Invacare® LiNX
For further maintenance and cleaning instructions, refer to 5 Maintenance, page 91.
Sip and Puff is not the most manoeuvrable or intuitive control method and therefore requires a considerable amount of training. In the
early tuning stages, this is best done outdoors in an unrestricted but safe area. Also the presence of an attendant is recommended.
Driving
The drive function cards for the Sip-N-Puff are pre-set in latched driving mode. For more information, refer to 4.10 Latched Driving Mode, page 37.
B
A
For more information about the calibration of hard a nd soft demands, see the service manual of the LiNX system.
Stopping
A lipswitch B is mounted to the mouthpiece. This switch can be used as an external stop switch, when in latched driving mode. While you are in
latched driving, you do not need to give a drive demand all the time, but the mouthpiece must stay inside your mouth. As soon as the lipswitch is
pressed while driving, the wheelchair stops.
Changing Function Cards
The lipswitch can also be used as a mode function switch.
For difference between function card and profile, refer to 2.2.3 User Function Card Overview, page 8.
1. Stop wheelchair.
2. Short press lipswitch to change function card.
3. Long press lipswitch to change profile.
78
1. Puff hard into mouthpiece A to drive forwards.
2. Sip hard at mouthpiece to drive in reverse.
3. When in latched driving mode, puff soft into mouthpiece to veer to the right.
4. When in latched driving mode, sip soft at mouthpiece to veer to the left.
