINKSYS 1972 ZT GROUP 1272 MEDIA CENTER 1972 MICROSOFT 1972 MIND 1972 Invacare® MK6i™IR Control/ Mouse Emulation Part No 1160891...
Page 63
1972 GOODMIND 2450 VOODOO 1972 GRIDLINK 2348 ZT GROUP 1972 INSIGNIA 1415 LASONIC 2348 DTA Converter Codes MAGNAVOX 1563 BRAND CODE MEMOREX 2486 BEFORE 10/1/2011 AFTER 10/1/2011 MICROGEM 2489 ACCESS HD 2185 Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Page 75
AUDIOVOX 1390 BRAND CODE BOSE 1229, 1629, 1933 BEFORE AFTER CAMBRIDGESOUND 1370 10/1/2011 10/1/2011 WORKS AUDI DVD/AUDIO COBY DENON 2857, 2279 AIWA 1388, 1641 FISHER 1801 AKAI 1512 GATEWAY 1517 HITACHI 1801 Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Page 76
ZENITH 1293 PHILIPS 1266, 2311, 2459 TV/DVD/Tuner Combo Codes PIONEER 1384 BRAND CODE POLK AUDIO 1289, 2270 BEFORE 10/1/2011 AFTER 10/1/2011 1609, 1390, TUNE TV, DVD, TUNER 1511, 2041 1869 PANASONIC 279 Invacare® MK6i™IR Control/ Mouse Emulation Part No 1160891...
Page 77
PANASONIC 314 Tuner/CD Combo Codes Tuner/CD Combo Codes BRAND CODE BRAND CODE BEFORE 10/1/2011 AFTER 10/1/2011 BEFORE 10/1/2011 AFTER 10/1/2011 TUNER TUNER, CD TUNER TV, TUNER AIWA AUDIOVOX BOSE GRADIENTE EMERSON PHILIPS POLAROID Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Page 78
9 IR Device Codes Home Automation Codes BRAND CODE BEFORE 10/1/2011 AFTER 10/1/2011 LIGHTOLIER 0184 LUTRON 0597, 1239, 1597 0184 RUSSOUND 1232 SMARTLINC 0184 2267 Invacare® MK6i™IR Control/ Mouse Emulation Part No 1160891...
Page 79
9 IR Device Codes Notes Part No 1160891 Invacare® MK6i™IR Control/ Mouse Emulation...
Page 80
Invacare Corporation Canada One Invacare Way 570 Matheson Blvd E Elyria, Ohio USA Unit 8 44036-2125 Mississauga Ontario 800-333-6900 L4Z 4G4 Canada 800-668-5324 www.invacare.com Part No 1160891 Rev D - 4/12...
